Technical Specifications

Standards Compliance IEEE 802.3 10BASE-T Ethernet,
Protocol
Max Forwarding and
Max Filtering Rate
(for 64-byte packets)
LED-Indicators
Network Cables
Dimensions
Weight
Operating
Temperature
Operating Humidity
EMI
Safety
IEEE 802.3u 100BASE-TX/FX Fast Ethernet,
IEEE 802.3z 1000BASE-X Fiber Gigabit Ethernet
IEEE 802.3ab 1000BASE-T UTP Gigabit Ethernet
ANSI/IEEE standard 802.3 N-Way Auto-negotiation
CSMA/CD
14,880 pps to Ethernet port,
148,800 pps to Fast Ethernet port
1,488,000pps to Gigabit Ethernet port
Modules:1000M-T : 1000M,100M, LK/ACT, FDX (4 LEDs)
100M FX: LK/TX, RX, FDX/COL (3 LEDs)
Gigabit Fiber: LK, ACT (2 LEDs)
GBIC/Mini-GBIC: LK, ACT (2 LEDs)
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable EIA/TIA-568 (100m )
100Base-TX: 2-pair UTP/STP Cat. 5 cable EIA/TIA-568 (100m )
1000Base-T: 4-pair UTP/STP Cat. 5 or above EIA/TIA-568 (100m )
100Base-FX: 50, 62.5/125 micron multi-mode fiber-optics ( 2Km )
8,9/125 micron single-mode fiber-optics ( 60Km )
1000Base-X: 50, 62.5/125 micron multi-mode fiber-optics ( 500m )
10/125 micron single-mode fiber-optics (10Km )
120 mm x 79 mm x 22 mm ( L x W x H )
71g ~ 73 g
0ºC to 45ºC (32ºF to 113ºF)
10% to 90% (Non-condensing)
FCC Class A, CE Mark
UL, TUV
