Features
One 1000Mbps fiber port ( SX/LX connectors )
Full-duplex
LED-indicators for LK, ACT statuses
For establishing fiber links cable distance up to 500 m ( 1000Base-SX
SC multi-mode), 10 Km ( 1000Base-LX SC single mode).
LED Indicators
The are two LED indicators for the Gigabit Fiber connection port. If there is
no connection to this port, the LED indicators are not lit.
LK The LED indicator is green when there is a connection securely to
a device ( Link ) to the corresponding port.
ACT This LED indicator blinks green when there is a data transmission
( Activity ) taking place at the corresponding port.

Installation Steps

To install the Expansion Modules, follow these steps:
1. First of all, power off the switch, which you want to insert the module.
2. Insert the module into a SMC-EZ1026DT V.2 Switch module slot
and secure the retaining screws.
3. After the modules are installed, reset or reboot switch.
4. Connect the network cable to the module port and check the module
and network device for correct operation.
Details on these steps are provided in the following document.
Insert the Module Into the Slot
The modules are installed into SMC-EZ1026DT V.2 expansion slots
intelligent switch as follow:
1. Unscrew the thumbscrews on the blank bracket. Remove the blank
bracket and set aside, but do not discard it. Put the blank bracket back in if
you remove the new module.
