EZ Switch 10/100 SMC-1026DT V.2 Unmanaged Ethernet/Fast Ethernet Switch User Guide Expansion Module Series SMC-EZ1026FMSC V.2 SMC-EZ1026GSSC V.2 SMC-EZ1026LXSC V.2 SMC-EZ1026GT V.2... - Page 2 Introduction The Expansion Module series for SMC-EZ-1026DT V.2 switch can be installed into a number of 24+1/2 intelligent switch devices to provide 100 Mbps Fiber and 1000 Mbps UTP/Fiber connections to other compatible network devices. The Expansion Modules are designed to extend the distance between the Switch and other devices or as backbone in the networking infrastructure.
-
Page 3: Led Indicators
Expansion Module Series --- SMC-EZ1026GT V.2: Gigabit 1000 Base-T Module Figure 1. 1000 Base-T N-Way Module Front View Features: One 10/100/1000 Mbps N-Way auto-negotiation RJ-45 port Automatic MDI/MDIX supported Pause-Frame Base flow control on Full-duplex mode Full-duplex modes supported LED-indicators for 1000M, 100M, LK/ACT, FDX status LED Indicators There are four types of LED indicators for the RJ-45 Port. - Page 4 1. 100Base-FX( SC ) Fiber Module Figure 2. 100Base-FX ( SC ) Module Front View 2. 100Base-FX( SC Single-mode ) Fiber Module SMC-EZ1026FMSC V.2 Figure 3. 100Base-FX ( SC Single-mode ) Module Front View 3. 100Base-FX( MTRJ ) Fiber Module Figure 4.
- Page 5 FDX/COL The LED indicator is yellow when the port is operating in Full-duplex mode. When the port is operating in Half-duplex mode, the LED indicator is not lit. When collisions are occurring at the port, the LED indicator blinks. SMC-EZ1026GLSC V.2 :Gigabit 1000Base-LX/SC Fiber Modules SMC-EZ1026GSSC V.2: Gigabit 1000Base-SX/SC Fiber Modules Figure 6.
-
Page 6: Installation Steps
To install the Expansion Modules, follow these steps: 1. First of all, power off the switch, which you want to insert the module. 2. Insert the module into a SMC-EZ1026DT V.2 Switch module slot and secure the retaining screws. 3. After the modules are installed, reset or reboot switch. - Page 7 4. Using the flat bladed or screwdriver, gently push the thumbscrews in and turn clockwise to tighten. Do not over tighten the thumbscrews. 5. Power SMC-EZ1026DT V.2 ON, and the Switch will automatically detect the expansion Module. Plug the network cable connector into the expansion Module.
- Page 8 Cabling RJ-45 port can be use unshielded twisted pair (UTP) or shielded twisted pair (STP) cabling. The cable must comply with the IEEE 802.3u 100Base TX standard for Category 5. The cable between the switch and the link partner ( switch, hub, workstation, etc.
-
Page 9: Module Name
100 Base-FX module 1300 ( VF-45 ) Avg. Power Max. FDX Fiber Size Module Name Loss Budget Fiber Distance ( um ) ( dBm ) ( Km ) 62.5/125 100 Base-FX module( SC ) 50/125 100 Base-FX module 9/125 8/125 ( SC-Single mode ) 100 Base-FX 62.5/125... -
Page 10: Troubleshooting
Troubleshooting The section is intended to help you solve the most common problems on the expansion modules. Cabling For UTP module, verify that the cabling type is correct. Be sure all cable connectors are securely seated in the required ports. Use all standard unshielded twisted-pair (UTP), Category 3, 4, or 5 cables for 10Base-T connection；or Category 5 for 100Base-TX connection. -
Page 11: Technical Specifications
Technical Specifications Standards Compliance IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX/FX Fast Ethernet, IEEE 802.3z 1000BASE-X Fiber Gigabit Ethernet IEEE 802.3ab 1000BASE-T UTP Gigabit Ethernet ANSI/IEEE standard 802.3 N-Way Auto-negotiation Protocol CSMA/CD Max Forwarding and 14,880 pps to Ethernet port, Max Filtering Rate 148,800 pps to Fast Ethernet port (for 64-byte packets)
