- Page 1 ARC-EX300-K HDMI ARC & S/PDIF Audio Extender Follow us on Youtube and Facebook (150m) over CAT Cable U S E R M A N U A L www.orei.com page 1...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions Application Example Thank you for purchasing this product Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operat- ing or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be dam- aged by electrical spikes, surges, electric shock, lightning strikes, etc. - Page 3 Registration Page Please Activate your warranty by registering our product through the link below - https://www.orei.com/pages/warranty-registration Technical Support Need Help? Our experienced Technical Support Team is here for you to an- swer your questions, give technical advice or help troubleshoot your project to get you installed on time and on budget.
-
Page 4: Introduction
Introduction The ARC-EX300-K can transmit HDMI ARC and S/PDIF audio signals up to a distance of 150m/492ft (96kHz) or 90m/295ft (192kHz) over a single CAT cable. CEC pass-through between HDMI ARC input port and ARC output port. For TVs without an... -
Page 5: Features
Supports PCM 2.0ch, Dolby 5.1ch, DTS 5.1ch audio formats. CEC pass-through when HDMI ARC mode is enabled Plug-and-play Small compact size Ultra-low jitter and high-fidelity design Package Contents ARC-EX300-K (Transmitter) 1pcs ARC-EX300-K (Receiver) 1pcs USB Shielded Cable (USB-A to Micro USB, 1m) 2pcs 5V/1A Power Adapter... -
Page 6: Specifications
Specifications Technical Supported PCM 2.0ch, Dolby 5.1ch, DTS 5.1ch Audio Formats Transmission ARC audio: 150m/495ft - 96kHz, 90m/295ft - 192kHz Distance and S/PDIF audio: 150m/495ft - 96kHz Sample Rates Human-body Model: ±8kV (Air-gap discharge) , ESD Protection ±4kV (Contact discharge) Connection 1 ×... -
Page 7: Operation Controls And Functions
Operation Controls and Functions Transmitter CAT OUT S/PDIF IN ARC IN DC 5V S/PDIF Name Function Description When the Transmitter is powered on, the red power Power LED LED will be on. Use this switch to select audio pass-through channel. Switch to “S/PDIF”: The S/PDIF OUT port outputs the S/PDIF optical audio from the S/PDIF IN port of the transmitter. - Page 8 Operation Controls and Functions Receiver CAT IN S/PDIF OUT ARC OUT DC 5V Name Function Description When the Receiver is powered on, the red power LED Power LED will be on. Connect to the CAT OUT port of the transmitter with a CAT IN CAT6 cable.
-
Page 9: Application Example
Application Example Situation 1: ARC Mode S/PDIF Transmitter CAT OUT S/PDIF IN ARC IN DC 5V USB Power Cable CAT6 cable TV with ARC feature CAT IN S/PDIF OUT ARC OUT DC 5V Receiver USB Power Cable Soundbar page 09... - Page 10 Application Example Situation 2: S/PDIF Pass-through Mode S/PDIF Transmitter CAT OUT S/PDIF IN ARC IN DC 5V USB Power Cable CAT6 cable CAT IN S/PDIF OUT ARC OUT DC 5V Receiver USB Power Cable Amplifier The terms HDMI and HDMI High-Definition Multimedia interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
- Page 11 HDMI ARC & S/PDIF Audio Extender (150m) over CAT Cable ARC-EX300-K www.orei.com © 2023 page 11...
