TECHNICAL SPECIFICATIONS

PORTS
• 12 SFP 1000BASE-X ports
• 4 10/100/1000BASE-T ports
• Built-in network management
NETWORK MEDIA
• 10BASE-T : RJ-45 UTP Cat. 3, 4, 5
• 100BASE-TX; RJ-45 UTP Cat. 5
• 1000BASE-T: RJ-45 UTP Cat. 5
• 1000BASE-X : SFP interface
• Multimode fiber cable: 62.5/125
or 50/125 micros
• Singlemode fiber cable: 9/125 microns
LEDs
• System (power, Diagnostics)
• Port: Link, Activity
DIMENSIONS
• 17.4 x 9 x 1.7 in / 44.0 x 22.9 x 4.3cm
WEIGHT
• 11.02 lb / 5.0kg
HUMIDITY
• Operating 5% to 95% (non-condensing)
TEMPERATURE
o o o
• Operating : 32 – 122 F / 0 – 50
o o o
• Storage: -40 – 158 F / -40 – 70
WARRANTY
• Limited Lifetime
AGGREGATED BANDWIDTH
• 24Gbps
BUFFER ARCHITECTURE
• 1Mb per system
SWITCHING DATABASE
• 16K MAC address entries
AC INUT
• 100 to 240V, 50-60Hz
POWER SUPPLY
• Internal, auto-ranging transformer :
90 TO 260 VAC, 47 to 63 Hz
• Redundant DC input
POWER CONSUMPTION
• 70W max
HEAT DISSIPATION
• 239 BTU/hr
MAXIMUM CURRENT
• 1.2A @ 110VAC,
• 0.6A @ 240 VAC
SWITCH FEATURES
LAYER 3
• IP routing
• RIP routing
• OSPF
• Multinetting
• Supernetting (CIDR)
• Multicast routing
• DVMRP
• IGMP
www.smc.com
SMC8612XL3
• PIM *
• Virtual Router Redundancy Protocol
• Address Resolution Protocol (ARP)
LAYER 2
• Spanning Tree Protocol
• Forwarding mode with support to IEEE802.1w
• Store-and-forward
• Flow Control
• Full Duplex: IEEE802.3x
• Half Duplex: back pressure
• VLAN Support
• Up to 256 groups; port-based or with
802.1Q VLAN tagging, GVRP for automatic
VLAN learning, Private VLANs
• Private VLANs
• IEEE802.1v protocol based VLANs*
• Class of Service
• Supports four levels of priority and
weighted fair queuing
• DSCP based Class of Service
• TCP/UDP Port Based Class of Service
• Broadcast storm control
• Link Aggregation
• Port Mirroring
• RADIUS Client Enhancement for 802.1x
o
F
• TACACS+ authentication client
o
F
• SSL
• SSH1.5 and 2 for secure Telnet Session
• Access Control List
• Rate Limiting
• Static Port Security
• SNTP (Simple Network Time Protocol)
• IEEE802.1s independent Spanning
Tree for VLAN groups*
• DiffServ*
MANAGEMENT FEATURES
• In-band Management
• Telnet, SLIP, Web-based HTTP, or
SNMP manager
• Out-of-band Management
• RS-232 DB-9 console port
• Software Loading
• TFTP in-band or Xmodem out-of-band
• System Event log
• MIB Support
• MIB II (RFC1213), Bridging MIB (RFC1493),
Ethernet-Like MIB (RFC1643), RMON
MIB (RFC1757), RADIUS authentication
client MIB (RFC2618), SMC's private MIB,
Port Entity Access MIB (802.1x), UDP
MIB, RFC1850 OSPF II MIB, RFC2096
Forwarding Table MIB, RFC2737 Entity
MIB, RFC2742 Extensible SNMP Agents
MIB, IP Multicasting related MIBs, IGMP
MIB, Private MIB, IEEE802.1w Rapid
Reconfiguration Spanning Tree MIB
RMON SUPPORT
• Groups 1, 2, 3, 9 (Statistics, History,
Alarm, Event)
STANDARDS
• IEEE802.3 Ethernet, IEEE802.3u
Fast Ethernet, IEEE802.3z Gigabit
• IEEE802.1D Spanning Tree Protocol
and traffic priorities
• IEEE802.1p priority tags
• IEEE802.1Q VLAN
• IEEE802.1ac VLAN tagging
• IEEE802.1ad Link aggregation control protocol
• IEEE802.1w Fast Spanning Tree
• IEEE802.1s Multiple Spanning Tree*
• IEEE802.1v Protocol based VLANs*
• IEEE802.1x authentication
ISO
• IEC8802.3
• SNMP (RFC 1157), RMON (RFC 1757), ARP
(RFC826), IEGMP (RCF1157), IGMP (RFC1112),
MIB II (RFC1213), Ethernet-like MIB
(RFC1643), Bridge MIB (RFC1493), RADIUS
(RFC2618), MAU MIB
COMPLIANCES
• CE Mark
• Emissions
• FCC Class A
• Industrial Canada Class A
• EN550222 (CISPR 22) Class A
• VCCI A
• C-Tick – AS/NZS 3548 (1995)
Class A Immunity
• IEC 1000- 4 – 2/3/4/6
• Safety
• CSA/NTRL (CSA22.2.2950 &
UL1950), EN60950 (TUV/GS)
SFP/MINI-GBICs
•SMCBGSLCX1
• SMCBGLLCX1
• SMCBGZLCX1
NETWORK INTERFACE
• LC connector, 50/125 or 62.5/125
micron multimode fiber cable
• LC connector, 9/125 micron
single-mode fiber cable
STANDARDS
•802.3z Gigabit Ethernet
MAXIMUM HAUL
• 550m
• 10Km
• 100Km
