CP0576
FITTING INSTRUCTIONS FOR CP0576 CRASH PROTECTORS
T
.
HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE
S
.
OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY
D
.
O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT
P
.
LEASE READ ALL INSTRUCTIONS BEFORE PROCEEDING
IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF OUR DEALERS
OR HAVE FITTED BY A QUALIFIED TECHNICIAN.
P
LEASE NOTE THAT THE WAY THE KIT IS PACKED DOES NOT NECESSARILY REPRESENT THE WAY OF
.
MOUNTING TO THE BIKE
I
,
N THE EVENT OF RUBBER WASHERS BEING USED TO HOLD COMPONENTS ONTO BOLTS
.
THESE RUBBER WASHERS CAN BE THROWN AWAY
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM:
WWW.RG-RACING.COM
R&G Racing Unit 1, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: +44 (0)1420 89007
www.rg-racing.com
Email:
info@rg-racing.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for R&G CP0576
Summary of Contents for R&G CP0576
- Page 1 Page 1 of 15 CP0576 FITTING INSTRUCTIONS FOR CP0576 CRASH PROTECTORS HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT...
-
Page 2: Tools Required
Page 2 of 15 CP0576 TOOLS REQUIRED GENERAL TORQUE SETTINGS Socket set M4 BOLT = 8Nm • • Torx Set M5 BOLT = Ratchet • Torque wrench (up to 50Nm). • M6 BOLT = M8 BOLT = 20Nm 0 BOLT = 40Nm... - Page 3 Page 3 of 15 CP0576 EXPLODED ASSEMBLY VIEW LHS EXPLODED ASSEMBLY VIEW RHS R&G Racing Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 www.rg-racing.com Email: info@rg-racing.com...
- Page 4 Page 4 of 15 CP0576 FITTING PICTURES PICTURE 1 PICTURE 2 PICTURE 3 R&G Racing Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 www.rg-racing.com Email: info@rg-racing.com...
-
Page 5: Fitting Instructions
Page 5 of 15 CP0576 PICTURE 4 PICTURE 5 PICTURE 6 FITTING INSTRUCTIONS 1. Remove the LHS and RHS fairing panels and connecting belly pan piece from the bike. 2. Before removing engine bolts, ensure the bike is upright and supported by a suitable engine stand or jack placed under the sump of the motorbike to support the partial weight of the engine, this will prevent the engine from moving during fitting. - Page 6 Page 6 of 15 CP0576 4. Ensuring the engine is fully supported, remove the 2xM10 engine bolts. The front mount is secured by a nut on the inside of the frame behind the radiator which will need to be secured during removal of the bolt.
-
Page 7: Right Hand Side
Page 7 of 15 CP0576 RIGHT HAND SIDE 18. Referring to the RHS assembly Diagram, repeat the process for the RHS using the remaining crash protector (item 5) washer (item 16) and Anti-rotation washer (item 17) over the M10x70mm hex head bolt (item 14) referring to Picture 4 and using the RHS assembly diagram. - Page 8 Page 8 of 15 CP0576 NOTICE DE MONTAGE CP0576 PROTECTIONS CRASH E KIT CONTIENT LES ARTICLES ILLUSTRES ET ETIQUETES SUR LA PAGE ERTAINES PARTIES PEUVENT ETRE PRESENTES UNIQUEMENT POUR LA CLARTE DES INSTRUCTIONS E PAS PROCEDER AU MONTAGE TANT QUE VOUS N...
-
Page 9: Outils Requis
Page 9 of 15 CP0576 OUTILS REQUIS VALEURS DE SERRAGE Jeu de douilles M4 BOULON = 8Nm • • Jeu de clés Torx M5 BOULON = 12Nm Cliquet • Clé dynamométrique (jusqu'à 50 Nm). • M6 BOULON = 15Nm M8 BOULON = 20Nm... - Page 10 Page 10 of 15 CP0576 SCHÉMA D’ENSEMBLE CÔTÉ GAUCHE SCHÉMA D’ENSEMBLE CÔTÉ DROIT R&G Racing Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 www.rg-racing.com Email: info@rg-racing.com...
- Page 11 Page 11 of 15 CP0576 PHOTOS DE MONTAGE PHOTO 1 PHOTO 2 PHOTO 3 R&G Racing Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 www.rg-racing.com Email: info@rg-racing.com...
- Page 12 Page 12 of 15 CP0576 PHOTO 4 PHOTO 5 PHOTO 6 NOTICE DE MONTAGE 1. Retirez les panneaux de carénage gauche et droit et la pièce de raccordement du carter inférieur de la moto. 2. Avant de retirer les boulons du moteur, assurez-vous que la moto soit en position verticale et soutenue par un support moteur ou un cric approprié...
- Page 13 Page 13 of 15 CP0576 3. Une fois le moteur soutenu comme indiqué sur la photo 1, présentez le bloc de support gauche (article 1) et localisez les boulons du moteur à retirer également entourés sur la photo 1. 4. Assurez-vous que le moteur soit entièrement soutenu, retirez les 2 boulons du moteur M10. Le support avant est fixé...
-
Page 14: Côté Droit
Page 14 of 15 CP0576 (article 17) et placez cet ensemble à travers la protection crash (article 8) de sorte que la tête du boulon se trouve dans le renfoncement de la protection crash. 2. Faites glisser l'entretoise de protection crash côté gauche de 54 mm (article 5) sur l'ensemble de la protection crash et fixez-la au support de montage côté... - Page 15 Page 15 of 15 CP0576 its liability shall be limited to the amounts paid by the Buyer for the Products or the fitting or service concerned. These terms do not affect the Buyer’s statutory rights. R&G RACING RETURNS POLICY (NON-FAULTY GOODS) Returns must be pre-authorised (if not pre-authorised the return will be rejected).
