PROAIM P-MNRL-01 Assembly Manual

Polaris - monorail camera slider dolly

Download this manual

Polaris - Monorail Camera Slider Dolly

(P-MNRL-01)

A s s e m b l y M a n u a l

What's In The Box

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

2 x Pipe Support Clamps

Rig Wheels Monorail Carriage Kit

with Two Pipe Clamps

2 x Button Heads

2 x Allen Keys

2 x Allen Bolts

Mounting Bar

(Size: M8 x 16mm)

(Size: 3/16"-5mm)

(Size: 1/4 x 3/8")

No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright

statutes or in writing by the Publisher.

Need help?

Do you have a question about the P-MNRL-01 and is the answer not in the manual?

Page 1 Polaris - Monorail Camera Slider Dolly (P-MNRL-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
Page 2 Polaris - Monorail Camera Slider Dolly Setup Monorail Dolly Assembly • Attach the rig wheels to the mounting bar . • Insert the button head screw (M8x16mm) through the aligned hole. • Next, tighten the button head screw using a 3/16”...
Page 3 Mounting Quick Release Camera Plate on Monorail Dolly • Mount the quick release plate (not included) onto the monorail dolly. • Align the holes and insert the Allen bolts (1/4x3/8”). Feature: The mounting plate includes multiple threaded free holes various configurations, with included screws ensuring a secure and easy attachment.
Page 4 • Slide the dolly onto the speed rail, ensuring it is properly aligned. Feature: The included pipe clamps ensure a secure and stable setup, allowing the carriage to glide seamlessly along the track with wheels that feature sealed bearings for reduced friction and smooth movements.
Page 5 YOUR PROAIM MICROTILT WEDGE CAMERA PLATE ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
