Harbor Breeze 40048 Manual

Sail stream ceiling fan
Hide thumbs

Advertisement

Table of Contents

Harbor Breeze® is a registered trademark
of LF, LLC. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Purchase Date _________________________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5 p.m.,
EST, Friday.
EB16263
1
ITEM #0609448
SAIL STREAM
CEILING FAN
MODEL #40048
Español p. 19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 40048 and is the answer not in the manual?

Questions and answers

Related Manuals for Harbor Breeze 40048

Summary of Contents for Harbor Breeze 40048

  • Page 1 SAIL STREAM CEILING FAN MODEL #40048 Español p. 19 Harbor Breeze® is a registered trademark of LF, LLC. All Rights Reserved. ATTACH YOUR RECEIPT HERE Purchase Date _________________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Hardware Contents .

  • Page 3: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Mounting Bracket Canopy (preassembled to Motor Assembly [C]) Motor Assembly Fitter Plate (preassembled to Motor Assembly [C]) Switch Housing Light Pan Locking Ring (preassembled to Bowl Housing [H]) Bowl Housing Glass Bowl (preassembled to Bowl Housing [H]) Blade Bulb Metal Bowl...

  • Page 4: Hardware Contents

    HARDWARE CONTENTS (shown actual size) Wire Connector Blade Screw Blade Washer Qty . 3 Qty . 9 Qty . 9 + 1 extra + 1 extra + 1 extra...

  • Page 5: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product . • Before you begin installing the fan, disconnect the power by removing fuses or turning off the circuit breakers . • Make sure all electrical connections comply with local codes, ordinances, the National Electrical Code and ANSI/NFPA 70-199. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring .

  • Page 6: Preparation

    SAFETY INFORMATION CAUTION: Be sure the outlet box is properly grounded or that a ground (green or bare) wire is present . CAUTION: Carefully check all screws, bolts and nuts on the fan motor assembly to ensure they are secured . CAUTION: This device complies with Part 15 of the FCC Rules .

  • Page 7: Initial Installation

    INITIAL INSTALLATION 1 . Turn off the circuit breakers and the wall switch to the fan supply line leads . DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death . 2 . This fan is intended for Flushmount Installation . Standard Mounting, Angle Mounting, and Closemount installations are not available .
  • Page 8 INITIAL INSTALLATION 4 . Loosen the four light pan screws (O) preassembled to the fitter plate (D). Then, turn the orange shipping block counterclockwise and remove . Discard the shipping block . Shipping Block 5 . Feed the supply wires from the outlet box through Outlet Box the center hole in the mounting bracket (A) . Then, secure the mounting bracket (A) to the outlet box (not included) using screws and washers provided with the outlet box .

  • Page 9: Wiring

    WIRING WARNING: To reduce the risk of fire, electrical shock or personal injury, wire connectors provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from the fan . If your house wire is larger than 12-gauge and/or there is more than one house wire to connect to the two fan lead wires, consult an electrician for the proper size wire connectors to use .

  • Page 10: Final Installation

    FINAL INSTALLATION 1 . Loosen all four mounting bracket screws (M), then completely remove two mounting bracket screws (M) from opposite sides of the mounting bracket (A) . Slide the canopy (B) over the mounting bracket (A), aligning the slotted holes in the canopy (B) with the pre-loosened mounting bracket screws (M) in the mounting bracket (A) .
  • Page 11 FINAL INSTALLATION 4 . Note: If you wish to install the fan without the light kit, proceed to Step 8 . To install the fan with the light kit, remove one of the switch housing screws (N) from the light pan (F), and loosen (do not remove) the other two screws .
  • Page 12 FINAL INSTALLATION 7 . Align the notches in the switch housing (E) with the grooves in the locking ring (G) preassembled to bowl housing (H) . Then, twist the locking ring (G) tightly in a clockwise direction until it is secure . Turn on the circuit breakers and the wall switch to the fan supply lead lines .
  • Page 13 FINAL INSTALLATION 10 . Align the notches in the switch hosing (E) with the grooves in the locking ring (G) preassembled to bowl housing (H) . Then, twist the locking ring (G) tightly in a clockwise direction until it is secure . Turn on the citcuit breakers and the wall switch to the fan supply lead lines .

  • Page 14: Operating Instructions

    OPERATING INSTRUCTIONS 1 . To operate the fan using the remote from remote pack (Q), press and release the following buttons: III - High speed Led Indicator II - Medium speed High Speed I - Low speed Fan Off - Turns power to fan off . Medium Speed Light Delay - Tap the light delay button, which will Low Speed...

  • Page 15: Care And Maintenance

    CARE AND MAINTENANCE At least twice each year, tighten all screws on the fan . Clean the motor housing with only a soft brush or lint-free cloth to avoid scratching the finish. Clean the blades with a lint-free cloth. Bulb Replacement: Use 75-watt max . halogen bulb or LED equivalent . CFL and incandescent bulbs are not recommended for this item .
  • Page 16 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1 . The blades are loose . 1 . Check and tighten all screws that hold the fan blades to the blade arms and the motor . 2 . There is a cracked blade . 2 .

  • Page 17: Warranty

    LIFETIME LIMITED WARRANTY The manufacturer warrants this fan to be free from defects in workmanship and materials present at time of shipment from the factory for a lifetime from the date of purchase by the original purchaser . The retailer also warrants that all other fan parts, excluding any glass or plastic blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of one year after the date of purchase by the original purchaser .

  • Page 18: Replacement Parts List

    REPLACEMENT PARTS LIST For replacement parts, call the customer service department at 1-800-643-0067, 8 a .m . - 6 p .m ., EST, Monday - Thursday, 8 a .m . - 5 p .m ., EST, Friday . PART DESCRIPTION PART# Mounting Bracket 0609448-A...
