Summary of Contents for Floyd Sofa 2.0
- Page 1 How to Assemble: The Sofa 2.0...
- Page 2 Components 6x Legs 1x Floyd Tool 12x Pins (B) 12x Knobs (A) 12x Bolts (C) Assembly Instructions The Sofa 2.0...
- Page 3 Components Cont’d 1x Back Panel 1x Seat Panel 2x Back Cushions 3x Seat Cushions 2x Arm Cushions 2x Arm Panels Assembly Instructions The Sofa 2.0...
- Page 4 Ottoman Components 4x Ottoman Legs 2x Connector Plates 1x Ottoman Panel 12x Knobs 1x Ottoman Cushion Assembly Instructions The Sofa 2.0...
-
Page 5: Assembling The Base
Step: 1 Assembling the Base... - Page 6 (B) into the holes on the leg and through the crossbar as shown. NOTE: The pins should click into place — make sure they go all the way through both sides of the leg. Assembly Instructions The Sofa 2.0...
- Page 7 On the same leg, insert two knobs (A) into the holes on the bottom of the plate. Turn to tighten. Repeat these steps for the remaining 5 legs, following the same order— first pins, then fasteners. Assembly Instructions The Sofa 2.0...
- Page 8 Once all six legs are securely attached with both pins and knobs, have your friend help flip the seat base upright. Next, take one arm panel and place it on the small ledges of the side legs. Assembly Instructions The Sofa 2.0...
- Page 9 Turn the bolt by hand to ensure that the bolt is tightening, then use the provided hex key to fully tighten the bolt. Attach the remaining arm panel and back panel the same way. Make sure all panels are securely attached before adding cushions. Assembly Instructions The Sofa 2.0...
- Page 10 Now you’re ready to add the cushions! The two widest cushions are for the back, three smaller cushions are for the seat, and the smallest two cushions are for the arms. If you don’t have an ottoman, that’s it—you’re done! Assembly Instructions The Sofa 2.0...
- Page 11 Assembling the Ottoman...
- Page 12 Begin by turning the ottoman over to attach the four legs to the bottom with the knobs. Once again, we recommend doing this on a rug or the packaging it came in to protect the surface of the panel. Assembly Instructions The Sofa 2.0...
- Page 13 Once all four legs are attached, flip over the chaise panel. If you’d like to attach the ottoman to your sofa for use a chaise, identify which side you’d like to attach it to— you can always change it later! Assembly Instructions The Sofa 2.0...
- Page 14 The side of the plate with the longer slotted hole should attach to the bottom of the seat panel, as shown. Use the remaining two knobs to fasten the Ottoman connector plates to the Seat Base. Assembly Instructions The Sofa 2.0...
- Page 15 Step: 2C You’re done! That’s it! Simply add your Ottoman cushion and enjoy your new Sofa. Don’t be shy, we’d love to see your Sofa in action— tag us on Instagram at @floyddetroit. Assembly Instructions The Sofa 2.0...
- Page 16 There is a risk of injury from not only intended as shown for use with the Floyd Sofa. following these warnings. Keep all packaging and The sofa is only meant for use indoors. The sofa parts away from children.
- Page 17 Assembly Instructions The Sofa 2.0...
