Rowlinson Garden Products SS292 Quick Start Manual

6. Roof felt

Cut the roll of felt in to to equal lengths. Place a length of felt on one side of the roof. At front and back and along the lower
edge of the roof leave an overhang of felt of at least 45mm. Fold down the felt along the lower edge and secure to the felt
batten using 15 x 10mm felt nails evenly spaced. Dress the felt over the roof ridge, tension and secure along the edge using
4 x 10mm felt nails. position the second piece of felt in the same way as the first on the other side of the roof. Attach to
the felt batten using 15 x 10mm felt nails, tension over the roof and secure with 15 x 10mm felt nails. At the front dress
down the felt and secure to the felt blocks and the ends of the felt battens using 6 x 10mm felt nails per end. At the back
secure to the back panel using 6 x 10mm felt nails. Using a sharp knife trim off any excess felt.
10mm
10mm

7. Bargeboards

On each end of the roof secure two bargeboards, ensure that the top edges are flush with the roof line and the boards
meet evenly at the apex secure using 3 x 30mm nails per board.
30mm

Important information

Shiplap buildings come ready stained but this is only a preparatory treatment. To VALIDATE the guarantee, the building must be properly
treated with a recognised external wood preserver WITHIN 3 MONTHS of assembly and RE-TREATED ANNUALLY thereafter.
Adequate provision must be made to ensure ground contact is avoided and air is able to circulate underneath the building. Placing the
building on a concrete pad or slab base is acceptable provided that the building is not allowed to sit in pooled water during wet conditions.
If the building is to sit on soil or grass it MUST be erected on pressure treated wooden 50mm x 50mm or similar bearers (These are
not supplied in the kit). Rowlinson Garden Products recommend using pressure treated bearers with all buildings on any type of base.
Timber Information.
As timber is a natural material, there are certain weather conditions that may affect the materials properties. In times of excessive dry
spells the material may lose some of its internal moisture causing a certain degree of shrinkage on a panel and in periods of excessive rain
there will be a certain amount of swelling throughout the wooden panels. This process can not be avoided. If you have problems with
certain boards shrinking in dry spells try to decrease the amount of direct sunlight on the building or the amount of air passing over the
building. During hot spells spray water directly onto the panels with the aid of a garden hose.
If in doubt of any aspect regarding the assembly, use or safety of your kennel please contact us:
Help Line (Normal Office Hours) 01829 261 121
ROWLINSON GARDEN PRODUCTS LIMITED
Green Lane
Wardle Nr. Nantwich
Cheshire
CW5 6BN
10mm
10mm
30mm
We constantly improve the quality of our products, occasionally the
components may differ from the components shown and are only
correct at time of printing. We reserve the right to change the
specification of our products without prior notice.
2012 © Rowlinson Garden Products Ltd
Medium Dog Kennel

Assembly Instructions

Before assembly

• We recommend that time is taken to
read the instructions before starting
assembly, then follow the easy step by
step guide. The instruction sheet is only
a guide to the assembly.
Certain items may not be shown to scale.
• Check all components prior to assembly
• This product should be assembled
by no less than two people
• Drill all components where indicated
x 2
Drill

Recommended tools for assembly

•
Cross head screw driver
•
Drill with 3mm diameter drill bit
•
Tape measure
•
Hammer
.
No. Components
Qty
1 Floor 1
2 Front panel 1
3 Side panel 2
4 Back panel 1
5 Purlin 1
6 Roof panel 2
7 Felt Batten 2
8 Bargeboard block 4
9 Roof felt 1
10 Bargeboards 4
.
No. Fixing kit
Qty
11 63mm screws 2
12 50mm screws 8
13 40mm screws 7
14 30mm nails 46
15 10mm felt nails 60
English SS292
5
8
6
9
7
1
2
3
10
4
