Rowlinson Garden Products SS214F Assembly Instructions Manual

Before assembly
• We recommend that time is taken to read
the instructions before starting assembly,
then follow the easy step by step guide.
The instruction sheet is only a guide to the
assembly. Certain items may not be shown
to scale.
• Check all components prior to assembly
• This product should be assembled by no less
than two people
• Drill all components where indicated
x 2
Gloves
Drill
Recommended tools for assembly
• Power Drill/Screwdriver
• Crosshead drill bit
• 3mm diameter drill bit
• 12mm diameter drill bit
• Hammer
• Sharp knife
• Spirit level
• Silicon sealant
• Step ladder
• Hacksaw
No. Components
1 Floor
2 Back wall panel
3 Small wall panel
4 Small window panel
5 Door panel
6 Left-hand large window
7 Right-hand large window
8 Left door (Catch plate rebate)
9 Right door (Lock rebate)
10 Window frame
11 Roof centre block
12 Large roof panel
13 Corner roof panel
14 Roofing felt roll
(4m)
15 Roof cap/inside cover
16 Acorn finial
17 Short bargeboard
18 Long bargeboard
19 Corner coverstrip
20 Window glazing
(372x 263mm)
21 Door glazing
(372x 190mm)
22 Window panel coverstrip
23
Door bead top/bottom
(14x10x405mm)
24
Door/Window bead TR/BL*
(14x10x380mm)
25
Door/Window bead TL/BR*
(14x10x380mm)
26
Door/Window bead middle
(14x10x390mm)
27
Door/Window vertical spar
(44x10x360mm)
28 Door horizontal spar
(44x10x390mm)
29 Window horizontal spar
(44x10x537mm)
30
Window bead top/bottom
(14x10x555mm)
* TR/BL = Top right/bottom left
TL/BR = Top left/botom right
No. Fixing Kit
31 Door lock and catch plate set
32 Door handle kit
33 Door handle spindle
34 Door hinge 300mm (12")
35 Door hinge 75mm (3")
36 Tower bolt
37 Window hinge
38 Window stay
(black)
39 63mm screws
40 50mm screws
41 25mm screws
42 25mm black screws
43 25mm brass screws
44 20mm screws
45 19mm roundhead screws
46 30mm nails
47 25mm panel pins
48 10mm Felt nails
Ryton 8'x8'
Octagonal Summerhouse
Assembly Instructions
Caution
This product
contains glass.
Wear protective
work gloves while
handling these
components.
Dimensions:
For information on
building dimensions
please see back page.
