- Page 1 BK-EX100C-K USB-C to HDMI Extender Follow us on Youtube and Facebook over CAT6 up to 100ft at 4K 120Hz www.orei.com USE R M A N UA L page 1...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents Specifications Operation Control & Functions Application Example FAQs & Troubleshooting Thank you for purchasing this product For optimum performance and safety, please read these instructions care- fully before connecting, operating or adjusting this product. Please keep this manual for future reference. -
Page 3: Registration Page
Registration Page Please Activate your warranty by registering our product through the link below - www.orei.com/register Technical Support Need Help? Our experienced Technical Support Team is here for you to answer your questions, give technical advice or help troubleshoot your project to get you installed on time and on budget. Call, email or chat with us now. -
Page 4: Introduction
Introduction The BK-EX100C-K is a USB C to HDMI Extender that transmits media signals from your laptop or PC to a distant HDMI display. It supports video resolutions up to 4K@120Hz and extends the signal up to 100 feet over a CAT 6/7 cable. -
Page 5: Features
7. DP 1.4 Alt Mode support 8. Uncompressed LPCM audio and compressed DTS and Dolby Digital including Dolby TrueHD and DTS-HD Master Audio 9. No drivers or software needed Package Contents BK-EX100C-K 1pcs USB-A to USB-C Power Cable 1pcs User Manual... -
Page 6: Specifications
Specifications Technical HDCP Compliance HDCP 2.3 HDMI Compliance HDMI 2.1 Video Bandwidth 8Gbps per channel (32Gbps all channels) Video Resolution 480p,576p,720p,1080p,4K@60Hz/120Hz Color Space 4:4:4/4:2:2/4:2:0 Color Depth 8/10/12 bit LPCM/DTS/Dolby Digital/DTS-HD Master Audio™ / Audio Formats Dolby TrueHD HDR10 Contact discharge (±4KV), air discharge (±8kv),lmple- ESD Protection mentation of the standard: IEC61000-4-2 Connection... - Page 7 Specifications Mechanical Housing Aluminium Alloy + ABS Color Black Transmitter: L: 93.4mm / 3.67in W: 34mm / 1.33in H: 15mm / 0.59in Dimensions Receiver: L: 72.5mm / 2.85in W: 34mm / 1.33in H: 15mm / 0.59in Weight 156g / 5.5oz Power Supply FCC, CE, RoHS Power Consumption...
-
Page 8: Operation Control & Functions
Operation Control & Functions Page 08... - Page 9 Operation Control & Functions Name Function Description USB-C Connect a Laptop or PC with a USB C port Connect a CAT 6/7 cable. The other end connects to RJ45 OUT the Receiver. Connect a CAT 6/7 cable. The other end connects to RJ45 IN the Transmitter.
-
Page 10: Application Example
Application Example USB-C to HDMI Extender over CAT6 up to 100ft at 4K 120Hz BK-EX100C-K Receiver USB-C to HDMI Extender over CAT6 up to 100ft at 4K 120Hz BK-EX100C-K Sender Page 10... -
Page 11: Faqs & Troubleshooting
FAQs & Troubleshooting 1. Video keeps flickering or no video Try changing the CAT cable Try changing the HDMI cable Try lowering the resolution from the laptop or PC 2. The display does not get audio Try changing the audio format from the laptop or PC Try changing the CAT cable Most laptops output audio from the laptop speakers only. - Page 12 USB-C to HDMI Extender over CAT6 up to 100ft at 4K 120Hz BK-EX100C-K www.orei.com © 2024 page 12...
