Loosen these screws and remove the cover plate
2. Touch a grounded, metal object (such as a powered-on switch) to
discharge any static electricity on your body, then carefully remove the
module from its protective anti-static packaging. Hold the module
by its bulkhead or edges, taking care not touch any of its board
Components or metal connectors.
3. Install the new expansion Module by inserting it into the guides and
sliding it in until it stops. Press it firmly until you feel the module snap into
place. Never force, twist or bend the expansion Module.
4. Using the flat bladed or screwdriver, gently push the thumbscrews in
and turn clockwise to tighten. Do not over tighten the thumbscrews.
5. Power SMC-EZ1026DT V.2 ON, and the Switch will automatically
detect the expansion Module. Plug the network cable connector into
the expansion Module. Check the LEDs to verify that if there is a link
and proper connection.
Slide the module into the slot
until it snaps into place
