Flex

TechBridge Assembly Instructions and Owner's Manual 236A153.

Make sure anyone assembling, installing or

using this product has read and understands

these instructions.

These mounting brackets are only intended to attach the Yamaha Harmony Director HD-300 keyboard

to the Wenger Flex TechBridge. Contact Wenger Corporation for fitment of other keyboard models.

Visit the Conductor's Equipment web page at wengercorp.com for more information.

Note: Please read and understand these instructions before proceeding.

Note: If you need additional information, contact Wenger Corporation using the information below.

©Wenger Corporation 2025

Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448

Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com

Yamaha Harmony Director

Basic Instructions only!

For more detailed product information, refer to the

CAUTION

Mounting Brackets Accessory

Failure to comply with Warnings and Cautions in

this document or on the equipment can result in

damage to property or injury.

NOTICE

Printed in USA 2025-01

Assembly Instructions

HD-300

™

for Flex

TechBridge

CAUTION

Part #236A206-01

Need help?

Do you have a question about the Yamaha Harmony Director HD-300 and is the answer not in the manual?

Page 1 NOTICE These mounting brackets are only intended to attach the Yamaha Harmony Director HD-300 keyboard to the Wenger Flex TechBridge. Contact Wenger Corporation for fitment of other keyboard models. Visit the Conductor's Equipment web page at wengercorp.com for more information.
Page 2 O-Ring (below bracket) 2. Attach the mounting brackets to a Yamaha Harmony Director HD-300 Keyboard. a. On the underside of the keyboard, locate the "STAND SCREW" receptacle near each end. b. With the knob end facing toward the keys at the front the keyboard, attach a mounting bracket to each receptacle with the M5 x 25 mm pan head screw as shown.
Page 3 Assembly (continued) 3. Attach the mounting brackets and keyboard to the Flex TechBridge. a. Fit the rear post of the mounting bracket into the channel in the rear of the Flex TechBridge and rotate the keyboard and brackets onto the Flex TechBridge. Fit front post into front channel...
Page 4 Assembly (continued) b. Tighten both knobs to secure the brackets into the rear channel of the Flex TechBridge. Tighten knob to secure into channel...
