Wenger Flex Assembly Instructions

Conductor's stand basket accessory

Download this manual

Polycarbonate Desk Flex Conductor's Stand procedure only, see other side

for High-Pressure Laminate Desk Flex Conductor's Stand procedure.

To attach each Basket to the underside of the clear Polycarbonate Desk Flex Conductor's Stand:

1. Insert four #8-32 x 1/4 Binding Post Screws through the holes

in the top of the Desk Surface and in the Basket Tab.

2. Secure each Screw with a #8-32 Binding Post Barrel

at the underside of the Basket Tab.

Note: If necessary, the desk can be rotated

while attaching the Baskets.

#8-32 x 1/4

Binding Post

Screw

#8-32

Binding Post

Barrel

©Wenger Corporation 2014

Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448

Questions? Call.....USA: 800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com

Flex

Printed in USA 12/14

Assembly Instructions

Conductor's Stand

Basket Accessory

Baskets

Polycarbonate Desk with

Baskets Attached

Part #236C128-01
