BXP-A101 Series Windows 10 IoT
Enterprise LTSC 2021 (21H2) User Manual
Version 1.0, January 2025
www.moxa.com/products
© 2025 Moxa Inc. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BXP-A101 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Moxa Technologies BXP-A101 Series

Summary of Contents for Moxa Technologies BXP-A101 Series

  • Page 1 BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual Version 1.0, January 2025 www.moxa.com/products © 2025 Moxa Inc. All rights reserved.

  • Page 2: Copyright Notice

    BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice © 2025 Moxa Inc. All rights reserved.

  • Page 3: Table Of Contents

    Table of Contents Introduction ............................4 Moxa Windows ............................4 System Initialization ..........................5 Initializing User Settings ......................... 5 Initializing System ..........................9 BitLocker ............................10 Enabling the BitLocker .......................... 10 Disabling the BitLocker ......................... 14 Teaming .............................. 17 Intel® Net Team ..........................17 Creating an Intel®...

  • Page 4: Introduction

    Moxa computers are integrated with Windows drivers and I/O controller utilities based on the recent up-to- date version of Microsoft Windows so that you can use the most compatible hardware-software combination in your application fields. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 5: System Initialization

    Microsoft Account, and share information with the OEM. Initializing User Settings The following is a non-exhaustive list of OOBE screens that you will see in the order that they are listed here: Select a region. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 6 Select a keyboard. Select a second keyboard. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 7 Connect to a network or continue with limited setup. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 8 Sign in to or create a local account or a Microsoft account (MSA). Set a password. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 9: Initializing System

    After the OOBE settings, you will be redirected to the device desktop of the device. Wait until the process is complete. The device will reboot, and the new settings will take effect after the system restarts. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 10: Bitlocker

    For more information about BitLocker, go to: https://learn.microsoft.com/en-us/windows/security/operating-system-security/data-protection/bitlocker/ This chapter describes the BitLocker setup process. Enabling the BitLocker In the Windows Devices and drives, right-click on the drive and select Turn on BitLocker. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 11 Select an option to back up the recovery key. For example, select Save to a file. Select the path to store the file in. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 12 Follow the onscreen instructions to specify the drive encryption options. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 13 Click Continue. Restart the computer. Wait for the encryption process to complete and then click Close. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 14: Disabling The Bitlocker

    Disabling the BitLocker In the Windows Devices and drives, right-click on the drive and select Manage BitLocker. Click on Turn off BitLocker. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 15 Wait for the decryption process to complete and click Close to exit the program. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 16 Check the disk status after the decryption process is completed. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 17: Teaming

    Intel® Net Team This chapter describes the setup process for the Intel® Teaming function. Creating an Intel® Net Team Run Intel® PROSet Adapter Configuration Utility as administrator. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 18 Select the adapter to include in this team and click Next. An Intel® ANS team can contain a maximum of eight members. Name the team and select a team type. Click Next to continue. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 19 Select the primary and secondary adapters for the team and click Finish to create an Intel® Net team. Check the Network adapters in the Windows Device Manager. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 20: Removing An Intel® Net Team

    Removing an Intel® Net Team Select an Intel® Net team and click Remove Team to remove the specified Intel® ANS team. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 21: Unified Write Filter

    After UWF is enabled, you can select a drive that you want to protect and start using UWF. UWF can help you manage PCs and devices remotely using WMI. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 22: Turning On Uwf On A Running Pc

    Click Close. Enable the following filter as an Administrator: • cmd uwfmgr filter enable Enable write protection for a drive: • cmd uwfmgr.exe volume protect C: BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 23: Installing Uwf Using Wmi

    Dynamic configuration changes occur immediately and persist after a device restarts. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 24: Driver

    From the Software & Documentation page, filtered by Driver and download the driver package. The driver packages are categorized by their OS version, with separate sections for Peripheral and Expansion modules. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 25: Utility

    The utilities come preinstalled on the device if the Windows 10 OS is provided by Moxa. If you have installed Windows 10 on your own, go to https://www.moxa.com/en/support to download the utilities. On the support page, search for your device (e.g., MC-3201). BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 26: Dependent Packages

    Use the following links to download and install the packages. • Microsoft Visual C++ Redistributable: https://learn.microsoft.com/en-us/cpp/windows/latest-supported-vc-redist?view=msvc-170 • Microsoft .NET Framework 4.8: https://support.microsoft.com/en-us/topic/microsoft-net-framework-4- 8-offline-installer-for-windows- 9d23f658-3b97-68ab-d013-aa3c3e7495e0 BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 27: Moxa Io Controller Utility

    Run the mx-dio-ctl --help command to see the instructions on using this utility and follow them to get or set the DIO status. IMPORTANT The DIN and DOUT indices start at 0. Even though the console output starts at 1, the indices still start at BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 28: Setting The Uart Mode

    UART mode. IMPORTANT The UART index starts from 0. Even though the console output starts at 1, the index still starts at 0. Example: BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 29: Setting Pcie Slot Power Status

    PCIE slot power. IMPORTANT The PCIE Slot index starts from 0. Even though the console output starts at 1, the index still starts at 0. Example: BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 30: Setting Pcie Reset Pin Status

    PCIE reset pin status and delay time . IMPORTANT The PCIE reset pin index starts from 0. Even though the console output starts at 1, the index still starts at Example: BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 31: Moxa Serial Interface Utility

    Install the Moxa Serial Interface utility. From the Windows Start menu, run the Moxa Serial Interface utility. Select the target COM port and UART mode and click Apply to save the settings. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 32: Moxa Sort Net Name Utility

    If you want to rename the Ethernet adapter, wait for the installation process to complete. The order of the Ethernet adapter will correspond to the order of the label (e.g., LAN 2 of the computer is mapped to Ethernet 2 in Windows). BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 33: Io Control Api

    8. IO Control API This chapter describes how to use the IO Control API. Downloading the API Go to https://www.moxa.com/en/support. Select your product series (e.g., DA-820). Download the related files. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 34: Mxdgio

    The following error codes can be retrieved using the DIO_STATUS function. Name Value Meaning LIB_INITIALIZE_FAIL The mxdgio library initialization failed. Cannot open json profile. Requirements Name Items Header mxdgio.h Library mxdgio.lib mxdgio.dll Profile MxdgioProfile[ModelName].json BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 35: Getdoutcount

    Meaning LIB_INITIALIZE_FAIL The mxdgio library initialization failed. Cannot open json profile. PORT_OUTOF_INDEX Target port index is out of range. Requirements Name Items Header mxdgio.h Library mxdgio.lib mxdgio.dll Profile MxdgioProfile[ModelName].json BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 36: Getdoutstatus

    PORT_OUTOF_INDEX Target port index is out of range. SET_STATUS_ERR Status setting failed or is defined with a bad format. Requirements Name Items Header mxdgio.h Library mxdgio.lib mxdgio.dll Profile MxdgioProfile[ModelName].json BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 37: Mxsp

    The following error codes can be retrieved using the UART_STATUS function. Name Value Meaning LIB_INITIALIZE_FAIL The mxsp library initialization failed. Cannot open json profile. Requirements Name Items Header mxsp.h Library mxsp.lib mxsp.dll Profile MxspProfile[ModelName].json BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 38: Getuartmode

    Status setting failed or is defined with a bad format. NOT_SUPPORT_MODE Target mode is not supported for this port. Requirements Name Items Header mxsp.h Library mxsp.lib mxsp.dll Profile MxspProfile[ModelName].json BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 39: Mxpcie

    Meaning LIB_INITIALIZE_FAIL The mxpcie library initialization failed. Cannot open json profile. PORT_OUTOF_INDEX Target port index is out of range. Requirements Name Items Header mxpcie.h Library mxpcie.lib mxpcie.dll Profile MxpcieProfile[ModelName].json BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 40: Setpcieslotstatus

    PORT_OUTOF_INDEX Target port index is out of range. SET_STATUS_ERR Status setting failed or is defined with a bad format. Requirements Name Items Header mxpcie.h Library mxpcie.lib mxpcie.dll Profile MxpcieProfile[ModelName].json BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 41: Setpcieslotstatuswithreset

    PORT_OUTOF_INDEX Target port index is out of range. SET_STATUS_ERR Status setting failed or is defined with a bad format. Requirements Name Items Header mxpcie.h Library mxpcie.lib mxpcie.dll Profile MxpcieProfile[ModelName].json BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 42: Mxpciereset

    Meaning LIB_INITIALIZE_FAIL The mxpciereset library initialization failed. Cannot open json profile. PORT_OUTOF_INDEX Target port index is out of range. Requirements Name Items Header mxpciereset.h Library mxpciereset.lib mxpciereset.dll Profile MxpcieresetProfile[ModelName].json BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 43: Setresetslotstatus

    The interval at which the watchdog timer is refreshed; the unit is seconds. Return Value Returns the pointer to the watchdog handle; returns -1 on failure to initialize the watchdog timer. Requirements Name Items Header mxwdg.h Library mxwdg.lib mxwdg.dll BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 44: Mxwdg_Refresh

    Disables the watchdog timer. Parameters fd: The handle of the watchdog timer. Return Value This function does not return a value. Requirements Name Items Header mxwdg.h Library mxwdg.lib mxwdg.dll BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 45: System Backup Restore

    UEFI BIOS machine. This chapter describes the setup process of the Windows Recovery function. Preparing the USB device Contact a Moxa technical staff and get the required file. Run the BuildWindowsRecoveryUSB_V1.2.0.exe. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 46 Select the USB drive to format. Click ... to select .wim file from the folder. Click Start and make sure the selected USB can be formatted. Click Yes to start creating the recovery USB. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 47 You can close the windows after the process finishes. To create a recovery USB disk with the Windows 10 image, copy the os_image_ModelName directory to the \home\partimag folder in the USB drive. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 48: Booting From The Usb Disk

    Turn on the computer and press F2 when you hear the beep sound to enter the BIOS setup menu, select Boot Manager and press Enter to continue. Select the EFI USB Device on the computer and press Enter to continue to boot from the USB device. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 49: System Image Backup

    Windows Recovery utility will display. Follow these steps. Click Backup. Select the Source disk to backup and Destination USB to store the OS image, also give an image name and description. Click Start to backup. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 50 Click Yes to continue. Wait for the backup process to complete. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 51 When the process is done, click OK. Click OK, the computer will shut down. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 52 The OS image will be saved in USB disk at home\partimag. In the os_image folder you can view the backup information and the image files. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...

  • Page 53: Restoring The System From A Backup

    Recovery utility will display. Follow these steps. Click Recovery. Select the Source USB Device, Image Folder File and check the image information, select the Destination Drive to restore. Click Apply. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 54 If dual operating systems are required, we recommend restoring the image to the destination drive with the PCIe interface (if available) first. Click Yes to continue the process. Click Yes to overwrite the destination drive. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
  • Page 55 The system configuration files will be initialized during the first boot- up process. Do not turn off or shut down the computer while the system is restarting. BXP-A101 Series Windows 10 IoT Enterprise LTSC 2021 (21H2) User Manual...
