- Page 1 User Manual SPD3000 Series Programmable DC Power Supply SIGLENT TECHNOLOGIES CO., LTD www.biall.com.pl...
- Page 2 1. SIGLENT TECHNOLOGIES CO., LTD. All Rights Reserved. 2. Information in this publication replaces all previous corresponding material. 3. SIGLENT reserves the right to change the specifications and price of the product. 4. Any way of copying, extracting and translating the content of the manual is not allowed without permission of SIGLENT.
-
Page 3: General Safety Summary
SIGLENT General Safety Summary Please review the following safety precautions carefully to avoid personal injury or damage to this product or any product connected to it. To prevent potential danger, please use the instrument as specified. Use proper power cord Only the power cord designed for the instrument and authorized by local country could be used. - Page 4 SIGLENT Do not operate in an explosive atmosphere To avoid personal injury or damage to instrument, please do not operate in an explosive atmosphere. Keep surface of the product clean and dry To avoid dust or moisture in the air influence the performance of the instrument , please keep surface of the product clean and dry.
-
Page 5: Safety Terms And Symbols
SIGLENT Safety Terms and Symbols Terms may appear on the product: DANGER: Indicates direct injury or hazard that may happen. WARNING: Indicates potential injury or hazard that may happen. CAUTION: Indicates potential damage to the instrument or other property that may happen. -
Page 6: Spd3000 Series Brief Introduction
SIGLENT SPD3000 Series Brief Introduction SPD3000 series Programmable DC Power Supply is convenient, flexible and multi-function. It has three independent outputs, two sets of adjustable voltage value and a fixed set of selectable voltage value of 2.5V, 3.3V, and 5V ,and it also provides output short circuit and overload protection at the same time. -
Page 7: Table Of Contents
SPD3000 Series Brief Introduction..................V Chapter 1 Start Guide ......................1 The front panel ..........................2 The rear panel ...........................6 Notice in first use of SPD3000 Series .................7 Input power requirement ......................7 Electrical check .........................7 Output check ..........................8 Chapter 2 Control panel operation ..................9 2.1 Output summary ......................10... -
Page 8: Chapter 1 Start Guide
If the instrument is damaged during shipment, the compensation will be provided by consigner or carrier, and SIGLENT will not undertake free repair or replacement. If there is a mechanical damage or loss please contact with your sales representative. -
Page 9: The Front Panel
SIGLENT The front panel ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Description Description Logo CH3 DIP Switch Display Area Power Switch Model CH1 Output Terminal System parameter Ground Terminal configuration button Multi-function knob... - Page 10 SIGLENT Instruction for buttons Buttons for setting parameters WAVEDISP : Press the button to turn on/off the waveform display interface; : Press the button to set series mode of CH1/CH2, and the logo “ ” displays at the same time;...
- Page 11 SIGLENT The output terminal on front panel The output terminals of CH1、CH2 and CH3 include positive terminal and negative terminal, and a common ground for CH1 and CH2 additional. Each channel has its own logo. The operation details are introduced in the follow-up ”...
- Page 12 SIGLENT User interface ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Parallel/Series logo: The logo will be displayed when the corresponding mode is on ○ Channel logo; ○ Operating mode logo: The corresponding logo will display when working in CV or CC mode;...
-
Page 13: The Rear Panel
SIGLENT The rear panel ○ ○ ○ ○ ○ ○ ○ Description: ○ warning message ○ The DIP switch of the AC power and its identification . ○ The description of the AC input voltage ○ AC power socket ○... -
Page 14: Notice In First Use Of Spd3000 Series
To ensure that the instrument can work normally,, you need to undertake the necessary inspection before using the SPD3000. Input power requirement The SPD3000 series allows two kinds of frequency that are 50hz and 60hz, four kinds of AC power that are 100v、110v、220v and 230v. You can choose the different input power with the “DIP switch ”at the rear panel according to... -
Page 15: Output Check
SIGLENT Output check The output check includes voltage check in condition of all channels with no load and current check in condition of short circuit so as to make sure that the instrument correctly responds to operation of the front panel. -
Page 16: Chapter 2 Control Panel Operation
SIGLENT Chapter 2 Control panel operation In this chapter，the function and operation of SPD3000 series control panel will be introduced in detail to giving you an all-around understanding of it, which will eventually lead to easier work. Brief introduction: Output summary... -
Page 17: Output Summary
SIGLENT 2.1 Output summary Summary SPD3000 series have three independent outputs, two of which are adjustable in voltage value and the other one includes selectable 2.5V, 3.3V or 5.0V Independent/Parallel/Series SPD3000 series have three output modes: independent、parallel and series, which can be selected through the track switch on the front panel. In the independent mode, the output current and voltage are controlled respectively. -
Page 18: Ch1/Ch2 Independent Output
SIGLENT 2.2 CH1/CH2 Independent Output Instruction CH1 and CH2 are working in the independent mode, at the same time，they are insulated from the ground. Output rating 0~30V/0~3A (max:32V, 3.2A) Operation steps 1. Make sure that parallel/series mode is off. 2. Connect load to the positive and negative terminals of CH1/CH2. -
Page 19: Ch3 Independent Mode
SIGLENT 2.3 CH3 Independent mode Instruction CH3 is independent from CH1 and CH2, and it works neither in parallel mode nor in series mode. Its voltage and current ratings are respectively 2.5V,3.3V, 5V and 3A. Output ratings 2.5V/3.3V/5V, 3A Operation steps: 1. -
Page 20: Ch1/Ch2 Series Mode
SIGLENT 2.4 CH1/CH2 Series mode Instruction In the series mode, CH1 and CH2 are linked internally into one channel which is controlled by CH1, and the output voltage value is twice compared with that of single channel. Output rating 0~60V/0~3A (max: 64V,3.2A) Operation steps：... - Page 21 SIGLENT 14 SPD3000 User Manual www.biall.com.pl...
-
Page 22: Ch1/Ch2 Parallel Mode
SIGLENT 2.5 CH1/CH2 Parallel mode Instruction In the parallel mode, CH1 and CH2 are linked internally into one channel which is controlled by CH1. Its output current value is twice as much as the single channel. Output rating 0~30V/0~6A Operation steps: 1. -
Page 23: Save And Recall
SIGLENT 2.6 Save and Recall Save setup Five group setups can be saved in memory. The contents of the setup file including: Independent/series/parallel mode Output voltage/current value Timer setup Operation steps 1. Set the state that you wanted; 2. Press “STORE” to enter Save/Recall interface;... -
Page 24: Timer
SIGLENT 2.7 Timer The timer works in the Independent mode, and can save five timing setups, each of which is independent from each other. You can set any voltage/current value within the range as you want. The timer supports consecutive output, and the longest time of each group is 10000s. - Page 25 SIGLENT Start the Timer 1. Move cursor to “TIMER” menu by pressing the direction button; 2. Revolve the multi-function knob to make theTimer state to “ON”; 3. Press the knob to start theTimer. Note: If press the “TIMER” button when the timer is running, then you can observe the decreasing of the time ,and the changes of the curve .The Timer will automatically turn off when the time reduces to 0.
- Page 26 SIGLENT 2.8 Waveform display Display the changing of current voltage and current in the form of curve. Operation steps: 1. Select CH1/CH2, and then set voltage/current parameter; 2. Press “WAVE” button to enter Waveform Display interface, and the indicator light turns bright immediately.
-
Page 27: Version Information
SIGLENT 2.9 Version information Press “LOCK” button quickly to enter Version Information interface, which is shown below: 20 SPD3000 User Manual www.biall.com.pl... -
Page 28: Upgrade Firmware
SIGLENT 2.10 Upgrade firmware The software of the instrument is upgraded with a fixed name file via PC management software with USBTMC. The upgrade method is below: Upgrade in normal Interface 1. Open the EsayPower software after USB line having been connected perfectly, and make sure the instrument is connected with the software correctly. - Page 29 SIGLENT Figure 3 4. As it shows in figure 4, click Upgrade button to start upgrading. The upgrade is finished when the progress bar complete and the instrument will run the version after upgrade. Figure 4 Upgrade Via Guide Procedure Upgrade via guide procedure also can be used if the method above is failed.
-
Page 30: Chapter 3 Remote Control
SIGLENT Chapter 3 Remote control The SCPI Commands are used to perform remote control through USBTMC. Connect the USB device on the rear panel to computer which has been installed with EasyPower software or NI（Measurement & Automation）. 3.1 Command list 1. -
Page 31: Command Description
Description Query the manufacturer, product type, series NO. and software version. Return Info Manufacturer, product type, series NO., software version. Example Siglent, SPD3303S, SPD00001130025, 1.01.01.02. 2.*SAV Command format *SAV <name> Description Save current state in nonvolatile memory with the specified name. - Page 32 SIGLENT Command format INSTrument? Description Query the current operating channel Example INSTrument? Return Info 5.MEASure Command format MEASure: CURRent? < CH1|CH2> Description Query current value for specified channel, if there is no specified channel, query the current channel. Example MEASure: CURRent? CH1 Return Info 3.000...
- Page 33 SIGLENT 6.SOURce Command format <SOURce:>CURRent <value> <SOURce>:={CH1 | CH2} Description Set current value of the selected channel Example CH1:CURRent 0.5 Command format <SOURce>: CURRent? <SOURce>:={CH1 | CH2} Description Query the current value of the selected channel. Example CH1: CURRent? Return Info 0.500...
- Page 34 SIGLENT 7.OUTPut Command format OUTPut <SOURce>, <state> <SOURce>:={CH1 | CH2}; <state>:={ON | OFF} Description Turn on/off the specified channel. Example OUTPut CH1, ON Command format OUTPut: TRACK <NR1> <NR1>:={0[Independent] | 1[Series] | 2[Parallel]} Description Select operation mode Example OUTPut: TRACK 0 Command format OUTPut: WAVE<SOURce>, <state>...
- Page 35 SIGLENT Command format TIMEr: SET? <SOURce>, <secnum> <SOURce>:={CH1 | CH2}; < secnum >;=1 to 5; Description Query the voltage/current/time parameters of specified group of specified channel. Example TIMEr: SET? CH1, 2 Return Info 3, 0.5, 2 Command format TIMEr <SOURce>, <state>...
- Page 36 SIGLENT Command format SYSTem: STATus? Description Query the current working state of the equipment. Instruction The return info is Hexadecimal format, but the actual state is binary , so you must change the return info into a binary. The state correspondence relationship is as follow.
-
Page 37: Chapter 4 Specification
SIGLENT Chapter 4 Specification ℃ ℃ Test condition:Heat for 30minitus, temperature between +20 ~+30 . Output CH1/CH2 independent 0～30V , 0～3A rating CH1/CH2 series 0～60V , 0～3A CH1/CH2 parallel 0～30V , 0～6A 2.5V/3.3V/5.0V , 0～3A Constant Voltage coefficient ≤0.01%+3mV Voltage Mode Load coefficient ≤0.01%+3mV(rating current ≤... - Page 38 SIGLENT Operating Indoor environment Altitude ≤2000 m Environment temperature 0 ~ 40℃ Comparative humidity Ⅱ Installation level Pollution level Storage Environment temperature -10 ~ 70℃ environment Comparative humidity ≤ 70% Power supply AC 100V/120V/220V/230V±10%, 50/60HZ Volume 275mm x 225mm x 136mm...
-
Page 39: Chapter 5 Troubleshooting
SIGLENT Chapter 5 Troubleshooting Question 1: what to do if there occurs a short circuit on output terminal? Answer1: There are over current protection and short circuit protection inside the power, so current will be controlled in safety range. Question 2: Is it abnormal that the... -
Page 40: Chapter 6 Service And Support
Chapter 6 Service and Support Maintain summary SIGLENT warrants that the products that it manufactures and sells will be free from defects in materials and workmanship for a period of three years from the date of shipment from an authorized SIGLENT distributor. If a product or CRT proves defective within the respective period, SIGLENT will provide repair or replacement as described in the complete warranty statement. -
Page 41: Appendix A: Accessories
SIGLENT Appendix A: Accessories SPD3000 Series Programmable DC Power Supply Accessories: Standard Accessories: A User Manual A Certification A Guaranty Card A CD(including EasyPower computer software system) A Power Cord that fits the standard of destination country ...
