2019 CF Moto Z Force 800/1000 Soft Door Rear Window Combo
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
Be sure to read these instructions thoroughly before opening and installing. The installation is best done
when the temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if conditions
prevent installing in warmer weather it helps to store the adhesive Velcro at room temperature prior to
installation.
1. Carefully open the carton and remove the enclosure on a large flat surface that is clean and free of dirt.
2. Check over the parts included in the carton with the parts list shown below:
Adhesive Velcro Hook Strips:
"
Snap Screw Studs
---------------------------------------------------------------------------
Adhesive Velcro Hook Strips:
"
"
Snap Screw Studs
If any parts are damaged or missing please contact customer service at (800) 213-7981.
The cab for you Z-Force is made up of 3 different components that work together to enclose your vehicle.
Install the cab in the following order.
1) Soft Doors
2) Rear Window
Soft Doors:
1. Begin by holding the door up to the frame and attach it using the double-sided Velcro strips sewn
perpendicular to the edge of the door. At each of the double-sided strips take one of the 3" adhesive
Velcro strips and adhere it to the inside of the frame. Then wrap the double-sided strip around it so that
the adhesive strip holds it firmly in place. The following diagrams show how it should look.
3510-1 Port Jacksonville Pkwy, Jacksonville, FL 32226
800-213-7981
Instructions for Installation and Care of
CF-19-Z-DRW01
"
"
"
"
"
"
"
"
"
Soft Doors
24 each------------3"
20 each ( 2 extra )
Rear Window
1 each------------18"
2 each------------20"
4 each
