Care And Maintenance; Troubleshooting - Harbor Breeze 43305 Manual

CARE AND MAINTENANCE

At least twice each year, tighten all screws on the fan. Clean the motor housing with only a soft brush
or lint-free cloth to avoid scratching the finish. Clean the blades with a lint-free cloth.
Bulb Replacement: Use 40-watt max. E26-base LED, CFL or incandescent bulbs. Halogen bulbs are
not recommended for this item.

Important: Shut off the main power supply before you begin any maintenance tasks. Do not use
water or a damp cloth to clean the ceiling fan.

TROUBLESHOOTING

PROBLEM
The fan does not
move.
There is excessive
wobbling.
The fan operates
correctly, but the
lights are not
working.
POSSIBLE CAUSE
1. The power is off or the fuse is
blown.
2. There is a faulty wire connection.
3. The plugs are not connected
properly.
4. The reverse switch is not
completely engaged.
1. The blades and/or blade are loose.
2. The blades are unbalanced.
3. The fan mounting is not secure.
1. The bulbs are not installed
correctly.
2. The light kit wire plugs are not
connected properly.
3. There is a faulty wire connection.
CORRECTIVE ACTION
1. Turn the power on or check the fuse.
2. Turn the power off. Loosen the
canopy and check all connections.
3. Check that the connectors from the
light kit and fan are connected properly.
4. Push the reverse switch completely
to the left or right.
1. Check and tighten all screws that
hold the fan blades to the blade arms
and the blade arms to the motor.
2. Switch one blade with a blade from
the opposite side. Or balance the
fan using a blade balancing kit (sold
separately).
3. Turn off the power. Loosen the
motor housing and verify the upper
mounting bracket is secure to the
electrical outlet box. The bracket must
be flush without movement against
the outlet box.
1. Re-install the bulb(s).
2. Ensure the 9-pin connectors in the
light kit are connected properly.
3. Turn the power off and check all
connections at the ceiling outlet box.
14
