Heinrichs Messtechnik GmbH
Variable-Area Flow Meter
All-Metall design
Installation and Operating Instructions
Extreme robustness due to guide stars instead of guide rods
Flow measurement of liquids, gases and steam
Available up to DN 150 nominal size
Linear characteristic curve due to conically optimized float form
Outstandingly clear reading thanks to 90° arranged scale
Electrical transmitter with HART®, PROFIBUS-PA® or Fieldbus Foundation®
Suitable for installation in safety-related measuring systems according to SIL
BGN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Heinrichs BGN and is the answer not in the manual?

Questions and answers

Related Manuals for Kobold Heinrichs BGN

Summary of Contents for Kobold Heinrichs BGN

  • Page 1 Heinrichs Messtechnik GmbH Variable-Area Flow Meter All-Metall design Installation and Operating Instructions Extreme robustness due to guide stars instead of guide rods  Flow measurement of liquids, gases and steam  Available up to DN 150 nominal size  Linear characteristic curve due to conically optimized float form ...
