When using Outputs 7-8 and 9-10 for CV Control (HP A and HP B), be careful to first unplug any attached headphones from the
front panel outputs.
▪ When using these outputs with for CV control, we found that using High Impedance Headphones Mode or Line
Output Mode with unbalanced ticked generally provided the most reliable results.
▪ Remember Headphone level knobs are still affecting the signal and some experimentation may be required to find the
optimal level required for your connected equipment.
Best Practices & Safety
• NEVER send CV directly to your speakers (direct voltage can cause damage to your speakers).
• The CV Instrument device is only capable of calibrating oscillators that use bipolar voltage (+/-5V) for 1v/oct. tuning. However,
some digital oscillator modules exclusively use unipolar signals (+5V or above) for tuning. As a result, CV Tools will be
incompatible with these modules. If you are unsure whether this applies to the modules in your system, please consult the user
manual for the device.
• Remember - Eurorack signals are up to 5x louder than line-level audio! Before connecting your modular system to a digital audio
interface, be sure to reduce the signal down to line-level using a dedicated output module.
Specifications
Unless specified otherwise, default test configuration:
Sample Rate: 48kHz, Bandwidth: 20 Hz to 20 kHz
Measurement device output impedance: 40 Ω (20 Ω unbalanced)
Measurement device input impedance: 200 kΩ (100 kΩ unbalanced)
Unless otherwise quoted all figures have a tolerance of ±0.5dB or 5%
Microphone Inputs
Max input level
Gain range
Frequency Response 20 Hz - 20 kHz
Dynamic range (A-weighted)
THD+N (-8dBFS input level)
EIN (A-weighted)
Input Impedance
Line Inputs
Max input level
Gain range
Frequency Response 20 Hz - 20 kHz
Dynamic range (A-weighted)
THD+N (-8dBFS input level)
Input Impedance
Instrument Inputs
Max input level (min gain, balanced)
Gain range
Frequency Response 20 Hz - 20 kHz
Dynamic range (min gain, A-wt)
THD+N (min gain, -8dBFS input level)
Input Impedance
15 dBu
67 dB
+/-0.06 dB
120 dB typical
-100 dB/0.001%
130.5 dBu
1.2 kΩ
24.1 dBu
26 dB
+/-0.05 dB
120 dB typical
-106 dB/0.0005%
15 kΩ
15dBu
67 dB
+/-0.05 dB
120 dB typical
-100 dB / 0.001%
1 MΩ
