Installation Guide | iC7 Series Liquid-cooled L Filter OF7Z5
Figure 16: Using the Cable Clamps
1 Stripping length, 15 mm (0.59 in)
3 Grounding
4.
At the terminal X86 end of the cable, place the cable in a cable clamp for strain relief.

Wiring Diagrams

4.9
1
L1 L1'
L1
L2 L2'
L2
L3 L3'
L3
Figure 17: Wiring Diagram, L Filter and Single Power Unit
1 L Filter
3
LC Filter, loose option
5 DC fuses, loose option
Danfoss Drives Oy © 2024.11
1
2
2
L1
L2
L3
PE
3
2 Strain relief
3
L1 L1'
L1 L1
L2 L2'
L2 L2
L3 L3'
L3 L3
PE
2 AC fuses, loose option
4
AFE module AM10L
Electrical Installation
4 5
1
DC+
2
DC-
3
AN447722950367en-000201 / 172K1111B |
DC+
DC-
15
