Cove ceiling fan
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Harbor Breeze® is a registered trademark
of LF, LLC. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Serial Number _________________________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-643-0067, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5 p.m.,
EST, Friday.
AB15786
ABERLY COVE CEILING FAN
Purchase Date _________________________
1
ITEM #0747610
MODEL #40842
Español p. 23
Lowes.com/harborbreeze

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ABERLY 40842 and is the answer not in the manual?

Questions and answers

Related Manuals for Harbor Breeze ABERLY 40842

Summary of Contents for Harbor Breeze ABERLY 40842

  • Page 1 ITEM #0747610 ABERLY COVE CEILING FAN MODEL #40842 Harbor Breeze® is a registered trademark Español p. 23 of LF, LLC. All Rights Reserved. ATTACH YOUR RECEIPT HERE Serial Number _________________________ Purchase Date _________________________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-643-0067, 8 a.m.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Package Contents ..............3 Hardware Contents .

  • Page 3: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Downrod Downrod Pin (preassembled to Downrod [A]) Downrod Clip (preassembled to Downrod [A]) Mounting Bracket (preassembled to Canopy [E]) Canopy Canopy Cover (preassembled to Canopy [E]) Motor Assembly Fitter Plate (preassembled to Motor Assembly [G]) Switch Housing (preassembled to Light Kit [J]) Light Kit Finial Cap (preassembled to Light Kit [J])

  • Page 4: Hardware Contents

    HARDWARE CONTENTS (shown actual size) Wire Connector Blade Screw Blade Washer Plug Button Qty. 1 Qty. 15 Qty. 15 Qty. 1 + 1 extra + 1 extra + 1 extra Lowes.com/harborbreeze...

  • Page 5: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. • Before you begin installing the fan, disconnect the power by removing fuses or turning off the circuit breakers. • Make sure all electrical connections comply with local codes, ordinances, the National Electrical Code and ANSI/NFPA 70-199. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring.

  • Page 6: Preparation

    SAFETY INFORMATION CAUTION: Read all instructions and safety information before installing your new fan. Review the accompanying assembly diagrams. CAUTION: Be sure the outlet box is properly grounded or that a ground (green or bare) wire is present. CAUTION: Carefully check all screws, bolts and nuts on the fan motor assembly to ensure they are secured.

  • Page 7: Initial Installation

    INITIAL INSTALLATION 1. Turn off the circuit breakers and the wall switch to the fan supply line leads. DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death. 2. Determine the mounting method to use. Standard mounting is best suited for ceilings 8 ft.
  • Page 8 INITIAL INSTALLATION 4. Loosen all four preassembled mounting bracket screws (S), then completely remove the two mounting bracket screws (S) from the round holes of canopy (E). Set aside for later use. Detach mounting bracket (D) from canopy (E). 5. Attach mounting bracket (D) to outlet box (not Standard or included) using screws and washers provided with Closemount...

  • Page 9: Standard Or Angle Mounting Instructions

    STANDARD OR ANGLE MOUNTING INSTRUCTIONS 1. Remove the downrod pin (B) and downrod clip (C) from the downrod (A). Then partially loosen the set screws (W) in the yoke at the top of the motor assembly (G). Yoke 2. Insert the downrod (A) through the canopy (E) and yoke cover (O).
  • Page 10 STANDARD OR ANGLE MOUNTING INSTRUCTIONS 4. Depending on the length of downrod you use, you may need to cut the lead wires back to simplify the wiring. If you decide to cut back the lead wires, it is suggested you do so in the following manner: Take the lead wires and make sure you have pulled them 8 in.

  • Page 11: Closemount Instructions

    CLOSEMOUNT INSTRUCTIONS Helpful Hint: The downrod (A), canopy cover (F) and yoke cover (O) are not used in this type of installation. 1. Remove the canopy cover (F) from the bottom of the canopy (E). 2. Remove three Phillips-head closemount screws (V) from the top of the motor assembly (G).

  • Page 12: Wiring

    WIRING WARNING: To reduce the risk of fire, electrical shock or personal injury, wire connectors provided with this fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If your house wire is larger than 12-gauge and there is more than one house wire to connect to the two fan lead wires, consult an electrician for the proper size wire connectors to use.

  • Page 13: Final Installation

    FINAL INSTALLATION Note: Closemount installation will not have the downrod (A), yoke cover (O) or canopy cover (F). 1. Align the canopy (E) over the loosened mounting bracket screws (S) preassembled on mounting bracket (D). Place the keyholes of the canopy (E) onto the mounting bracket screws (S) and rotate the canopy (E) clockwise.
  • Page 14 FINAL INSTALLATION 4. Install the blade arm (P) to the underside of the motor assembly (G) with motor screws (R) previously removed (Step 6, page 8). Tighten with Phillips screwdriver. Repeat for each blade arm (P). Note: If you wish to install the fan without the light kit (J), proceed to Step 8.
  • Page 15 FINAL INSTALLATION 7. Remove the preassembled finial (L), finial cap (K), hex nut (T) and rubber washer (U) from the light kit (J). Lift the glass bowl (N) onto the threaded rod at the bottom of the light kit (J). Feed the pull chain coming from the grommet in the light kit (J) through the off-center hole in the glass bowl (N).
  • Page 16 FINAL INSTALLATION 10. If desired, the mounting bracket in remote pack (Z) Mounting Bracket can be installed to a wall using the provided mounting screws. The remote from remote pack (Z) can be stored in the mounting bracket for easy access. Mounting Bracket 11.

  • Page 17: Operating Instructions

    OPERATING INSTRUCTIONS 1. Remove the battery cover from the back of the remote Remote found in remote pack (Z). Insert the battery from remote pack (Z) into the remote; ensuring the polarity of the LED Indicator battery matches the polarity indicated in the battery compartment -- positive (+) to positive (+) and negative (-) to negative (-).
  • Page 18 OPERATING INSTRUCTIONS 3. Use the fan reverse switch, located on the switch housing (I), to optimize your fan for seasonal performance. Using a ceiling fan will allow you to raise your thermostat setting in summer and lower your thermostat Reverse Switch setting in winter without feeling a difference in your comfort.

  • Page 19: Care And Maintenance

    CARE AND MAINTENANCE At least twice each year, lower the canopy to check the downrod assembly, and then tighten all screws on the fan. Clean the motor assembly with only a soft brush or lint-free cloth to avoid scratching the finish. Clean the blades with a lint-free cloth. Bulb Replacement: Use 60-watt max. candelabra-base bulbs or CFL equivalent. Battery Replacement: Use a 23-amp, 12-volt alkaline battery.
  • Page 20 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION 1. The blades and/or blade arms 1. Check and tighten all screws that hold are loose. the fan blades to the blade arms and the blade arms to the motor. 2. The blades are unbalanced. 2.

  • Page 21: Lifetime Limited Warranty

    LIFETIME LIMITED WARRANTY The manufacturer warrants this fan to be free from defects in workmanship and materials present at time of shipment from the factory for a lifetime from the date of purchase by the original purchaser. The retailer also warrants that all other fan parts, excluding any glass or plastic blades, to be free from defects in workmanship and material at the time of shipment from the factory for a period of one year after the date of purchase by the original purchaser.

  • Page 22: Replacement Parts List

    0747610-J Finial Cap 0747610-K Finial 0747610-L Glass Bowl 0747610-N Yoke Cover 0747610-O Blade Arm 0747610-P Blade 0747610-Q Remote Pack 0747610-Z Hardware Kit 0747610-HW Printed in China Harbor Breeze® is a registered trademark of LF, LLC. All Rights Reserved. Lowes.com/harborbreeze 9121 • 101615...
