SMC Networks GS24C-SMART - ANNEXE 1 User Manual

10/100/1000 24-port smart switch
Hide thumbs Also See for GS24C-SMART - ANNEXE 1:
Table of Contents

Advertisement

Quick Links

USER GUIDE

ta
SMCGS24C-Smart
TM
EZ Switch
10/100/1000
24-Port Smart Switch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS24C-SMART - ANNEXE 1 and is the answer not in the manual?

Questions and answers

Related Manuals for SMC Networks GS24C-SMART - ANNEXE 1

Summary of Contents for SMC Networks GS24C-SMART - ANNEXE 1

  • Page 1: User Guide

    USER GUIDE SMCGS24C-Smart EZ Switch 10/100/1000 24-Port Smart Switch...
  • Page 3 EZ Switch 10/100/1000 User Guide From SMC’s EZ line of cost-effective workgroup LAN solutions 20 Mason March 2008 Irvine, CA 92618 Pub. # 149100009500H E032008-AP-R04 Phone: (949) 679-8000...
  • Page 4 No license is granted by implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to change specifications at any time without notice.
  • Page 5 Life of that Product, which is defined as the period of time during which the product is an “Active” SMC product. A product is considered to be “Active” while it is listed on the current SMC price list. As new technologies emerge, older technologies become obsolete and SMC will, at its discretion, replace an older product in its product line with one that incorporates these newer technologies.
  • Page 6 WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.

  • Page 7: Japan Vcci Class A

    OMPLIANCES FCC - Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 8 OMPLIANCES CE Mark Declaration of Conformance for EMI and Safety (EEC) SMC contact for these products in Europe is: SMC Networks Europe, Edificio Conata II, Calle Fructuós Gelabert 6-8, 2 08970 - Sant Joan Despí, Barcelona, Spain. This information technology equipment complies with the requirements of the Council...

  • Page 9: Safety Compliance

    OMPLIANCES Safety Compliance Warning: Fiber Optic Port Safety When using a fiber optic port, never look at the transmit laser while CLASS I it is powered on. Also, never look directly at the fiber TX port and LASER DEVICE fiber cable ends when they are powered on. Avertissment: Ports pour fibres optiques - sécurité...
  • Page 10 OMPLIANCES Important! Before making connections, make sure you have the correct cord set. Check it (read the label on the cable) against the following: Power Cord Set U.S.A. and Canada The cord set must be UL-approved and CSA certified. The minimum specifications for the flexible cord are: - No.
  • Page 11 OMPLIANCES Veuillez lire à fond l'information de la sécurité suivante avant d'installer le Switch: AVERTISSEMENT: L’installation et la dépose de ce groupe doivent être confiés à un personnel qualifié. • Ne branchez pas votre appareil sur une prise secteur (alimentation électrique) lorsqu'il n'y a pas de connexion de mise à...
  • Page 12 OMPLIANCES Cordon électrique - Il doit être agréé dans le pays d’utilisation Suisse: La prise mâle d’alimentation doit respecter la norme SEV/ASE 1011. Europe La prise secteur doit être conforme aux normes CEE 7/7 (“SCHUKO”) LE cordon secteur doit porter la mention <HAR> ou <BASEC> et doit être de type HO3VVF3GO.75 (minimum).

  • Page 13: Warnings And Cautionary Messages

    OMPLIANCES Warnings and Cautionary Messages Warning: This product does not contain any serviceable user parts. Warning: Installation and removal of the unit must be carried out by qualified personnel only. Warning: When connecting this device to a power outlet, connect the field ground lead on the tri-pole power plug to a valid earth ground line to prevent electrical hazards.

  • Page 14: End Of Product Life Span

    OMPLIANCES End of Product Life Span This product is manufactured in such a way as to allow for the recovery and disposal of all included electrical components once the product has reached the end of its life. Manufacturing Materials There are no hazardous nor ozone-depleting materials in this product. Documentation All printed documentation for this product uses biodegradable paper that originates from sustained and managed forests.

  • Page 15: Table Of Contents

    ABLE OF ONTENTS About the EZ Switch 10/100/1000 ....1-1 Overview ..........1-1 Switch Architecture .
  • Page 16 ABLE OF ONTENTS Making Network Connections ....4-1 Connecting Network Devices ....... . . 4-1 Twisted-Pair Devices .
  • Page 17 ABLE OF ONTENTS Trunk Configuration ........5-27 Trunk Rate Limit .
  • Page 18 ABLE OF ONTENTS...
  • Page 19 ABLES Table 1-1 Port Status LEDs ........1-4 Table 1-2 Power Status LED .
  • Page 20 IGURES Figure 1-1 Front Panel ........1-1 Figure 1-2 Rear Panel .
  • Page 21 IGURES Figure 5-20 Trunk Membership ......5-27 Figure 5-21 Trunk Configuration ......5-28 Figure 5-22 Trunk Rate Limiting .
  • Page 22 IGURES xviii...

  • Page 23: Figure 1-1 Front Panel

    BOUT THE EZ S 10/100/1000 WITCH Overview SMC’s EZ Switch 10/100/1000 SMCGS24C-Smart is a web managed switch with 24 10/100/1000BASE-T ports, four of which are combination ports that are shared with four SFP transceiver slots (see Figure 1-1, Ports 21-24).

  • Page 24: About The Ez Switch 10/100/1000

    EZ S 10/100/1000 BOUT THE WITCH Switch Architecture The switch employs a wire-speed, non-blocking switching fabric. This permits simultaneous wire-speed transport of multiple packets at low latency on all ports. The switch also features full-duplex capability on all ports, which effectively doubles the bandwidth of each connection. The switch uses store-and-forward switching to ensure maximum data integrity.

  • Page 25: Description Of Hardware

    ESCRIPTION OF ARDWARE Description of Hardware 10/100/1000BASE-T Ports The switch contains 24 RJ-45 ports that operate at 10 Mbps or 100 Mbps, half or full duplex, or at 1000 Mbps, full duplex. Because all ports on the switch support automatic MDI/MDI-X operation, you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs.

  • Page 26: Table 1-1 Port Status Leds

    EZ S 10/100/1000 BOUT THE WITCH 0/1000 10 11 1000 Link/Act 1000 Link/Act 13 14 15 16 17 18 19 20 21 22 23 24 Power Power Status LED Port Status LEDs Figure 1-3 Port LEDs and Power LED Table 1-1 Port Status LEDs Condition Status Gigabit Ethernet Ports (Ports 1-24)

  • Page 27: Power Supply Socket

    EATURES AND ENEFITS Power Supply Socket The power socket is located on the rear panel of the switch. The standard power socket is for the AC power cord. 100-240V ~50-60Hz 0.8A Figure 1-4 Power Supply Socket Features and Benefits Connectivity •...

  • Page 28: Expandability

    EZ S 10/100/1000 BOUT THE WITCH Expandability • 4 Small Form Factor Pluggable (SFP) transceiver slots (shared with 1000BASE-T ports) • Supports 1000BASE-SX, 1000BASE-LX and 1000BASE-LH SFP transceivers. Performance • Transparent bridging. • Provides store-and-forward switching • Supports Jumbo frames up to 9.6 Kbytes •...

  • Page 29: Network Planning

    HAPTER ETWORK LANNING Introduction to Switching A network switch allows simultaneous transmission of multiple packets via non-crossbar switching. This means that it can partition a network more efficiently than bridges or routers. Switches have, therefore, been recognized as one of the most important building blocks for today’s networking technology.

  • Page 30: Application Examples

    ETWORK LANNING Application Examples The EZ Switch 10/100/1000 is not only designed to segment your network, but also to provide a wide range of options in setting up network connections. Some typical applications are described below. Collapsed Backbone The EZ Switch 10/100/1000 is an excellent choice for mixed Ethernet, Fast Ethernet, and Gigabit Ethernet installations where significant growth is expected in the near future.

  • Page 31: Central Wiring Closet

    PPLICATION XAMPLES Central Wiring Closet With 24 parallel bridging ports (i.e., 24 distinct collision domains), this switch can collapse a complex network down into a single efficient bridged node, increasing overall bandwidth and throughput. In the figure below, the 1000BASE-T RJ-45 ports on the switch are providing 1 Gbps full-duplex connections for up to 24 local segments.

  • Page 32: Remote Connections With Fiber Cable

    ETWORK LANNING Remote Connections with Fiber Cable Fiber optic technology allows for longer cabling than any other media type. A 1000BASE-SX (MMF) link can connect to a site up to 550 meters away, a 1000BASE-LX (SMF) link up to 5 km, and a 1000BASE-ZX link up to 100 km.

  • Page 33: Making Vlan Connections

    PPLICATION XAMPLES Making VLAN Connections The switch supports VLANs that can be used to organize any group of network nodes into separate broadcast domains. VLANs confine broadcast traffic to the originating group, and can eliminate broadcast storms in large networks. This provides a more secure and cleaner network environment.

  • Page 34: Application Notes

    ETWORK LANNING Application Notes 1. Full-duplex operation only applies to point-to-point access (such as when a switch is attached to a workstation, server or another switch). When the switch is connected to a hub, both devices must operate in half-duplex mode. 2.

  • Page 35: Installing The Switch

    HAPTER NSTALLING THE WITCH Selecting a Site EZ Switch 10/100/1000 units can be mounted in a standard 19-inch equipment rack or on a flat surface. Be sure to follow the guidelines below when choosing a location. • The site should: - be at the center of all the devices you want to link and near a power outlet.

  • Page 36: Ethernet Cabling

    NSTALLING THE WITCH Ethernet Cabling To ensure proper operation when installing the switches into a network, make sure that the current cables are suitable for 10BASE-T, 100BASE-TX or 1000BASE-T operation. Check the following criteria against the current installation of your network: •...

  • Page 37: Equipment Checklist

    • Power cord—either US, Continental Europe or UK • User Guide CD • SMC Warranty Registration Card—be sure to complete and return to Optional Rack-Mounting Equipment If you plan to rack-mount the switches, be sure to have the following equipment available: •...

  • Page 38: Rack Mounting

    NSTALLING THE WITCH Rack Mounting Before rack mounting the switch, pay particular attention to the following factors: • Temperature: Since the temperature within a rack assembly may be higher than the ambient room temperature, check that the rack-environment temperature is within the specified operating temperature range (see page C-2).

  • Page 39: Figure 3-2 Attaching The Brackets

    OUNTING To rack-mount devices: 1. Attach the brackets to the device using the screws provided in the Bracket Mounting Kit. Figure 3-2 Attaching the Brackets 2. Mount the device in the rack, using four rack-mounting screws (not provided). Figure 3-3 Installing the Switch in a Rack...

  • Page 40: Desktop Or Shelf Mounting

    NSTALLING THE WITCH 3. If installing a single switch only, turn to “Connecting to a Power Source” at the end of this chapter. 4. If installing multiple switches, mount them in the rack, one below the other, in any order. Desktop or Shelf Mounting 1.

  • Page 41: Installing An Sfp Transceiver

    SFP T NSTALLING AN RANSCEIVER Installing an SFP Transceiver Figure 3-5 Inserting an SFP Transceiver into a Slot The switch supports the following optional transceivers: • 1000BASE-SX (SMCBGSLCX1) • 1000BASE-LX (SMCBGLLCX1 • 1000BASE-ZX (SMCBGZLCX1) To install an SFP transceiver, do the following: 1.

  • Page 42: Connecting To A Power Source

    NSTALLING THE WITCH Connecting to a Power Source To connect a device to a power source: 1. Insert the power cable plug directly into the socket located at the back of the device. 100-240V ~50-60Hz 0.8A Figure 3-6 Power Socket 2.

  • Page 43: Making Network Connections

    HAPTER AKING ETWORK ONNECTIONS Connecting Network Devices The EZ Switch 10/100/1000 units are designed to interconnect multiple segments (or collision domains). It can be connected to network cards in PCs and servers, as well as to hubs, switches or routers. It may also be connected to devices using optional SFP transceivers.

  • Page 44: Connecting To Pcs, Servers, Hubs And Switches

    AKING ETWORK ONNECTIONS Connecting to PCs, Servers, Hubs and Switches 1. Attach one end of a twisted-pair cable segment to the device’s RJ-45 connector. Figure 4-1 Making Twisted-Pair Connections 2. If the device is a PC card and the switch is in the wiring closet, attach the other end of the cable segment to a modular wall outlet that is connected to the wiring closet.

  • Page 45: Network Wiring Connections

    WISTED EVICES Network Wiring Connections Today, the punch-down block is an integral part of many of the newer equipment racks. It is actually part of the patch panel. Instructions for making connections in the wiring closet with this type of equipment follows.

  • Page 46: Fiber Optic Sfp Devices

    AKING ETWORK ONNECTIONS Fiber Optic SFP Devices An optional Gigabit SFP transceiver (1000BASE-SX, 1000BASE-LX or 1000BASE-ZX) can be used for a backbone connection between switches, or for connecting to a high-speed server. Each single-mode fiber port requires 9/125 micron single-mode fiber optic cable with an LC connector at both ends.

  • Page 47: Figure 4-3 Making Connections To Sfp Transceivers

    SFP D IBER PTIC EVICES 3. Connect one end of the cable to the LC port on the switch and the other end to the LC port on the other device. Since LC connectors are keyed, the cable can be attached in only one orientation. Figure 4-3 Making Connections to SFP Transceivers 4.

  • Page 48: Connectivity Rules

    AKING ETWORK ONNECTIONS Connectivity Rules When adding hubs (repeaters) to your network, please follow the connectivity rules listed in the manuals for these products. However, note that because switches break up the path for connected devices into separate collision domains, you should not include the switch or connected cabling in your calculations for cascade length involving other devices.

  • Page 49: 100 Mbps Fast Ethernet Collision Domain

    ONNECTIVITY ULES Table 4-3 Maximum 1000BASE-LX Fiber Optic Cable Length Fiber Diameter Fiber Cable Length Connector Bandwidth Range 9/125 micron 2 m - 5 km single-mode fiber (7 ft - 3.2 miles) Table 4-4 Maximum 1000BASE-ZX Fiber Optic Cable Length Fiber Diameter Fiber Cable Length...

  • Page 50: Cable Labeling And Connection Records

    AKING ETWORK ONNECTIONS Cable Labeling and Connection Records When planning a network installation, it is essential to label the opposing ends of cables and to record where each cable is connected. Doing so will enable you to easily locate inter-connected devices, isolate faults and change your topology without need for unnecessary time consumption.

  • Page 51: Configuring The Switch

    HAPTER ONFIGURING THE WITCH Using the Web Interface This switch provides an embedded HTTP web agent. Using a web browser you can configure the switch and view statistics to monitor network activity. The web agent can be accessed by any computer on the network using a standard web browser (Internet Explorer 5.5 or above, or Mozilla Firefox 1.0 or above).

  • Page 52: Navigating The Web Browser Interface

    ONFIGURING THE WITCH Navigating the Web Browser Interface To access the web-browser interface you must first enter a password. The user has read/write access to all configuration parameters and statistics. The default password for the switch is “smcadmin.” Note: If user input is not detected within five minutes, the current session is terminated.

  • Page 53: Configuration Options

    AVIGATING THE ROWSER NTERFACE Configuration Options Configurable parameters have a dialog box or a drop-down list. Once a configuration change has been made on a page, be sure to click on the Apply button to confirm the new setting. The following table summarizes the web page configuration buttons.

  • Page 54: Main Menu

    Upgrade the switch system firmware using a 5-16 file provided by SMC. Restart Restarts the switch. 5-17 Register Product Enables you to connect to the SMC web site 5-18 to register your switch. Static MAC Adds static MAC addresses to the switch 5-18 MAC address table.
  • Page 55 AVIGATING THE ROWSER NTERFACE Table 5-2 Switch Main Menu (Continued) Menu Description Page PORTS 5-21 Settings Configure the speed and duplex mode of the 5-21 port. Rate Limiting Sets the rate limiting parameters for ports. 5-22 Storm Control Sets the broadcast storm control parameters. 5-24 Port Mirroring Sets up the port mirroring features of the...

  • Page 56: Web Configuration

    ONFIGURING THE WITCH Web Configuration Displaying Status Overview You can easily identify the system by displaying the device name, location and contact information. Field Attributes System Information • System Name – Name assigned to the switch system. • Number of Ports – Number of built-in ports. •...
  • Page 57 ONFIGURATION • Speed/Duplex Status – Shows the current speed and duplex mode. • 10hdx: 10 Mbps half duplex. • 10fdx: 10 Mbps full duplex. • 100hdx: 100 Mbps half duplex. • 100fdx: 100 Mbps full duplex. • 1000fdx: 1000 Mbps full duplex. •...

  • Page 58: Figure 5-3 Switch Information

    ONFIGURING THE WITCH Web – Click STATUS, Overview. Figure 5-3 Switch Information...

  • Page 59: Showing Port Statistics

    ONFIGURATION Showing Port Statistics You can display statistics on network traffic from the ports. These statistics can be used to identify potential problems with the switch (such as a faulty port or unusually heavy loading). All values displayed have been accumulated since the last system reboot, but can be reset to zero by clicking the CLEAR button.
  • Page 60 ONFIGURING THE WITCH Table 5-3 Port Statistics (Continued) Parameter Description Received Broadcast The number of packets, delivered by this sub-layer to Packets a higher (sub-)layer, which were addressed to a broadcast address at this sub-layer. Transmitted Octets The total number of octets transmitted out of the interface, including framing characters.
  • Page 61 ONFIGURATION Table 5-3 Port Statistics (Continued) Parameter Description Received Bytes Total number of bytes of data received on the network. This statistic can be used as a reasonable indication of Ethernet utilization. Broadcast Frames The total number of good frames received that were directed to the broadcast address.

  • Page 62: Displaying System Name

    ONFIGURING THE WITCH Web – Click STATUS, Statistics. Figure 5-4 Port Statistics Displaying System Name You can easily identify the system by displaying the device name. Field Attributes • Switch Name – Name assigned to the switch system. 5-12...

  • Page 63: Setting The Switch's Ip Address

    ONFIGURATION Web – Click System, Name. Figure 5-5 System Name Setting the Switch’s IP Address This section describes how to configure an IP interface for management access over the network. The IP address for this switch is 192.168.2.10 by default. To manually configure an address, you need to change the switch’s default settings (IP address 192.168.2.10 and netmask 255.255.255.0) to values that are compatible with your network.

  • Page 64: Configuring The Logon Password

    ONFIGURING THE WITCH Manual Configuration Web – Click System, LAN Settings. Enter the IP address, subnet mask and gateway, then click APPLY. Note that if you change the switch IP address, you must close the web interface and start a new session using the new IP address.

  • Page 65: Tools

    ONFIGURATION Web – Click System, Password. To change the password for the administrator, enter current password, the new password, confirm it by entering it again, then click APPLY. Figure 5-7 Password Settings Tools On the Tools page, you can restore the switch to default settings, upgrade the firmware of the switch, or restart the switch.

  • Page 66: Figure 5-8 Reset To Factory Defaults

    “Browse” button to select the firmware file. Click the APPLY button to upgrade the selected switch firmware file. You can download firmware files for your switch from the Support section of the SMC web site at www.smc.com. Web – Click System, Tools, Upgrade Firmware.

  • Page 67: Figure 5-11 Restart Switch

    ONFIGURATION Upload/Download Configuration Web – Click SYSTEM, Tools, Upload/Download Configuration. To upload or download the configuration file, select "Upload/Download Configuration" from the Tools drop-down list, then click "Upload" or "Download", and then click on the "Browse" button to select the file. Figure 5-10 Upload/Download configuration Restart Switch Web –...

  • Page 68: Register Product

    ONFIGURING THE WITCH Register Product SMC request that you register your switch online, if you have not already done so. The Register Product page provides a convenient link to the SMC web site for this purpose. Web – Click System, Register Product. Click the Register Now button to access the SMC web site and register your switch.

  • Page 69: Counter Config

    ONFIGURATION Static MAC Address Configuration This table shows the stored static MAC entries in MAC table. Web – Click System, Static MAC. Enter the MAC address, VLAN ID, then click ADD button to add a new static MAC address. Figure 5-13 Static MAC Address Configuration Counter Config This page allows specific statistics to be selected for monitoring.

  • Page 70: Figure 5-14 Counter Configuration

    ONFIGURING THE WITCH Web – Click SYSTEM, Counter Config. Figure 5-14 Counter Configuration 5-20...

  • Page 71: Port Configuration

    ONFIGURATION Port Configuration You can use the Port Configuration page to manually fix the speed, duplex mode, and flow control. Field Attributes • Speed/Duplex – Allows you to manually set the port speed and duplex mode. • Flow Control – Allows flow control to be enabled or disabled. When the box is checked, flow control is enabled.

  • Page 72: Configuring Rate Limits

    ONFIGURING THE WITCH Configuring Rate Limits This function allows the network manager to control the maximum rate for traffic transmitted or received on an interface. Rate limiting is configured on interfaces at the edge of a network to limit traffic into or out of the switch.

  • Page 73: Figure 5-16 Rate Limiting

    ONFIGURATION Web – Click PORTS, Rate Limiting. This page enables you to set the rate limiting parameters for each port on the switch. Figure 5-16 Rate Limiting 5-23...

  • Page 74: Storm Control

    ONFIGURING THE WITCH Storm Control Broadcast storms may occur when a device on your network is malfunctioning, or if application programs are not well designed or properly configured. If there is too much broadcast traffic on your network, performance can be severely degraded or everything can come to complete halt.

  • Page 75: Port Mirroring

    ONFIGURATION Web – Click PORTS, Storm Control. This page enables you to set the broadcast storm control parameters for every port on the switch. Figure 5-17 Port Broadcast Control Port Mirroring You can mirror traffic from any source port to a target port for real-time analysis.

  • Page 76: Cable Diagnostic

    ONFIGURING THE WITCH Note: If the total ingress bandwidth exceeds the mirror port’s egress bandwidth, packets will eventually be dropped on ingress to the switch, which means they will not reach the mirror port or their intended destination port. Input rate-limiting in conjunction with port flow-control should be used to ensure that the total ingress bandwidth never exceeds the egress bandwidth.

  • Page 77: Trunks Membership

    ONFIGURATION • Cable Status – Shows the cable length, operating conditions and isolates a variety of common faults that can occur on Category 5 twisted pair cabling. Web – Click PORTS, Cable Diagnostics. Figure 5-19 Cable Diagnostics Trunks Membership This page allows you to create a maximum of eight trunks of up to eight ports each.

  • Page 78: Trunk Configuration

    ONFIGURING THE WITCH • Trunk T1-T8 – These columns correspond to the eight trunks that are supported by the switch. To assign a port to a trunk, click on the radio button in the corresponding column, then click APPLY. Web – Click TRUNKS, Membership. To assign a port to a trunk, click the required trunk number, then click APPLY.

  • Page 79: Trunk Rate Limit

    ONFIGURATION • Flow Control – Allows flow control to be enabled or disabled. When the box is checked, flow control is enabled. • Ports – Indicates which ports belong to the trunk. Web – Click TRUNKS, Settings. Figure 5-21 Trunk Configuration Trunk Rate Limit This page allows you to change the maximum input and output data rate for each each trunk on the switch.

  • Page 80: Vlan Settings

    ONFIGURING THE WITCH Web – Click TRUNKS, Rate Limiting. Figure 5-22 Trunk Rate Limiting VLAN Settings This page allows you to create and delete VLANs (Virtual LANs) and to change the VLAN membership and behaviour of individual ports. VLANs are powerful, but can be difficult to set up properly. Each row of the table corresponds to one port or trunk;...
  • Page 81 ONFIGURATION In the default configuration, any port is able to send traffic to any other port and a PC connected to any port will be able to access the management interface. Broadcast traffic, for example, will be flooded to all ports on the switch.
  • Page 82 ONFIGURING THE WITCH Note: QinQ “customer” ports are those ports that are connected to normal VLAN aware switches in the customer’s network. QinQ “network” ports are those which are connected to the service provider's network. To tunnel packets through a service provider’s metro network, QinQ needs to be enabled on the network port.

  • Page 83: Qos Settings

    ONFIGURATION Web – Click VLANS, VLAN Port Configuration. Fill in the required settings for each interface, click Apply. Figure 5-23 VLAN Settings QOS Settings QoS (Quality of Service) is a mechanism that is used to prioritize certain traffic as it is forward through the switch. Traffic can be classified as High or Normal priority and, when the switch is heavily loaded, it is the Normal priority packets that are dropped first.
  • Page 84 ONFIGURING THE WITCH 802.1p Packets are prioritzed using the content of the VLAN-tag. The 802.1p field is held within the VLAN-tag of a packet. The field is three bits long so can hold eight values; 0 - 7 inclusive. When QoS Mode is set to 802.1p, the 802.1p Configuration table appears which allows a priority (normal or high) to be set for each of the eight values.

  • Page 85: Security

    ONFIGURATION Web – Click QOS, Settings. In QoS Mode, select QoS Diabled, 802.1p, or DSCP to configure the related parameters. Figure 5-24 QoS Settings Security IP Filter On this page, you can set up a source IP Filter on all or some ports. It is used to block unwanted access and provide access to the network for either a specific source IP address or a specific subnet.

  • Page 86: Figure 5-25 Ip Filter Configuration

    ONFIGURING THE WITCH • Static - Enable the IP filter with configured values in the Address and IP Mask fields. • DHCP - The IP address for the device connected to this port will be automatically assigned by DHCP server and only frames with the assigned IP address are allowed to access the network.
  • Page 87 ONFIGURATION Port Security Port security is a feature that allows you to configure a port with one or more MAC addresses that are authorized to access the network through that port. The Port Security table has one row for each port and five columns.

  • Page 88: Figure 5-26 Port Security

    ONFIGURING THE WITCH • The MAC addresses already in the address table will be retained and will not age out. Any other device that attempts to use the port will be prevented from accessing the switch. • Number of Learned MAC addresses - Displays the number of currently learned MAC addresses.

  • Page 89: Figure 5-27 Management Access Filter Configuration

    ONFIGURATION This page enables you to set up a management access filter on the switch. With the Management Access Filter Configuration table, you can create a list of up to 8 IP addresses or IP address groups that are allowed management access to the switch through the web interface .

  • Page 90: Igmp Snoop

    ONFIGURING THE WITCH IGMP Snoop The switch can use Internet Group Management Protocol (IGMP) to filter multicast traffic. IGMP Snooping monitors IGMP service requests passing between multicast clients and servers, and dynamically configures the ports which need to recieve the mulitcast traffic. Note: For IGMPV3, the switch incudes basic support for reports only, Source Multicast is not supported.

  • Page 91: Figure 5-28 Igmp Snooping Configuration

    ONFIGURATION Web – Click IGMP Snoop, Settings. Figure 5-28 IGMP Snooping Configuration IGMP Status Show the IGMP Snooping statistics for the whole switch Field Attributes • VLAN ID - VLAN ID number. • Querier - Show whether Querying is enabled. •...

  • Page 92: Figure 5-29 Igmp Snoop Status

    ONFIGURING THE WITCH Web – Click IGMP Snoop, Status. Figure 5-29 IGMP Snoop Status 5-42...

  • Page 93: Troubleshooting

    Check connections between the switch, the power cord, and the wall outlet. • Contact your dealer for assistance. • Contact SMC Technical Support. Link LED is Off • Verify that the switch and attached device are powered • Be sure the cable is plugged into both the switch and corresponding device.

  • Page 94: Power And Cooling Problems

    ROUBLESHOOTING Power and Cooling Problems If the power indicator does not turn on when the power cord is plugged in, you may have a problem with the power outlet, power cord, or internal power supply. However, if the unit powers off after running for a while, check for loose power connections, power losses or surges at the power outlet, and verify that the fans on the unit are unobstructed and running prior to shutdown.

  • Page 95: Cables

    PPENDIX ABLES Twisted-Pair Cable and Pin Assignments For 10BASE-T/100BASE-TX connections, a twisted-pair cable must have two pairs of wires. For 1000BASE-T connections the twisted-pair cable must have four pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be green and the other, green with white stripes.

  • Page 96: 10Base-T/100Base-Tx Pin Assignments

    ABLES 10BASE-T/100BASE-TX Pin Assignments Use unshielded twisted-pair (UTP) or shielded twisted-pair (STP) cable for RJ-45 connections: 100-ohm Category 3 or better cable for 10 Mbps connections, or 100-ohm Category 5 or better cable for 100 Mbps connections. Also be sure that the length of any twisted-pair connection does not exceed 100 meters (328 feet).

  • Page 97: Straight-Through Wiring

    WISTED ABLE AND SSIGNMENTS Straight-Through Wiring If the twisted-pair cable is to join two ports and only one of the ports has an internal crossover (MDI-X), the two pairs of wires must be straight-through. (When auto-negotiation is enabled for any RJ-45 port on the switch, you can use either straight-through or crossover cable to connect to any device type.) You must connect all four wire pairs as shown in the following diagram to...

  • Page 98: Crossover Wiring

    ABLES Crossover Wiring If the twisted-pair cable is to join two ports and either both ports are labeled with an “X” (indicating MDI-X) or neither port is labeled with an “X” (which indicates MDI), a crossover must be implemented in the wiring.

  • Page 99: 1000Base-T Pin Assignments

    WISTED ABLE AND SSIGNMENTS 1000BASE-T Pin Assignments All 1000BASE-T ports support automatic MDI/MDI-X operation, so you can use straight-through cables for all network connections to PCs or servers, or to other switches or hubs. The table below shows the 1000BASE-T MDI and MDI-X port pinouts. These ports require that all four pairs of wires be connected.

  • Page 100: Adjusting Existing Category 5 Cabling To Run 1000Base-T

    ABLES Note that when testing your cable installation, be sure to include all patch cables between switches and end devices. Adjusting Existing Category 5 Cabling to Run 1000BASE-T If your existing Category 5 installation does not meet one of the test parameters for 1000BASE-T, there are basically three measures that can be applied to try and correct the problem: 1.

  • Page 101: Specifications

    PPENDIX PECIFICATIONS Physical Characteristics Ports 20 10/100/1000BASE-T, with auto-negotiation 4 10/100/1000BASE-T shared with 4 SFP transceiver slots. Network Interface Ports 1-24: RJ-45 connector, auto MDI/X 10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better) 100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better) 1000BASE-T: RJ-45 (100-ohm, UTP or STP cable;...

  • Page 102: Switch Features

    PECIFICATIONS Size 44.0 x 17.1 x 4.3 cm (17.0 x 6.7 x 1.7 in.) Temperature Operating: 0 to 40 °C (32 to 104 °F) Storage: -40 to 70 °C (-40 to 158 °F) Humidity Operating: 10% to 90% (non-condensing) AC Input 100 to 240 V, 50-60 Hz, 0.8 A Power Supply Internal, auto-ranging transformer: 100 to 240 VAC, 50 to 60 Hz...

  • Page 103: Standards

    TANDARDS Software Loading HTTP in-band Standards IEEE 802.3-2005 Ethernet, Fast Ethernet, Gigabit Ethernet IEEE 802.1Q Virtual LAN IEEE 802.1X, Port-Based Network Access Control, 2001 ISO/IEC 8802-3 Compliances CE Mark Emissions FCC Class A VCCI Class A Immunity EN 61000-4-2/3/4/5/6/8/11 Safety UL 60950-1 &...
  • Page 104 PECIFICATIONS...

  • Page 105: Table D-1 Ez Switch 10/100/1000 Products And Accessories

    PPENDIX RDERING NFORMATION Table D-1 EZ Switch 10/100/1000 Products and Accessories Product Number Description Smart Switch SMCGS24C-Smart 24 port 10/100/1000 SMC1GSFP-SX 1-port 1000BASE-SX Small Form Pluggable (SFP) mini-GBIC transceiver SMC1GSFP-LX 1-port 1000BASE-LX Small Form Pluggable (SFP) mini-GBIC transceiver SMC1GSFP-ZX 1-port 1000BASE-ZX Small Form Pluggable (SFP) mini-GBIC transceiver...

  • Page 106: Ordering Information

    RDERING NFORMATION...

  • Page 107: Glossary

    LOSSARY 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3 or better UTP cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Fast Ethernet over two pairs of Category 5 or better UTP cable. 1000BASE-LX IEEE 802.3z specification for Gigabit Ethernet over two strands of 50/125, 62.5/125 or 9/125 micron core fiber cable.
  • Page 108 LOSSARY Bandwidth The difference between the highest and lowest frequencies available for network signals. Also synonymous with wire speed, the actual speed of the data transmission along the cable. Collision A condition in which packets transmitted over the cable interfere with each other.
  • Page 109 LOSSARY Full Duplex Transmission method that allows two network devices to transmit and receive concurrently, effectively doubling the bandwidth of that link. Gigabit Ethernet A 1000 Mbps network communication system based on Ethernet and the CSMA/CD access method. IEEE Institute of Electrical and Electronic Engineers. IEEE 802.3 Defines carrier sense multiple access with collision detection (CSMA/CD) access method and physical layer specifications.
  • Page 110 LOSSARY Layer 2 Data Link layer in the ISO 7-Layer Data Communications Protocol. This is related directly to the hardware interface for network devices and passes on traffic based on MAC addresses. Light emitting diode used for monitoring a device or network condition. Link Segment Length of twisted-pair or fiber cable joining a pair of repeaters or a repeater and a PC.
  • Page 111 LOSSARY Redundant Power Supply (RPS) A backup power supply unit that automatically takes over in case the primary power supply should fail. RJ-45 Connector A connector for twisted-pair wiring. Switched Ports Ports that are on separate collision domains or LAN segments. Telecommunications Industry Association Transmission Control Protocol/Internet Protocol (TCP/IP) Protocol suite that includes TCP as the primary transport protocol, and IP...
  • Page 112 LOSSARY Glossary-6...

  • Page 113: Index

    NDEX Numerics cleaning fiber terminators 4-4 compliances 10 Mbps connectivity rules 4-7 EMC C-3 100 Mbps connectivity rules 4-7 safety C-3 1000 Mbps connectivity rules 4-6 connectivity rules 1000BASE-LX fiber cable lengths 4-7 10 Mbps 4-7 1000BASE-SX fiber cable lengths 4-6 100 Mbps 4-7 1000BASE-T 1000 Mbps 4-6...
  • Page 114 NDEX IEEE 802.3z Gigabit Ethernet 1-5 indicators, LED 1-3 ordering information D-1 installation connecting devices to the switch 4-2 desktop or shelf mounting 3-6 port connections 4-1 package contents 3-3 power requirements 3-1 passwords problems A-2 administrator setting 5-14 rack mounting 3-4 pin assignments B-1 site requirements 3-1 1000BASE-T B-5...
  • Page 115 NDEX statistics port 5-9 status LEDs 1-3 user password 5-14 surge suppressor, using 3-1 switch architecture 1-2 switching, introduction to 2-1 VLANs tagging 2-5 temperature within a rack 3-4 troubleshooting in-band access A-2 Web interface power and cooling problems A-2 access requirements 5-1 switch indicators A-1 configuration buttons 5-3...
  • Page 116 NDEX Index-4...
  • Page 118 Informações sobre Suporte Técnico em www.smc.com SWEDISH Information om Teknisk Support finns tillgängligt på www.smc.com INTERNET E-mail address: techsupport@smc.com Driver updates http://www.smc.com/ index.cfm?action=tech_support_drivers_downloads World Wide Web http://www.smc.com/ SMCGS24C-Smart 149100009500H R04 20 Mason • Irvine, CA 92618 • Phn: 949-679-8000 • www.smc.com...

This manual is also suitable for:

Ez switch smcgs24c-smart

Table of Contents
