Physical Characteristics

Ports
20 10/100/1000BASE-T, with auto-negotiation
4 10/100/1000BASE-T shared with 4 SFP transceiver slots.
Network Interface
Ports 1-24: RJ-45 connector, auto MDI/X
10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)
1000BASE-T: RJ-45 (100-ohm, UTP or STP cable; Category 5, 5e, or 6)
*Maximum Cable Length - 100 m (328 ft)
Buffer Architecture
400 Kbytes
Aggregate Bandwidth
48 Gbps
Switching Database
8K MAC address entries, 1K static MAC addresses;
LEDs
System: Power
Port: Link/Act, 1000
Weight
3.72 kg (8.44 lbs)
