CP0534
FITTING INSTRUCTIONS FOR CP0534 AERO CRASH PROTECTORS
KTM 390 ADVENTURE 2020-
T
.
HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE
S
.
OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY
D
.
O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT
P
.
LEASE READ ALL INSTRUCTIONS BEFORE PROCEEDING
IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF OUR DEALERS
OR HAVE FITTED BY A QUALIFIED TECHNICIAN.
P
LEASE NOTE THAT THE WAY THE KIT IS PACKED DOES NOT NECESSARILY REPRESENT THE WAY OF
.
MOUNTING TO THE BIKE
I
,
N THE EVENT OF RUBBER WASHERS BEING USED TO HOLD COMPONENTS ONTO BOLTS
.
THESE RUBBER WASHERS CAN BE THROWN AWAY
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM:
WWW.RG-RACING.COM
R&G Racing
Unit 1, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ
Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301
www.rg-racing.com
Email:
info@rg-racing.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for R&G CP0534
Summary of Contents for R&G CP0534
- Page 1 Page 1 of 15 CP0534 FITTING INSTRUCTIONS FOR CP0534 AERO CRASH PROTECTORS KTM 390 ADVENTURE 2020- HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT...
-
Page 2: Tools Required
Page 2 of 15 CP0534 TOOLS REQUIRED GENERAL TORQUE SETTINGS M4 BOLT = 8Nm SOCKET & WRENCH SET INCLUDING 15mm and • M5 BOLT = 12Nm 17mm SOCKETS. M6 BOLT = 15Nm ALLEN KEY SET INCLUDING 4,5 & 6mm. •... - Page 3 Page 3 of 15 CP0534 LHS & RHS EXPLODED ASSEMBLY VIEW FITTING PICTURES Picture 1 Picture 2 Picture 3 Picture 4 R&G Racing Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com...
- Page 4 Page 4 of 15 CP0534 Picture 5 Picture 6 Picture 7 Picture 8 Picture 9 Picture 10 R&G Racing Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
-
Page 5: Fitting Instructions
Page 5 of 15 CP0534 FITTING INSTRUCTIONS Begin by removing the lower bolt on the inside of the radiator shroud with a 4mm Allen key as • shown in Picture 1. Remove the upper bolt as shown in Picture 2. - Page 6 Page 6 of 15 CP0534 NOTICE DE MONTAGE POUR CP0534 AERO PROTECTIONS CRASH KTM 390 ADVENTURE 2020- E KIT CONTIENT LES ARTICLES ILLUSTRES ET ETIQUETES SUR LA PAGE ERTAINES PARTIES PEUVENT ETRE PRESENTES UNIQUEMENT POUR LA CLARTE DES INSTRUCTIONS E PAS PROCEDER AU MONTAGE TANT QUE VOUS N...
-
Page 7: Outils Requis
Page 7 of 15 CP0534 OUTILS REQUIS VALEURS DE SERRAGE M4 BOULON = 8Nm CLÉ À CLIQUET + DOUILLES 15mm & 17mm. • M5 BOULON = CLÉS ALLEN 4,5 & 6mm. • M6 BOULON = CLÉ DYNAMOMÉTRIQUE (À 40Nm) •... - Page 8 Page 8 of 15 CP0534 VUE D’ENSEMBLE CÔTÉ GAUCHE ET DROIT PHOTOS DE MONTAGE Photo 1 Photo 2 R&G Racing Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email:...
- Page 9 Page 9 of 15 CP0534 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 R&G Racing Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com...
-
Page 10: Notice De Montage
Page 10 of 15 CP0534 NOTICE DE MONTAGE Commencez par retirer le boulon inférieur à l'intérieur du carénage de radiateur avec une clé • Allen de 4 mm comme indiqué sur la photo 1. Retirez le boulon supérieur comme indiqué sur la photo 2. - Page 11 Page 11 of 15 CP0534 MONTAGEANLEITUNG FÜR CP0534 AERO STURZPADS KTM 390 ADVENTURE 2020- EILE SIND AUF DEN NACHFOLGENDEN EITEN ABGEBILDET UND GEKENNZEICHNET IE ABGEBILDETEN EILE DIENEN LEDIGLICH ZUR RKLÄRUNG Ü BERPRÜFEN IE ZUERST DASS ALLE EILE VORHANDEN SIND ESEN...
- Page 12 Page 12 of 15 CP0534 SIE BENÖTIGEN FOLGENDES WERKZEUG ALLGEM. ANZUGSDREHMOMENT M4 SCHRAUBE = 8Nm STECKSCHLÜSSEL-SATZ INKL. 15mm und • M5 SCHRAUBE = 17mm STECKSCHLÜSSEL M6 SCHRAUBE = SATZ INBUSSCHLÜSSEL INKL. 4,5 & 6mm • M8 SCHRAUBE = 20Nm DREHMOMENTSCHLÜSSEL (BIS 50Nm) •...
- Page 13 Page 13 of 15 CP0534 ZUSAMMENBAU LINKE & RECHTE SEITE - EXPLOSIONSZEICHNUNG MONTAGE - ABBILDUNGEN Abbildung 1 Abbildung 2 Abbildung 3 Abbildung 4 R&G Racing Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com...
- Page 14 Page 14 of 15 CP0534 Abbildung 5 Abbildung 6 Abbildung 7 Abbildung 8 Abbildung 9 Abbildung 10 R&G Racing Unit 1, Shelley’s Lane, East Worldham, Alton, Hampshire, GU34 3AQ Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301 www.rg-racing.com Email: info@rg-racing.com...
- Page 15 Page 15 of 15 CP0534 MONTAGEANLEITUNG Entfernen Sie zuerst die untere Schraube an der Innenseite der Kühlerverkleidung mit einem • 4mm Inbusschlüssel wie in Abbildung 1 abgebildet. Entfernen Sie die obere Schraube wie in Abbildung 2 abgebildet. • • Das schwarze Verkleidungsteil, welches als unterste Teil der Verkleidung dient kann nun gelöst und entfernt werden wie in Abbildung 3 abgebildet.
