NOTICE: Please check contents of package for any damage and make sure all parts fit correctly
and you are happy with the product before removing protective film. Once the film is removed you
cannot return the product for a full refund.
Be sure to read these instructions thoroughly before opening and installing the Textron Stampede 4 Aero-
Vent Polycarbonate Windshield.
Check over the parts included in the cartons with the parts list shown below:
1.
Velcro Strap Clamps
1" Bolts
1 ¾" Hex Head Bolts
Lock Nuts
Nylon Spacers
Small Washers
Plastic Thumb Nuts
Slide Fasteners
48" End Bulb Rubber Gasket
Vent Sliders
Lexan Windshield
If any parts are damaged or missing please contact customer service at (606) 845-7439.
Start by pulling it out of the box, find a clean area to lay it down, and install the hardware. Begin by
2.
peeling off the protective film. Next take the 48" piece of rubber gasket and starting at one end firmly
place along entire bottom edge of the Windshield as shown in the photo below.
2515 Bypass Rd. Flemingsburg, KY 41041
Instructions for Installation and Care of Textron Stampede 4
Aero-Vent Polycarbonate Windshield
TX-STAMP-4-WD05
606-845-7439
4 each
2 each
2 each
2 each
4 each
2 each
2 each
10 each
1 each
2 each
1 each
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for FALCON RIDGE TX-STAMP-4-WD05
Summary of Contents for FALCON RIDGE TX-STAMP-4-WD05
- Page 1 Instructions for Installation and Care of Textron Stampede 4 Aero-Vent Polycarbonate Windshield TX-STAMP-4-WD05 NOTICE: Please check contents of package for any damage and make sure all parts fit correctly and you are happy with the product before removing protective film. Once the film is removed you cannot return the product for a full refund.
- Page 2 Next prepare the vent slider to be installed on the windshield. Take the two hex head bolts, 4 nylon spacers and two lock nuts and attach them to the vent sliders as shown in the photo below. Take the spacers and slide two of them over the bolt as shown below...
- Page 3 Now insert the bolt in the small holes and screw on the lock nuts so the end of the bolt is flush with the outside edge of the lock nut. Make sure that you place the bolt through hole on each slider so that they are mirror images of each other.
- Page 4 Then take the four Velcro clamps and place them through the square holes then wrap the strap around the roll cage and under the wire as shown in the photo below. Then just Pull the strap back around the bar and attach it to the Velcro. Next attach the two loom clamps along the top of the windshield as shown in the diagram and photo on the next page.
- Page 5 Now you are ready to take it out and enjoy. To clean the windshield, always clean using a liquid of some sort to decrease the chance of scratches. We recommend using micro fiber cloths that are readily available at any dollar store. Any window cleaner will work fine; just remember to use a soft clean rag or micro-fiber cloth to clean it.
-
Page 6: Return Policy
Any returns submitted to Falcon Ridge without a return authorization number will be charged a 20% restocking fee. If ordered from one of Falcon Ridge’s many distributors, you must first call them and see what their return policy is. Once your item reaches our production facility, our customer satisfaction team will inspect your item to ensure unused, factory new condition.
