User Manual
Ikargo1 Transmitter
Charger and battery
BC70K Charger LEDs Status
Battery Charging Recommendations
©
12 | Danfoss | January 2025
1. Connect the charger to a power source using the provided power supply.
The red LED will switch on if the charger is properly connected.
2. Place the batteries on the charger.
3. Optional: When charging two batteries, wait at least five seconds before inserting the second battery
into the compartment.
W
Warning
Possible damage to battery.
The Battery Charger must be installed in a dry/interior environment. Make sure to charge batteries in
environments with temperatures over 0°C.
The BC70K charger has a LED for each compartment (BAT 1 and BAT 2) and a common indicator
(POWER).
LED color / frequency
Green LED / pulsing (BAT 1, BAT 2)
Green LED / continuous (BAT 1, BAT 2)
Red LED / pulsing or continuous (BAT 1, BAT 2)
Red LED / continuous (POWER)
Charge the battery fully before use. This ensures that the battery's full capacity will be available. The
battery lifespan is estimated to 500 recharging cycles and is largely dependent on the conditions of use.
To maximize the lifespan of the batteries and battery charger, follow these recommendations:
•
Do not recharge the battery until it is completely flat, as shown with red LED slow pulse on the
transmitter
•
Always charge the batteries at temperatures between 0° and 45°C (the batteries will not become fully
charged at temperatures exceeding 45°C)
•
Do not leave the battery charger or batteries in a direct sunlight
•
Charge batteries at least once every three months
•
Make the charge of at least 40% of the full charge.
•
Ideal Battery storage temperature should be between 15ºC and 25ºC.
•
Avoid short circuits between the battery contacts; do not carry charged batteries in toolboxes or next
to other metal objects (keys, coins, etc.)
•
Always keep contacts clean
•
Caution! Risk of Explosion if Battery is Replaced by an incorrect type. Non Danfoss Battery use may
void warranty
Description
The battery is being charged
The battery is completely charged
The battery charger fault
The charger is properly connected to power source
