- Page 1 UHD-EXB330CU-K Follow us on Youtube and Facebook 4K HDMI/USB-C KVM Extender Over HDBaseT 3.0 US ER M ANUA L www.orei.com...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions IR Pin Definition API Commands Application Example FAQs & Troubleshooting Thank you for purchasing this product Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. -
Page 3: Registration Page
Registration Page Please Activate your warranty by registering our product through the link below - www.orei.com/register Technical Support Need Help? Our experienced Technical Support Team is here for you to answer your questions, give technical advice or help troubleshoot your project to get you installed on time and on budget. -
Page 4: Introduction
Introduction The UHD-EXB330CU-K HDMI extender is a versatile gadget that can send uncompressed audio-video signals up to 330 feet with just a single CAT 6/6A/7 cable. It features support for video resolutions up to 4K@60Hz. The device also features a USB-C input, which makes it compatible with the latest laptops and other devices. -
Page 5: Features
10. Analog audio output on both ends for Audio Extraction 11. Each USB-A port provides power up to 5V/500mA 12. Power over Cable technology for easy and flexible installation Package Contents UHD-EXB330CU-K Transmitter 1pcs UHD-EXB330CU-K Receiver 1pcs IR Blaster Cable (1.5m) 1pcs IR Wideband Receiver Cable (1.5m) -
Page 6: Specifications
Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.3 USB Compliance USB 2.0 Video Bandwidth 18Gbps Video Resolution Up to 4K@60Hz 4:4:4 Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0 Color Depth 8/10/12 bit IR Level 12Vp-p IR Frequency Wideband 20K-60KHz HDR, HDR10, HDR10+, Dolby Vision, HLG HDMI/USB-C/HDBT:... - Page 7 Specifications Connection Input: 1 × HDBaseT IN [RJ45, 8-pin female] Output: 1 × HDMI OUT [Type A, 19-pin female] 1 × L/R OUT [3.5mm Stereo Mini-jack] Control: 1 × IR IN [3.5mm Stereo Mini-jack] Receiver 1 × IR OUT [3.5mm Stereo Mini-jack] 1 ×...
-
Page 8: Operation Controls And Functions
Operation Controls and Functions Transmitter Panel SERVICE LINK USB-C HDMI MODE EDID SELECT 2 3 4 HDBaseT OUT HDMI IN USB-C IN USB HOST L/R OUT IR IN IR OUT RS-232 DC 24V ON OFF Name Function Description The LED will light up Red when the Transmitter is powered Power LED ▪... - Page 9 Operation Controls and Functions Name Function Description Used to switch HDBT mode. Switch to "STD": The HDBT Standard Mode (as factory default) is enabled, it can extend 4K60/4K30/1080P signal between MODE the transmitter and the receiver up to 100m via a single switch CAT6A/7 cable.
- Page 10 Operation Controls and Functions Name Function Description ▪ Light on: Transmitter and receiver are in good connection Link Signal status. Indicator ▪ Light flashing: Transmitter and receiver are in poor (Green) connection status. ▪ Light off: Transmitter and receiver are not connected. Connect a media source device such as a DVD Player, set-top 13.
-
Page 11: Operation Controls
Operation Controls and Functions Rear Panel IR IN IR OUT SERVICE LINK HDBaseT IN HDMI OUT L/R OUT RS-232 DC 24V ON OFF Name Function Description The LED will light up Red when the Transmitter is powered Power LED ▪ Light on: Transmitter and receiver are in good connection status. - Page 12 Operation Controls and Functions Name Function Description HDBaseT Connect a CAT6/7 cable. The other end connects to the Transmitter HDBaseT OUT. ▪ Light on: There is video signal transmission with HDCP Data Signal encryption. Indicator ▪ Light flashing: There is video signal transmission without (Yellow) HDCP encryption.
-
Page 13: Ir Pin Definition
IR Pin Definition IR Receiver and Blaster pin’s definition as below: IR BLASTER IR BLASTER IR RECEIVER IR Signal Grounding IR RECEIVER Power 12V Note: When the angle between the IR receiver and the remote control is ± 45 °, the transmission distance is 0-5 meters; when the angle between the IR receiver and the remote control is ±... -
Page 14: Api Commands
API Commands The product also supports API commands control. Connect the RS- 232 port of the product to a PC or control system with a 3-pin phoenix connector cable, or connect the SERVICE port of the product to a PC with a Micro USB cable. - Page 15 API Commands Command Code Function Description Example Feedback Default Get the firmware r fw version r fw version TX 1.0.0 RX 1.0.0 version Reboot… System Initializing... s reboot Reboot the device s reboot Initialization Finished! TX 1.0.0 RX 1.0.0 Sure to RESET to default Reset to factory s reset s reset...
- Page 16 API Commands Command Code Function Description Example Feedback Default r tx r tx autoswitch Get TX auto-switching autoswitch TMDS mode mode status mode Set RX downscaling mode, x= AUTO: automatically s rx s rx downscale according to display's downscale Set rx downscale AUTO AUTO capability AUTO ON: force 4K to 1080p...
- Page 17 API Commands Command Code Function Description Example Feedback Default Set input ports EDID x = USBC, HDMI, ALL 00 - EDID dip switch (default) 01 - 1920x1080@60 8bit Stereo 02 - WUXGA 1920x1200 03 - 1920x1080@60 8bit High Definition Audio 04 - 3840x2160@60Hz Set edid 4:2:0 Deep Color Stereo Audio...
-
Page 18: Application Example
Application Example Keyboard Printer Mouse SERVICE LINK USB-C HDMI SELECT MODE EDID Transmitter HDBaseT OUT HDMI IN USB-C IN USB HOST L/R OUT IR IN IR OUT RS-232 DC 24V HDMI Matrix with RS-232 function Laptop 2 (with Speakers USB-C port) IR Blaster IR Receiver PC or... - Page 19 Application Example Connection Instructions: - 1. Connect the HDMI output from the media source(DVD Player, set-top box, PC) to the Transmitter HDMI IN. 2. Connect the HDMI input port from the TV or monitor to the Receiver HDMI OUT. 3. Connect both devices with a CAT6/6A/7 cable. 4.
-
Page 20: Faqs & Troubleshooting
FAQs & Troubleshooting No Video Output from the Receiver End Try the following: 1. Check if the Power and Link indication LEDs are lighting on both ends 2. Change the HDMI cable going to the display 3. Change the CAT cable 4. - Page 21 FAQs & Troubleshooting How can I upgrade the firmware? You can upgrade the firmware by connecting the PC & this device via a Micro-USB cable. Check the ‘Downloads’ section on the product page on the website for firmware updates. What types of HDMI & CAT cables I should use with this product? We recommend you to use High-Quality HDMI cables under 30 feet&...
- Page 22 4K HDMI/USB-C KVM Extender Over HDBaseT 3.0 UHD-EXB330CU-K www.orei.com © 2023...
