Rowlinson Garden Products SS637 Assembly Instructions Manual

Before assembly
• We recommend that time is taken to read
the instructions before starting assembly,
then follow the easy step by step guide.
The instruction sheet is only a guide to the
assembly. Certain items may not be shown
to scale.
• Check all components prior to assembly
• This product should be assembled by no less
than two people
• Drill all components where indicated
• Gloves are recommended when handling
components
x 2
Gloves
Drill
Recommended tools for assembly
• Power Drill/Screwdriver
• Cross-head drill bit
• 3mm diameter drill bit
• 6mm diameter drill bit
• Tape measure
• Hammer
• Sharp knife
• Spirit level
• Step ladder
No. Components
1 Floor
2 Side wall panel
(Width 1174mm)
3 Back/Front wall panel
(Width 860mm)
4 Front panel
(Width 190mm)
5 Apex panel
6 Roof rafter
7 Roof rafter support block
8 Roof rafter brace
9 Roof rafter block
(Length 150mm)
10 Roof purlin
(Length 1174mm)
11 Felt batten
(Length 1186mm)
12 Roof panel
13 Roof felt roll
(5m)
14 Roof ridge felt roll
(2.5m)
15 Door header rail
(28x28x670mm)
16 Door rebate strip
(12x22x1685mm)
17 Door
18 Door weatherstrip
(12x48x830mm)
19 Coverstrips
(12x40x1715mm)
20 Bargeboard
21 Finial
No. Fixing Kit
22 T-Hinge
23 Pad bolt
24 Turn button
25 50mm coach bolt
26 Nut
27 Washer
28 60mm screws
29 50mm screws
30 32mm screws
31 25mm screws
32 20mm screws
33 30mm nails
34 10mm felt nails
8'x6' Shiplap
Single Door Shed
Assembly Instructions
Please Note
This instruction shows the
building construction with the
door to the left-hand side of the
front. If preferred the door can be
positioned to the right-hand side.
1
1 3
Qty.
1
1 4
2
4
3
1
2
2
2
1
4
4
4
4
1
1
1
1
1
2
7
4
2
16
Qty.
3
4
1
1
4
4
4
15
48
22
44
28
6
61
128
21
6
8
5
7
15
18
17
23
24
