- Page 1 UC-3400A Series Quick Installation Guide Version 1.1, February 2025 Technical Support Contact Information www.moxa.com/support 2025 Moxa Inc. All rights reserved. P/N: 1802034000002 *1802034000002*...
-
Page 2: Package Checklist
Overview Moxa’s UC-3400A Series computers can be used as edge gateways in the field for data pre-processing and transmission, as well as for other embedded data-acquisition applications. The series includes a diverse set of models, each supporting different wireless options and protocols. - Page 3 UC-3424A-T-LTE UC-3430A-T-LTE-WiFi UC-3434A-T-LTE-WiFi - 3 -...
-
Page 4: Led Indicators
Dimensions LED Indicators Color Status Function Name Green Steady on Power is on Power is off Steady on System is ready for use Green Blinking System is booting up READY Steady on System initialization failed System is still in the bootloader stage, kernel not up yet SIM card inserted Green... - Page 5 Color Status Function Name 3 LEDs Signal is good Steady on 2 LEDs Signal is moderate/ok Steady on (Cellular Green Signal 1 LED Signal is poor Strength) Steady on No signal Green Blinking Serial port is transmitting data P1/P2 (Serial Yellow Blinking Serial port is receiving data...
- Page 6 Wall Mounting (optional) The UC-3400A can also be wall mounted. The wall-mounting kit needs to be purchased separately. Refer to the product datasheet for information on the wall-mounting kit to be purchased. For the mounting dimensions, refer to the figure below: To mount the computer on to a wall, do the following: 1.
-
Page 7: Connector Descriptions
The additional four screws are not included in the wall-mounting kit and must be purchased separately. Refer to the following specifications for the additional screws to be purchased. Head Type: Pan/Doom Head Diameter: 5.2 mm < Outer Diameter (OD) < 7.0 mm Length: >... - Page 8 ATTENTION The product is intended to be supplied by a UL Listed Power Unit marked “L.P.S.” (or “Limited Power Source”) and rated 9 to 48 VDC, 1.2 A (min.), Tma = 70°C. If you need further assistance with purchasing the power source, contact Moxa for further information.
- Page 9 CAN Port The UC-3424A and UC-3434A models come with two CAN ports which use the terminal block connector and are compatible with the CAN 2.0A/B standard. SIM Card Slot The UC-3400A comes with a Nano-SIM card slot, a console port, and a microSD slot on the front panel.
- Page 10 Console Port The console port located on the left side of the SIM card slot is a RS- 232 port that can connect to a 4-pin pin header cable. You can use this port for debugging or firmware upgrade. Signal –...
- Page 11 Wi-Fi The UC-3430A-T-LTE-WiFi and UC-3434A-T- LTE-WiFi models come with a built-in Wi-Fi module. Connect the antenna to the RP-SMA connector marked W2 to enable the use of the Wi-Fi function. Bluetooth The UC-3430A-T-LTE-WiFi and UC-3434A-T- LTE-WiFi models come with a built-in Bluetooth module.
-
Page 12: Certification Information
Certification Information Model Type and Model Name on the Product Labels The UC-3400A Series models and models of other Moxa products have been organized into different model types for UL certification purposes. The following table maps the commercial names of the UC-3400A... - Page 13 警語 為避免電磁干擾，本產品不應安裝或使用於住宅環境。 - 13 -...
