Rowlinson Garden Products SS639 Assembly Instructions Manual

Before assembly
• We recommend that time is taken to read
the instructions before starting assembly,
then follow the easy step by step guide.
The instruction sheet is only a guide to the
assembly. Certain items may not be shown to
scale.
• Check all components prior to assembly
• This product should be assembled by no less
than two people
• Drill all components where indicated
• Gloves are recommended when handling
components
x 2
Gloves
Drill
Recommended tools for assembly
• Power Drill/Screwdriver
• Cross-head drill bit
• 3mm diameter drill bit
• 6mm diameter drill bit
• 12mm diameter drill bit
• Tape measure
• Hammer
• Sharp knife
• Spirit level
• Step ladder
• Silicon sealant
No. Components
1 Floor
2 Side wall panel
(Width 1174mm)
3 Window panel
(Width 1174mm)
4 Back/front wall panel
(Width 860mm)
5 Front panel
(Width 190mm)
6 Apex panel
7 Roof rafter
8 Roof rafter support block
9 Roof rafter brace
10 Roof rafter block
(Length 150mm)
11 Roof purlin
(Length 1174mm)
12 Felt batten
(Length 1186mm)
13 Roof panel
14 Roof felt roll
(5m)
15 Roof ridge felt roll
(2.5m)
16 Door header rail
(28x28x670mm)
17 Door rebate strip
(12x22x1685mm)
18 Door
19 Door weatherstrip
(12x48x830mm)
20 Coverstrips
(12x40x1715mm)
21 Window frame
22 Glazing
(560x520mm)
23 Window beading
(15x15x565mm)
24 Window beading
(15x15x489mm)
25 Bargeboards
26 Finial
No. Fixing Kit
27 T-Hinge
28 Pad bolt
29 Turn button
30 50mm coach bolt
31 Nut
32 Washer
33 60mm screws
34 50mm screws
35 40mm screws
36 32mm screws
37 25mm screws
38 20mm screws
39 30mm nails
40 25mm panel pins
41 10mm felt nails
8'x6' Shiplap Single Door
Shed With Window
Assembly Instructions
Please Note
This instruction shows the
building construction with the
door to the left-hand side of the
front. If preferred the door can be
positioned to the right-hand side.
Biocidal Products Regulation EU 528/2012
Wolmanit® CX treated wood, is a treated article incorporating
biocidal products: copper
cyclohexyl-diazenium-dioxy)-copper
protect wood against fungal decay, rot and insect attack. Wear
gloves when handling freshly treated wood. Avoid breathing dust
when cutting wood. Dispose of off-cuts responsibly.
Qty.
2
3
1
1 4
1
3
1
1
2
1 5
2
2
1
4
4
4
4
1
1
1
6
1
1
2
7
1
1
2
2
4
2
Qty.
3
1
1
4
4
5
4
17
15
18
48
4
44 27
28
6
28
61
12
128
hydroxide carbonate, bis(N-
and Boric Acid. They
9
10
7
4
16
8
1
2 1
1
2 2
19
24
23
29
English SS639
26
11
1
1 3
3
1
25
12
2
20
