PRODUCT NAME: Newberry Wall Shelf
ITEM NUMBER: KS012
ASSEMBLED DIMENSIONS: 40"H x 23 1/4"W x 6 3/4"D
STEP 1: Determine location for installation, then use a level and Pencil to mark wall (Fig.1).
See PAGE 2 for creating an easy template for placing interlocking wall brackets.
NOTE: Maximum support provided when at least one screw in driven directly into a wall stud.
Secure Bracket to wall
using 4 Wood Screws
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 1-15-2025
FULLY ASSEMBLED
REQUIRED TOOLS:
Phillips Screwdriver, Level
Assembled Weight: 13.4 lbs
A
8
2
B
C
STEP 2: Carefully lift Shelf (C) to installed Wall
Brackets (B) then fit interlocking Bracket
attached to back of Shelf over. Gently pull
down to lock into place.
(B)
(C)
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
3/4" Wood Screws
Wall Brackets
Component
Shelf
MADE IN PHILLIPINES
Page 1 of 2
