HARBOR BREEZE and logo design are trademarks or
registered trademarks of LF, LLC. All rights reserved.
ATTACH YOUR RECEIPT HERE
Purchase Date _________________________
Thank you for purchasing this Harbor Breeze product.
Questions, problems, or missing parts?
Before returning, contact us at:
888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday or at ascs@lowes.com.
SS24036
MAC III CEILING FAN
1
ITEM #5497049, 5497050
MODEL #43351, 43352
Español p. 19
Advertisement
Table of Contents
Related Manuals for Harbor Breeze MAC III
Summary of Contents for Harbor Breeze MAC III
- Page 1 ITEM #5497049, 5497050 MODEL #43351, 43352 MAC III CEILING FAN Español p. 19 HARBOR BREEZE and logo design are trademarks or registered trademarks of LF, LLC. All rights reserved. ATTACH YOUR RECEIPT HERE Purchase Date _________________________ Thank you for purchasing this Harbor Breeze product.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents ..............3 Hardware Contents . -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Mounting Bracket (preassembled to Canopy [B]) Canopy (preassembled to Motor Assembly [C]) Motor Assembly Fitter Plate (preassembled to Motor Assembly [C]) Fitter Plate Screw (preassembled to Fitter Plate [D]) Light Pan Light Pan Screw (preassembled to Light Pan [F]) Light Kit Glass Bowl Blade... -
Page 4: Hardware Contents
HARDWARE CONTENTS (shown actual size) Wire Connector Blade Screw Screw Cap Motor Screw Qty. 1 Qty. 9 Qty. 9 1 extra + 1 extra + 1 extra + 1 extra... -
Page 5: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. • Before you begin installing the fan, disconnect the power by removing fuses or turning off the circuit breakers. • Make sure all electrical connections comply with local codes, ordinances, the National Electrical Code and ANSI/NFPA 70-199. -
Page 6: Preparation
SAFETY INFORMATION CAUTION: Be sure the outlet box is properly grounded or that a ground (green or bare) wire is present. CAUTION: Carefully check all screws, bolts and nuts on the fan motor assembly to ensure they are secured. CAUTION: This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: 1) This device may cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 7: Initial Installation
INITIAL INSTALLATION 1. Turn off the circuit breakers and the wall switch to the fan supply line leads. DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death. 2. This fan is intended for Flushmount Installation. Standard Mounting, Angle Mounting, and Closemount installations are not available. - Page 8 INITIAL INSTALLATION 4. Loosen all four mounting bracket screws (M), then completely remove two mounting bracket screws (M) from the round holes in the canopy (B). Set them aside for later use. Remove mounting bracket (A) from canopy (B). Round Hole 5.
-
Page 9: Wiring
WIRING WARNING: To reduce the risk of fire, electrical shock or personal injury, wire connectors provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If your house wire is larger than 12-gauge and/or there is more than one house wire to connect to the two fan lead wires, consult an electrician for the proper size wire connectors to use. -
Page 10: Final Installation
FINAL INSTALLATION 1. Slide the canopy (B) over the mounting bracket (A), aligning the slotted holes in the canopy (B) with the Slotted Hole previously loosened mounting bracket screws (M) in the mounting bracket (A). Twist the canopy (B) clockwise to lock. - Page 11 FINAL INSTALLATION 4. Remove the three light pan screws (G) preassembled to the side of the light pan (F).Connect the 6-pin connector from the fan to the 6-pin connector from the light kit (H). Secure the light kit (H) with the previously removed light pan screws (G).
- Page 12 FINAL INSTALLATION Remote control from remote pack (L) comes equipped with a wall bracket. If you wish to install the wall bracket, remove the small plate to expose the screw holes. Insert wall brackets screws through holes and into wall, then cover with the previously removed small plate.
-
Page 13: Operating Instructions
OPERATING INSTRUCTIONS 1. To operate the fan using remote control, press and release the following buttons: Indicator LED Indicator - Indicates the three speeds of the fan. It should illuminate when any remote button is pressed. If Fan Power not, replace the 1.5 V, AAA batteries. Fan Power button has three options: Sleep Timer ) - Turns the fan off or turns on fan at previously... - Page 14 OPERATING INSTRUCTIONS 3. Using a ceiling fan will allow you to raise your thermostat setting in summer and lower your thermostat setting in winter without feeling a difference in your comfort. Reverse In warmer weather, push the reverse switch left to Switch display a sun icon, which will result in downward airflow creating a wind chill effect (Fig.
-
Page 15: Care And Maintenance
CARE AND MAINTENANCE At least twice each year, tighten all screws on the fan. Clean the motor housing with only a soft brush or lint-free cloth to avoid scratching the finish. Clean the blades with a lint-free cloth. Total fixture wattage is 23 watts; do not attempt to replace LED. Battery Replacement: Use 1.5 V, AAA alkaline batteries. - Page 16 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION The fan 1. The light kit wire plugs are not 1. Ensure that the male and female plugs in the operates connected properly. light kit fitter are connected properly. correctly, but the 2. Turn the power off and check all connections lights are not 2.
-
Page 17: Limited Lifetime Warranty
LIMITED LIFETIME WARRANTY Set forth below, the manufacturer warrants the fan motor for this ceiling fan to be free from defects in workmanship and material for the life of the product. Also, subject to the limitations below, the manufacturer warrants all ceiling fan parts (“ceiling fan parts” excludes the motor and parts made in whole or in part with glass) to be free from defects in workmanship and material for a period of one year after the date of purchase by the original purchaser at retail. -
Page 18: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call the customer service department at 888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also contact us at ascs@lowes.com. PART DESCRIPTION #5497049 #5497050 Mounting Bracket 4L000014460 4L000014460 Light Kit 4L000017220 4L000017230 Glass Bowl 4A166920001...
