What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything
that is listed below.
Director's Monitor Cage
4 x Side Brackets
4 x Button Heads
(Size: 1/4"-2")
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable
Director's Cage for 4"-7" LCD Camera Monitors (P-DMC-01)
A s s e m b l y M a n u a l
4 x Posts
2 x Handles
Neck Strap
16 x Spring Washers
(Size: 6mm)
All rights reserved.
copyright statutes or in writing by the Publisher.
2 x Offset Brackets
14 x Button Heads
(Size: 1/4" x 5/8")
4 x Washers
(Size: 6x10x1mm)
2 x Main Brackets
8 x Button Heads
(Size: 1/4" x 3/8")
1 x L-Type Allen Key
(Size: 4mm)
1
Advertisement
Related Manuals for PROAIM P-DMC-01
Summary of Contents for PROAIM P-DMC-01
- Page 1 Director's Cage for 4”-7” LCD Camera Monitors (P-DMC-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
- Page 2 Director's Cage Setup Director’s Monitor Cage Assembly • Insert the (6mm) spring washer into the (1/4”-2”) Button Heads and insert it into the Director’s Monitor Cage, as shown in the image. • Now, insert the post into the button Head. •...
- Page 3 • Repeat the same step for attaching the second Main Bracket. Offset Bracket Assembly • Mount the Offset Bracket on the Main Bracket and insert the (1/4”x 3/8”)button head aligning with the threads. • Tighten the button heads using the 4mm Allen Key.
- Page 4 Handle Assembly • Attach the handle to the Side Bracket and insert the (1/4” x 5/8”)button head & spring washer. NOTE: To attach the Handle, loosen the button head of the Side Bracket as needed and adjust the side Bracket per your requirement. •...
- Page 5 • Remove the Bolt and the Post. • Repeat the same step to remove the other bolt and post NOTE: To mount the screen, remove bolts and post , from one Main Bracket only. • Mount the Screen (Not Included) on the Director’s Monitor Cage and insert the button head into the Screen by aligning with the...
- Page 6 Neck Strap Assembly • Attach the hook of the Neck strap to the Side Bracket. Feature: The included neck strap helps keep you fatigue-free while walking/running with the cage. • You can easily adjust the strap length using the buckle to suit your convenience and setup requirements.
- Page 7 YOUR PROAIM DIRECTOR'S CAGE FOR 4”-7” LCD CAMERA MONITORS ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
