HARBOR BREEZE and logo design are trademarks or
registered trademarks of LF, LLC. All rights reserved.
Purchase Date _________________________
Thank you for purchasing this HARBOR BREEZE product.
Questions, problems, or missing parts?
Before returning, contact us at:
888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday or at ascs@lowes.com.
SC24478
ITEM #5971306/5979038/5979040/5979042
MODEL #43305/43382/43383/43384
42-INCH COACHMAN
ATTACH YOUR RECEIPT HERE
1
CEILING FAN
Español p. 17
Advertisement
Table of Contents
Related Manuals for Harbor Breeze 43305
Summary of Contents for Harbor Breeze 43305
- Page 1 42-INCH COACHMAN CEILING FAN Español p. 17 ATTACH YOUR RECEIPT HERE HARBOR BREEZE and logo design are trademarks or registered trademarks of LF, LLC. All rights reserved. Purchase Date _________________________ Thank you for purchasing this HARBOR BREEZE product. Questions, problems, or missing parts? Before returning, contact us at: 888-251-1003, 8 a.m.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Package Contents ..............3 Hardware Contents . -
Page 3: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Motor Housing Upper Mounting Bracket Bulb Lower Mounting Bracket (preassembled to Motor [E]) Motor Fitter Plate (preassembled to Motor [E]) Light Kit Glass Shade Blade Arm Blade Socket Ring (preassembled to Light Kit [G]) Motor Screw (preassembled to Motor [E]) Lower Bracket Screw (preassembled to Lower Mounting Bracket [D]) Fitter Plate Screw (preassembled to Fitter Plate [F]) Motor Housing Screw (preassembled to Upper Mounting Bracket [B]) -
Page 4: Hardware Contents
HARDWARE CONTENTS Wire Connector Blade Screw Blade Washer Pull Chain Extension Qty. 1 Qty. 5 Qty. 5 Qty. 2 + 1 extra + 1 extra + 1 extra Push-in Motor Screw Connector 1 extra 1 extra... -
Page 5: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. • Before you begin installing the fan, disconnect the power by removing fuses or turning off the circuit breakers. • Make sure all electrical connections comply with local codes, ordinances, the National Electrical Code and ANSI/NFPA 70-199. -
Page 6: Preparation
SAFETY INFORMATION CAUTION: Read all instructions and safety information before installing your new fan. Review the accompanying assembly diagrams. CAUTION: Be sure the outlet box is properly grounded or that a ground (green or bare) wire is present. CAUTION: Carefully check all screws, bolts and nuts on the fan motor assembly to ensure they are secured. - Page 7 INITIAL INSTALLATION 2. This fan is intended for Flushmount installation. Standard Mounting, Angle Mounting, and Closemount installations are not available. Standard Mounting Angle Mounting Flushmount Closemount 3. Ensure the blades (J) will be at least 30 in. from any obstructions and will be at least 7 ft. above the floor. 30 in.
- Page 8 INITIAL INSTALLATION 5. Remove the lower bracket screws (M) from underneath the lower mounting bracket (D). Remove the 10 motor screws (L) from the motor (E) and save for later use. Note: The notch in the fitter plate allows a Phillips screwdriver (not included) access to motor screws (L).
-
Page 9: Wiring
WIRING WARNING: To reduce the risk of fire, electrical shock or personal injury, wire connectors provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If your house wire is larger than 12-gauge and/or there is more than one house wire to connect to the two fan lead wires, consult an electrician for the proper size wire connectors to use. -
Page 10: Final Installation
FINAL INSTALLATION 1. Temporarily lift the motor housing (A) to the upper mounting bracket (B) to determine which two motor housing screws (O) in the sides of the upper mounting bracket (B) align with the slotted holes in the top edge of the motor housing (A). - Page 11 FINAL INSTALLATION 4. Install the blade arm (I) to the underside of the motor (E) with motor screws (L) previously removed (Step 5, page 8). Tighten with Phillips screwdriver. Repeat for each blade arm (I). 5. Remove the fitter plate screws (N) preassembled to the fitter plate (F).
- Page 12 FINAL INSTALLATION 7. Unscrew the socket ring (K) from the socket of the light kit (G). Then lift the glass shade (H) into the light cup. Secure the glass shade (H) by reinstalling the socket ring (K). 8. Install bulbs (C) into the sockets of the light kit (G). 9.
-
Page 13: Operating Instructions
OPERATING INSTRUCTIONS 1. The pull chain has four positions to control the fan speed. One pull is HIGH, two is MEDIUM, three is LOW, and four turns the fan OFF. The pull chain in the center of the light kit (G) turns the lights ON and OFF. Fan Pull Light Pull Chain... -
Page 14: Care And Maintenance
CARE AND MAINTENANCE At least twice each year, tighten all screws on the fan. Clean the motor housing with only a soft brush or lint-free cloth to avoid scratching the finish. Clean the blades with a lint-free cloth. Bulb Replacement: Use 40-watt max. E26-base LED, CFL or incandescent bulbs. Halogen bulbs are not recommended for this item. -
Page 15: Lifetime Limited Warranty
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. The blades are loose. 1. Check and tighten all screws that hold the fan blades to the blade arms and the motor. 2. There is a cracked blade. 2. Replace the cracked blade. 3. -
Page 16: Replacement Parts List
REPLACEMENT PARTS LIST For replacement parts, call the customer service department at 888-251-1003, 8 a.m. - 8 p.m., EST, Monday - Sunday. You could also contact us at ascs@lowes.com. PART DESCRIPTION #5971306 #5979038 #5979040 #5979042 PART# PART# PART# PART# Motor Housing 4A000028070 4A000028080 4A000028090...
