Mitchell Mounting Plate (P-MTCL-RGCL)
A s s e m b l y M a n u a l
What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
1 x L-Type Allen Key
Mitchell Mounting Plate
(Size:6mm)
(with 4 Screws Included)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
Advertisement
Related Manuals for PROAIM P-MTCL-RGCL
Summary of Contents for PROAIM P-MTCL-RGCL
- Page 1 Mitchell Mounting Plate (P-MTCL-RGCL) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
- Page 2 Mitchell Mounting Plate Setup Mitchell Mounting Plate Assembly • Remove all screws from the Mitchell mounting plate using a 6mm Allen key. • Remove the Castle ring from the SJ30 Scissor Crane (Not included). • Attach the Mitchell Mounting Plate to the SJ30 Scissor Crane.
- Page 3 • Insert all screws, aligning them with their holes. • Tighten all the screws using a 6mm Allen key to ensure they are securely fastened. Feature: This plate features four screw holes and comes with included screws for a secure attachment.
- Page 4 YOUR PROAIM MITCHELL MOUNTING PLATE ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
