15. Detachable/Removable Parts
1. Mattress (Detached from the Control Unit by removing the CPR connector). Part No. MAT12 (or variants of for the size).
2. Electric power cable. (Removed from the Control Unit by pulling the cable away from the mains inlet on the side of the Control Unit).
Part No. SP021016
Note: The battery is an integral part of the PCB and is not removable or changeable. Use of detachable parts not listed is not recommended by
DHG.
16. Disposal
All contaminated mattresses must be disposed of as clinical waste in accordance with regional and local regulation and guidelines.
Control units are electrical/electronic medical devices and must be disposed of in line with the Waste Electrical and Electronic Equipment Directive
(WEEE).
Please refer to www.dhg-healthcare.com for recommendations and responsibilities for disposal with the UK WEEE guidelines.
17. Technical Information
Control Unit
Electrical Supply
Power Rating
Fuses
Protection Against Shock
Noise Level
Dimensions
Weight
Mattress
Number of Air Cells
Air Cell Size
Foam Density (kg/m )
3
Nominal Hardness (N)
Minimum User Weight
Maximum User Weight
IFU
220-240VAC, 50/60Hz or 100-120VAC,
50/60Hz
10VA (220-240VAC) or 8VA
(100-120VAC)
TA1H 250V
Class 2
30dB(A)
245mm (W) x 160mm (H) x 95mm (D)
1.7kg
14 foam-in-air cells / 1 static foam head
cell
Variable (W) x 8cm (H) x 10cm (D)
U-Core: 38-40
Insert: 38-40
U-Core: 200
Insert: 120
10kg
254kg
Service Interval
Expect Life
Shelf Life of Parts
Alternating Cycle Type
Alternating Cycle Time
Warranty
Weight of Mattress
Expected Life of Mattress
Fire Testing
Sizes
Warranty
12 months / 8760 hours
5 years
5 years
1-in-2
10 minutes
2 years
13.3kg
8 years
BS 7177, Medium hazard
Length: 100-220cm
Width: 60-180cm
Height: 15cm
2 years
