Installation Guide | iC7 Series Liquid-cooled L Filter OF7Z5
Table 2: L Filter Terminal Descriptions
Terminal
L1, L2, L3
L1' , L2' , L3'
PE
Preparing the AuxBus Cable
4.7
1.
Cut the cable to the required length.
2. To reveal the wires, strip the cable at both ends.
3.
At 1 end of the cable, remove approximately 15 mm (0.59 in) of the cable insulation.
4.
Strip the wires 7 mm (0.28 in).
5. Connect the wires to the terminals included in the delivery. Use the tightening torque 0.22–0.25 Nm (1.9–2.2 in-lb).
Table 3: Wiring of the AuxBus Terminals
Pin
1
2
3
4
5
1 2 3
Figure 13: The Ready AuxBus Cable
1 Terminals
3
Shield removed
4.8 AuxBus Connections
For the drive to be able to protect the filters, AuxBus must be connected.
For more information about AuxBus, see the iC7 Series Liquid-cooled System Modules Design Guide.
Danfoss Drives Oy © 2024.11
Description
AC connection point for mains input
AC connection point for output to AFE
Grounding terminal for filter frame
Wire color
White
Brown
Green
Yellow
Grey
2 1
2 Wires
NOTICE
Electrical Installation
Signal
+24 V
GND
CAN_H
CAN_L
+24 V
AN447722950367en-000201 / 172K1111B | 13
