, XTS and XPlanar are registered trademarks of and licensed by Beckhoff Automation GmbH. Other designations used in this publication may be trademarks whose use by third parties for their own purposes could violate the rights of the owners. Patent Pending...
Further components of documentation This documentation describes device-specific content. It is part of the modular documentation concept for Beckhoff I/O components. For the use and safe operation of the device / devices described in this documentation, additional cross-product descriptions are required, which can be found in the following table.
All the components are supplied in particular hardware and software configurations appropriate for the application. Modifications to hardware or software configurations other than those described in the documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG. Personnel qualification This description is only intended for trained specialists in control, automation and drive engineering who are familiar with the applicable national standards.
Foreword Documentation issue status Version Comment 1.1.0 • Image of EL9562-0015 corrected • Chapter Process data updated 1.0.0 • First release Version: 1.1.0 EL9562, EL9562-0015...
Associated and synonymous with each revision there is usually a description (ESI, EtherCAT Slave Information) in the form of an XML file, which is available for download from the Beckhoff web site. From 2014/01 the revision is shown on the outside of the IP20 terminals, see Fig. “EL2872 with revision 0022 and serial number 01200815”.
Version identification of EL terminals The serial number/ data code for Beckhoff IO devices is usually the 8-digit number printed on the device or on a sticker. The serial number indicates the configuration in delivery state and therefore refers to a whole production batch, without distinguishing the individual modules of a batch.
1.5.3 Beckhoff Identification Code (BIC) The Beckhoff Identification Code (BIC) is increasingly being applied to Beckhoff products to uniquely identify the product. The BIC is represented as a Data Matrix Code (DMC, code scheme ECC200), the content is based on the ANSI standard MH10.8.2-2016.
Page 12
Fig. 3: Example DMC 1P072222SBTNk4p562d71KEL1809 Q1 51S678294 An important component of the BIC is the Beckhoff Traceability Number (BTN, position 2). The BTN is a unique serial number consisting of eight characters that will replace all other serial number systems at Beckhoff in the long term (e.g.
Electronic access to the BIC (eBIC) Electronic BIC (eBIC) The Beckhoff Identification Code (BIC) is applied to the outside of Beckhoff products in a visible place. If possible, it should also be electronically readable. The interface that the product can be electronically addressed by is crucial for the electronic readout.
Page 14
• The following auxiliary functions are available for processing the BIC/BTN data in the PLC in Tc2_Utilities as of TwinCAT 3.1 build 4024.24 ◦ F_SplitBIC: The function splits the Beckhoff Identification Code (BIC) sBICValue into its components using known identifiers and returns the recognized substrings in the ST_SplittedBIC structure as a return value ◦...
EL9562-0015 [} 16] EL9562 - Introduction Fig. 4: EL9562 The EL9562 power supply terminal generates two electrically isolated output voltages of 24 V each from the input voltage (24 V ). The output voltages can be tapped at the terminal and are electrically isolated from each other and from the input voltage.
Product overview EL9562-0015 - Introduction Fig. 5: EL9562-0015 The EL9562-0015 power supply terminal generates two electrically isolated output voltages of 15 V each from the input voltage (24 V ). The output voltages can be tapped at the terminal and are electrically isolated from each other and from the input voltage. A symmetrical DC voltage can be generated by connecting both output voltages.
Vibration / shock resistance conforms to EN 60068-2-6 / EN 60068-2-27 EMC immunity / emission conforms to EN 61000-6-2 / EN 61000-6-4 Protection rating IP20 Installation position variable Approvals / markings* CE, UKCA, EAC *) Real applicable approvals/markings see type plate on the side (product marking). EL9562, EL9562-0015 Version: 1.1.0...
• Each bus station must be terminated on the right-hand side with the EL9011 or EL9012 end cap to ensure the degree of protection and ESD protection. Fig. 6: Spring contacts of the Beckhoff I/O components Version: 1.1.0 EL9562, EL9562-0015...
To mount the mounting rails with a height of 7.5 mm under the terminals and couplers, you should use flat mounting connections (e.g. countersunk screws or blind rivets). EL9562, EL9562-0015 Version: 1.1.0...
Page 20
PE power contact The power contact labeled PE can be used as a protective earth. For safety reasons this contact mates first when plugging together, and can ground short-circuit currents of up to 125 A. Version: 1.1.0 EL9562, EL9562-0015...
Products marked with a crossed-out wheeled bin shall not be discarded with the normal waste stream. The device is considered as waste electrical and electronic equipment. The national regulations for the disposal of waste electrical and electronic equipment must be observed. EL9562, EL9562-0015 Version: 1.1.0...
The passive terminals have no current consumption out of the E-Bus. To ensure an optimal data transfer, you must not directly string together more than two passive terminals! Examples for positioning of passive terminals (highlighted) Fig. 10: Correct positioning Fig. 11: Incorrect positioning Version: 1.1.0 EL9562, EL9562-0015...
Other installation positions All other installation positions are characterized by different spatial arrangement of the mounting rail - see Fig “Other installation positions”. The minimum distances to ambient specified above also apply to these installation positions. EL9562, EL9562-0015 Version: 1.1.0...
Page 24
Mounting and wiring Fig. 13: Other installation positions Version: 1.1.0 EL9562, EL9562-0015...
Insert the new component and plug in the connector with the wiring. This reduces the installation time and eliminates the risk of wires being mixed up. The familiar dimensions of the terminal only had to be changed slightly. The new connector adds about 3 mm. The maximum height of the terminal remains unchanged. EL9562, EL9562-0015 Version: 1.1.0...
Page 26
Ultrasonically compacted (ultrasonically welded) strands Ultrasonically compacted (ultrasonically welded) strands Ultrasonically compacted (ultrasonically welded) strands can also be connected to the standard and high-density terminals. In this case, please note the tables concerning the wire-size width [} 28]! Version: 1.1.0 EL9562, EL9562-0015...
0.08 ... 2.5 mm Wire size width (fine-wire conductors) 0.08 ... 2.5 mm 0.08 ... 2.5 mm Wire size width (conductors with a wire end sleeve) 0.14 ... 1.5 mm 0.14 ... 1.5 mm Wire stripping length 8 ... 9 mm 9 ... 10 mm EL9562, EL9562-0015 Version: 1.1.0...
Wire size width (ultrasonically compacted only 1.5 mm (see notice [} 26]) [ultrasonically welded] strands) Wire stripping length 8 ... 9 mm 3.6.3 Shielding Shielding Encoder, analog sensors and actuators should always be connected with shielded, twisted paired wires. Version: 1.1.0 EL9562, EL9562-0015...
Mounting and wiring 3.6.4 EL9562 - connection and LED displays Fig. 18: EL9562 - connection and LED displays Connection Terminal point Description Name Output 1, 24 V Output 1, 24 V 24 V 24 V, internally connected to terminal point 6 and power contact 24 V 0 V...
Mounting and wiring 3.6.5 EL9562-0015 - connection and LED displays Fig. 19: EL9562-0015 - connection and LED displays Connection Terminal point Description Name Output 1, 24 V Output 1, 15 V 24 V 24 V, internally connected to terminal point 6 and power contact 24 V 0 V...
Beckhoff EtherCAT modules are intended for use with Beckhoff’s UL Listed EtherCAT System only. CAUTION Examination For cULus examination, the Beckhoff I/O System has only been investigated for risk of fire and electrical shock (in accordance with UL508 and CSA C22.2 No. 142). CAUTION For devices with Ethernet connectors Not for connection to telecommunication circuits.
This can be downloaded from the Beckhoff Website and installed according to the installation instructions. The configuration tree in the Beckhoff TwinCAT System Manager can be created in 2 ways: • by scanning of existing hardware (referred to as “online”), or •...
Page 33
• Appending a new box (see Fig. Appending a new box (Device -> right click -> Append Box…)). In the dialog that follows select an EK1100 system coupler, for example (see Fig. Selecting a system coupler (e.g. EK1100)) and confirm with OK. Fig. 23: Appending a new box (Device -> right-click -> Append Box... ) EL9562, EL9562-0015 Version: 1.1.0...
Page 34
EL95xx, (see Fig. Selecting the terminal, e.g. EL9505) and confirm with • The terminal is added in the TwinCAT tree (see Fig. Terminal in the TwinCAT tree). Fig. 25: Appending a new box (Device -> right-click -> Append Box... ) Version: 1.1.0 EL9562, EL9562-0015...
Page 35
Commissioning Fig. 26: Selecting the terminal, e.g. EL9505 Fig. 27: Terminal in the TwinCAT tree EL9562, EL9562-0015 Version: 1.1.0...
Commissioning Process data TwinCAT displays the process data of the EL9562 in a tree structure. Fig. 28: EL9562 - Tree structure The EL9562 contains the three input objects: • Status Uo Channel 1 (0x1A00) with the Power OK signal for the status of output voltage 1 •...
Commissioning On delivery, the output voltages of the EL9562 are switched on As soon as the EL9562-xxxx is supplied with input voltage (24 V ), the two output voltages are present, even if no EtherCAT communication is taking place. The output voltages must be actively switched off by setting the process data Control Channel 1 / Disable or Control Channel 2 / Disable.
Please contact your Beckhoff branch office or representative for local support and service on Beckhoff products! The addresses of Beckhoff's branch offices and representatives round the world can be found on her internet pages: www.beckhoff.com You will also find further documentation for Beckhoff components there.
Page 39
Trademark statements Beckhoff®, TwinCAT®, TwinCAT/BSD®, TC/BSD®, EtherCAT®, EtherCAT G®, EtherCAT G10®, EtherCAT P®, Safety over EtherCAT®, TwinSAFE®, XFC®, XTS® and XPlanar® are registered trademarks of and licensed by Beckhoff Automation GmbH. Third-party trademark statements DeviceNet and EtherNet/IP are trademarks of ODVA, Inc.
