- Page 1 M140TG Rugged Tablet PC Intel Core i51135G7 @ 2.40GHz, up to 4.20GHz Quick Start Guide Version 1.0 Document Part No. 9152140K1003 https://dc.winmate.com Please read the instructions carefully before using this product, and save this annual for future use...
-
Page 2: Read Me First
Rugged Tablet PC M140TG Quick Start Guide 1. Read Me First Advisory Conventions Four types of advisories are used throughout the user manual to provide helpful information or to alert you to the potential for hardware damage or personal injury. These are Notes, Important, Cautions, and Warnings. -
Page 3: Safety Information
1. Read Me First Safety Information Precaution on Battery Pack When the Battery Pack Has Deteriorated, Replace It with a New Battery. Continued use Précaution avec le bloc-pile of a damaged battery pack may result in heat generation, ignition, or battery rupture. [FR] Lorsque la pile est détériorée, Do Not Disassemble, Modify, or Insert Sharp remplacer par une nouvelle pile. - Page 4 Rugged Tablet PC M140TG Quick Start Guide General Product Safety This product should not be used near water such as bathtubs, sinks, swimming pools, wet Sécurité générale des basement, etc. produits [FR] Ce produit ne dois pas être utilisé près de l'eau comme les baignoires, les éviers, les...
-
Page 5: Handling And Maintenance
1. Read Me First Handling and Maintenance Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the product. General Guideline [FR] Essuyer délicatement l'écran avec un Guide Général chiffon doux non pelucheux. Ne pas utiliser d'alcool ou un détergent sur le produit. -
Page 6: Declaration Of Conformity (Doc)
Rugged Tablet PC M140TG Quick Start Guide Declaration of Conformity (DoC) FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including interference that may ... - Page 7 1. Read Me First IC Statement REN statement The Ringer Equivalence Number (REN) indicates the maximum number of devices allowed to be connected to a telephone interface. The termination of an interface may consist of any combination of devices subject only to the requirement that the sum of the RENs of all the devices not exceed five. Canadian Compliance Statement This device complies with Industry Canada license-exempt RSSs.
-
Page 8: Ce Notice (European Union)
Rugged Tablet PC M140TG Quick Start Guide CE Notice (European Union) This equipment is in conformity with the requirement of the following EU legislation and harmonized standards. The product also complies with the Council's directions. Electromagnetic Compatibility Directive (2014/30/EU) ... -
Page 9: Copyright Notice
Brand and product names are trademarks or registered trademarks of their respective owners. Disclaimer Winmate Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. We assume... -
Page 10: Getting Started
Introduction Congratulations on purchasing Winmate® 14-inch Rugged Tablet PC M140TG/T. M140TG/T is a rugged tablet with robust features designed to withstand industrial use while providing high- tech solutions that increase productivity, improve safety, and reduce operational costs. It features: Gen. Intel® Processor Family – Tiger Lake Processor... -
Page 11: Description Of Parts
2. Getting Started Description of Parts Dimensions: 341.91 x 224.67 x 25.4 mm Front: Left: Right: Item Description Item Description 14" Touch Micro HDMI HDMI output to the Display and act as one of Screen external display the inputs for the Tablet Computer Audio Jack Headset or headphone... - Page 12 Rugged Tablet PC M140TG Quick Start Guide Rear: Top: Bottom: Item Description Item Description Power Button Power on/off the tablet Speaker Send out sound and voice from the computer. Function Button Programmable function Cooling system key configured by Hottab Utility Rear Camera 8MP Autofocus Camera.
-
Page 13: First-Time Operation
2. Getting Started Hotkey for Specific Functions Physical buttons with its dedicated functions can also be used to emulate commonly used keyboard keystrokes. Under a different scenario, a single physical button or a combination of physical buttons provide different keyboard keystrokes, which are specified below: In POST (before Windows boots up): In Windows: Buttons... - Page 14 Rugged Tablet PC M140TG Quick Start Guide Charging Your Tablet The tablet operates either on external AC power or internal battery power. It is recommended to use AC power when you start up the tablet for the first time. Caution Use only the AC adapter included with your Tablet Computer. Using other AC adapters may damage the Tablet Computer and the Battery.
-
Page 15: Charging Your Tablet
Charging Your Tablet The tablet operates either on external AC power or internal battery power. It is recommended to use AC power when you start up the tablet for the first time. Caution Use only the AC adapter included with your Tablet Computer. Using other AC adapters may damage the Tablet Computer and the Battery. -
Page 16: Appendix A: Product Specifications
Rugged Tablet PC M140TG Quick Start Guide Appendix Appendix A: Product Specifications M140TG / M140TGT Model Name Size 14 inches Resolution 1920 x 1080 Brightness 700 nits Display Contrast Ratio 800:1 Viewing Angle 85,85,85,85 Touch Projected Capacitive Multi-Touch Bonding Optical Bonding for Sunlight Viewability Processor Intel Core i51135G7 @ 2.40GHz, up to 4.20GHz... - Page 17 1. Accessories and Integrated Options may vary depending on your configuration. The product shown in this document is a standard model. For diagrams that contain customized or optional I/O, please contact the Winmate Sales Team for more information. 2. All specifications are subject to change without prior notice.
- Page 18 US Inc Service : Winmate Communication US Inc. 2640 Mathews Street, Smyrna, GA 30080 Tel : +1-678-653-8800 Winmate Inc. 9F, No.111-6, Shing-De Rd., San-Chung District, New Taipei City 24158, Taiwan, R.O.C www.winmate.com Copyright © 2022 Winmate Inc. All rights reserved.
