MULTISPAN EM 10-M1 Operating Manual page 3

EM 10-M1
Modbus
Setting

MODBUS
Slave Address :
Baudrate :
Parity :
Datatype :
Read Function Register :
Write Function Register :
Access
Sr.No
Parameter
Type
1
R Kwh
2
R Line1 kw
3 Line2 kw
R
R Line3 kw
4
R Total kw
5
R/W CT Ratio
6
Pulse Mode
7 R/W
Selection
Auto
Manual
8 R/W Pulse Out
Selection
0.01
0.1
1
10
9
R/W Pulse on time
10
R/W Address
Buadrate
R/W
11
Selection
9600
19200
38400
12
R/W Parity
Selection
Non Non
Even
Odd
13
R/W Energy Reset
Page - 3


(35)


























Address

1
to
127
Baudrate
9600,19200,38400
Parity
None/Even/odd

1 to 127
9600,19200,38400bps
None,Even,Odd
Float (32 Bit Little Endian Byte Swap)
0x03 and 0x04
0x06 and 0x10
Register
Data Type
Float
0
2
4
6
8
10
12
14
Value
0 0
1
16
Value
0 0
1
2
3
18
20
Value
22
0 0
1
2
24
Value
0 0
1
2
26
