Declaration SIGLENT products are protected by patent law in and outside of P.R.C. SIGLENT reserves the right to modify or change parts of or all the specifications or pricing policies at the company’s sole decision. Information in this publication replaces all previously corresponding material.
Contents Copyright Information ......................1 General Safety Summary ...................... 3 Safety Terms and Symbols ....................4 Allgemeine Sicherheitsübersicht.................... 5 Sicherheitsbegriffe und -symbole ..................7 General Inspection ........................ 8 Preparation Before Use ......................9 Quick Start ........................... 10 Panel Introduction ........................ 11 User Interface ........................
General Safety Summary Understand the following safety precautions to avoid personal injury and prevent damage to this product or any other products connected to it. In order to avoid possible dangers, please use this product in accordance with regulations. Only qualified technicians can perform maintenance procedures. Prevent fire or personal injury.
Safety Terms and Symbols Terms used in this product. These terms may appear in the product: DANGER Indicates direct injury or hazards that may happen. WARNING Indicates potential injury or hazards that may happen. CAUTION Indicates potential damage to the instrument or other property that may happen. Symbols used in this product.
Allgemeine Sicherheitsübersicht Lesen Sie die folgenden Sicherheitshinweise sorgfältig durch, um Verletzungen oder Schäden am Gerät und an den daran angeschlossenen Produkten zu vermeiden. Um mögliche Gefahren zu vermeiden, verwenden Sie das Gerät bitte wie angegeben. Verwenden Sie ein geeignetes Netzkabel Verwenden Sie nur das fü...
Page 8
Wenn Sie vermuten, dass das Gerät beschä digt ist, lassen Sie es vor dem weiteren Betrieb von qualifiziertem Servicepersonal überprü fen. Jegliche Wartung, Einstellung oder Austausch, insbesondere von Schaltkreisen oder Zubehör, muss von SIGLENT autorisiertem Personal durchgeführt werden. Nicht in feuchter Umgebung betreiben Um einen Kurzschluss im Geräteinneren oder einen elektrischen Schlag zu vermeiden, betreiben Sie das...
Sicherheitsbegriffe und symbole Begriffe in diesem Handbuch. Diese Begriffe kö nnen in diesem Handbuch vorkommen: WARNUNG Warnhinweise weisen auf Bedingungen oder Praktiken hin, die zu Verletzungen oder zum Verlust des Lebens führen kö nnen. VORSICHT Vorsichtshinweise weisen auf Bedingungen oder Praktiken hin, die zu Schäden an diesem Produkt oder anderen Gegenstä...
The consigner or carrier will be responsible for damages to the instrument resulting from shipment. SIGLENT will not provide free maintenance or replacement if the instrument has been damaged in shipment. ...
Preparation Before Use Connect AC power According to the machine you get, please use the power cord provided in the accessories to connect to the power source as follows. Figure 1 TypeⅠ Figure 2 TypeⅡ Connection method TypeⅠ/10A: applicable models 360W and 720W The specification of the equipment that can input AC power is: 100~240V, 47~63Hz.
Standard accessories: One SPS power supply An international AC power cord A quick start manual Output terminal cover The SPS5000X series includes 16 models, with 4 voltage output types: 40V/50V/80V/160V, with up to three output channels: Model Type Channel Rated voltage (V)
Panel Introduction Front Panel Type Ⅲ/TypeⅤ: TypeⅡ/Type Ⅳ: TypeⅠ: A. Screen E. Panel B. Button Power switch C. Knob G. Stand D. USB Host port H. Front output port SPS5000X Quick Start...
Page 14
Screen Equipped with a 2.4-inch OLED display for displaying system output status, system parameter settings, menu options, and promotion information. Button Used to view system information and configure power parameters. In the main interface, press this key to select and set the output voltage value or output current value.
Page 15
Back Panel Type V TypeⅡ TypeⅠ A. Handle E. Fan port B. Analog connector port LAN port C. USB Device port G. AC power interface D. Output interface SPS5000X Quick Start...
Page 16
Analog connector port Used to detect the output of voltage and current, and also used for analog control of current and voltage output. USB Device port This interface can be connected to a PC to realize USBTMC communication, and control the power supply by sending commands through the upper computer software.
User Interface The SPS5000X series has three different user interfaces according to different output channels: TypeⅠ/TypeⅡ/TypeⅢ: TypeⅤ: ① For single-channel models, the status bar here displays the machine model information, if it is multi-channel, the status of each channel is displayed here.
Page 18
List interface: ① For single-channel models, the status bar displays the machine model; for multi-channel models, the current channel is displayed here. You can press the left and right direction keys to select. ② Set the voltage to be output. After pressing the knob, move the cursor to here, and select the knob to change the value.
Page 19
Enter the list parameter configuration interface, rotate the knob to select parameters. Press the knob at the point where the * sign points to set this parameter. After setting, press the knob again to take effect. ① List output enable status. It is used to realize the independent control of the list output of each channel by the multi-channel model.
Basic Operations View system information Users can view the system information through Menu -> System -> Version, and the contents to be viewed include: Boot times Supplier name Product model Specifications Serial number Software version Hardware version Upgrade Please follow the steps below to upgrade: Download the upgrade package from the official website.
Page 21
For multi-channel models, after setting the channel mode to List mode in Menu → Configure → Channel Mode , set the List parameters as above. Other configuration setting Users can configure the system function through Menu → Configure : Protect Set the overvoltage protection (OVP) value and overcurrent protection value (OCP), and the ON/OFF of OCP.
Page 22
Rear Analog Interface Wiring Method One in series Slave unit Load Master unit SPS5000X Quick Start...
Page 23
Connect two units in parallel Master unit Slave unit 1 Load Slave unit 2 SPS5000X Quick Start...
Remote Based on the SCPI (Standard Commands for Programmable Instruments) command set, the power supply supports communication with the computer via USB, LAN, and GPIB-USB interfaces to realize remote control. Press Menu → Communication to configure the remote control parameters of the power supply. View the USB resource information of the power supply.
(1) Check whether the power connector is properly connected (2) After checking, please restart the power. (3) If the power supply still cannot be started normally, please contact SIGLENT. Press Output without voltage output (1) Check whether the voltage and current settings are correct (2) Check whether it is in host mode, whether EXT on/off is in off state, Volt_ctrl and Curr_ctrl are in Local state, and whether the output resistance setting is reasonable.
For more information about this product, please refer to the following manual: (You can log in to the SIGLENT website to download Http://www.siglent.com) “SPS5000X User Manual” Provide a detailed description of the functions of this product, as well as a detailed description of the SCPI commands and programming of this product.
