  • Page 1 Please visit our website for the most current instructions, assembly tips, to report damage or request parts. www.walkeredison.com Revised 11/2023-V1 Copyright © 2018, by Walker Edison Furniture Co., LLC, All rights reserved.
  • Page 3 Part# Description Part# Description Top panel 01 pc Division 01 pc Left side panel 01 pc 02 pcs Back panel 01 pc Right side panel Drawer front 06 pcs Frame 01 pc Drawer back 06 pcs 01 pc Drawer bottom 06 pcs Bottom rail 02 pcs...
  • Page 4: Hardware List

    Hardware List 55 pcs Wooden dowel Ø8*30mm 29 pcs Ø4*40mm Screw 51 pcs Ø4*30mm Screw 38 pcs ø15*12mm Cam Lock 12 pcs Ø3*12mm Screw Handle 6 pcs Ø8*40mm Wooden dowel 12 pcs 40 pcs ø5,0*24mm Cam Bolt 38 pcs 1 pcs Wall anchor 2 pcs Washer...
  • Page 5 Insert wood dowel (A) into part 1,4,5,6,10,18,19, and 21. Step 1 Ø8*30mm Step 2 Attention to the dowel length: ø10*20mm Ø10*20mm Insert wood dowel (N) into part 9. Step 3 Attention to the dowel length: ø10*20mm Ø10*20mm Insert wood dowel (N) into part 8.
  • Page 6 Step 4 Ø4*25mm Join part 7 to part 6, using wood dowel (N) Secure part 7 to part 6 with Ø10*20mm screw (O) using a Phillips head screwdriver. Step 5 Insert Cam Bolt (I) into part1,2,3,4 and 12 using Phillips head screwdriver. ø5,0*24mm...
  • Page 7 Step 6 Secure part 8 to parts 2 and 3 with screw (B) using a Phillips head screwdriver. Ø4*40mm Step 7 Secure part 9 to parts 10 with screw (C) using a Phillips head screwdriver. Ø4*30mm...
  • Page 8 Step 8 Secure part 4 to part 10 with Cam Lock (D) using Phillips head screwdriver. ø15*12mm Step 9 Join part 4 and 10 to part 1, proceed to Ø4*40mm secure part 4 with screw (B) using Phillips head screwdriver. Secure part 10 to part 1 using Phillips head screwdriver.
  • Page 9 Step 10 Secure part 5 to parts 4 and 10 with screw (B) using Phillips head screwdriver. Ø4,0*40mm Step 11 Join parts 2 and 6 to parts 1,4 and 10, secure part 6 with screw (C) using Phillips head screwdriver. Ø4*30mm...
  • Page 10 Step 12 Ø4*40mm Secure part 2 to part 4 with screw (B) using Phillips head screwdriver. Secure part 2 to part 1 and 5 with Cam Lock (D) ø15*12mm using Phillips head screwdriver. Step 13 Join parts 3 and 6 to parts 1,4 and 5, secure part 6 with screw (C) using Phillips head screwdriver.
  • Page 11 Step 14 Ø4*40mm Secure part 3 to part 4 with screw (B) using Phillips head screwdriver. Secure part 3 to part 1 and 5 with Cam Lock (D) ø15*12mm using Phillips head screwdriver. Step 15 Secure hardware (J) and (K) to part 1 with Ø3,5*14mm screw (L) using Phillips head screwdriver.
  • Page 12 Step 16 Secure part 11 to parts 1,2,3,6 and 10 with nails (H). Attention: Position the part 11 recess facing the top. Step 17 Secure part 18 and 19 to parts 12 with Cam lock (D) using a Phillips head screwdriver. ø15*12mm Step 18 Insert panel 14 into groves of part 18 and 19...
  • Page 13 Step 19 Secure part 13 to part 18 and 19 with screw (C) using Phillips head screwdriver. Ø4*30mm Step 20 Secure parts 18 and 21 to parts 12 with Cam lock (D) using a Phillips head screwdriver. ø15*12mm Step 21 Insert panel 14 into groves of part 18 and 21 P.13...
  • Page 14 Step 22 Secure part 13 to part 18 and 21 with screw (C) using Phillips head screwdriver. Ø4*30mm Step 23 Insert wood dowel (A) into the front hole in the drawer rails 8 and 9. Ø8*30mm P.14...
  • Page 15 Step 24 Wall anchor and hardware are included with this product. Please make sure hardware is suitable for your walls before types of anchors. Ø4*30mm Name and address information for the manufacturer responsible for the anti-tip hardware and date of production can be found on the label on the back of the furniture. P.15...
  • Page 16: Warning Label

    The side drawer with Step 25 WARNING LABEL, should be mounted in highest drawer. Insert wood dowel (G) on the inside of all drawers, Ø8*40mm with the drawer inside the unit after having passed the wood dowel that is in the drawer slide. dowel is not flush with the panel, it is a little inside Ø3*12mm the drawer to help when you need to remove the...
