- Page 1 Infant Scale USER MANUAL MS4400I Please keep the instruction manual at hand and follow instruction for use.
-
Page 2: Table Of Contents
CONTENTS I. Explanation of Graphic Symbols on Label/Packaging 3 II. Copyright Notice ............5 III. Safety Notes ............6 A. General Information ..........6 B. EMC Guidance and Manufacturer's Declaration ... 9 IV. Installation .............. 13 A. Adjusting footrests ..........13 B. -
Page 3: Explanation Of Graphic Symbols On Label/Packaging
I. Explanation of Graphic Symbols on Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 4 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)
-
Page 5: Copyright Notice
Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. Charder reserves the right to correct misprints in the manual without prior notice, and modify the exterior of the device for quality purposes without customer consent. -
Page 6: Safety Notes
III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. - Page 7 (b) Minimum knowledge: - To be able to read at a high-school level and understand Arabic numerals (e.g. 1, 2, 3, 4...) - Basic hygiene knowledge - Trained in device's operation - Read the instruction manual (c) Language - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required...
-
Page 8: Maintenance
Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty. -
Page 9: Emc Guidance And Manufacturer's Declaration
B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic... - Page 10 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity IEC 60601 Compliance Electromagnetic test Test level level...
- Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance Electromagnetic level level...
- Page 12 Recommended separation distance between portable and mobile RF communications equipment and the product The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help preventelectromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximum output power of the communications equipment.
-
Page 13: Installation
IV. Installation A. Adjusting footrests Device does not require assembly, and can be used once batteries have been inserted, and S-hook and sling are attached. B. Inserting Batteries 1. Locate battery cover on bottom of device. Open cover, and remove battery case from device. -
Page 14: Key Functions And Indicator
V. Key Functions and Indicator Key Functions 1. ON/OFF/ZERO: Turn device on and off. Zero scale (± 2% of full capacity). Press and hold to turn off device. 2. HOLD: Determine stable weighing value - should be used when weight is unstable. 3. -
Page 15: Getting Started
VI. Getting Started Inspection before use 1. Confirm hook and sling are in good condition and undamaged 2. Clear and remove any sharp objects in area to ensure safety of infant 3. We recommend placing a cushion under the sling before weighing for comfort and safety... -
Page 16: Using Device
VII. Using Device A. Correct usage 1. Lay sling upon table and 2. Carefully place infant upon spread out evenly sling 3. Hook S-hook onto device 4. Hook s-hook onto sling. S-hook should now be hooked to both device and sling. 5. - Page 17 6. Carefully lift device with both hands until baby no longer touches table. After weight has stabilized, the reading on the indicator will flash. This means the result has been locked. Device should be carefully lowered until infant is safely placed back upon table. Note: If infant's weight exceeds scale capacity (including tare), indicator will display "Err"...
-
Page 18: Tare
B. Tare The tare function allows the user to deduct the weight of objects from the device's measurement result. Tare can be used when weight of object is ≧at/above 2% of max capacity. 1. Place object that needs to be tared onto sling. Lift sling from ground until weight is displayed on indicator. -
Page 19: Incorrect Usage Examples
D. Incorrect usage examples Using device with one hand Thumbs not properly supporting device weight. Thumbs should be wrapped around "neck" of device. -
Page 20: Wireless Connection
Warranty Program & Return Policy. 1. If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit. - Page 21 Relocate device to location without interference and try again Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key ◼...
-
Page 22: Error Messages
Error Messages Error Message Reason Action Low battery warning Voltage of battery is Replace batteries too low to operate device Overload Reduce weight on Total load exceeds measurement platform device's maximum and try again capacity Counting Error (too Error normally caused high) by faulty loadcell or Signal from loadcells... -
Page 23: Product Specifications
X. Product Specifications Device Information Model MS4400I Capacity 10 kg x 10g 15 kg x 20g Accuracy ± 1.5e Weight Measurement LCD Screen 1.0-inch LCD screen (5 digits) OIML Class III Device 105(W) x 79(D) x 193(H) mm Dimensions Device 0.4 kg... -
Page 24: Declaration Of Conformity
XI. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
