How to Assemble:
The Dresser System (Two Unit)

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dresser System and is the answer not in the manual?

Questions and answers

Related Manuals for Floyd Dresser System

Summary of Contents for Floyd Dresser System

  • Page 1 How to Assemble: The Dresser System (Two Unit)
  • Page 2 Components 2x Units 1x Top 2x Base Aprons 1x Base Leg Set 14x Bolts 8x Wing Nuts Pro Tip: If you’re considering a return, save your packaging! Assembly Instructions The Dresser System...
  • Page 3 Components 2x U-Brackets 1x Hex Tool 1x Anti-Tip Kit Pro Tip: If you’re considering a return, save your packaging! Assembly Instructions The Dresser System...

  • Page 4: Assembling The Base

    Step: 1 Assembling the Base Assembly Instructions The Dresser System...
  • Page 5 Base Aprons through the holes in the end of each Leg Set. Use the 8 provided Base Wing Nuts to secure the Base Aprons to the Leg Sets, making sure to fully tighten all Bolts. Assembly Instructions The Dresser System...
  • Page 6 Step: 1B Once assembled, place the Base on a level surface near its final location. Assembly Instructions The Dresser System...
  • Page 7 Step: 2 Adding the Units Assembly Instructions The Dresser System...
  • Page 8 Step: 2A With a partner, begin by placing the first Module onto the side of your choice. Both blocks on the underside of the Module should fit within the frame of the Base. Assembly Instructions The Dresser System...
  • Page 9 Step: 2B Ensure that the blocks located on the underside of the Module are aligned squarely between the Base Aprons. Slide the Module back and to the left until it stops. Assembly Instructions The Dresser System...
  • Page 10 Step: 2C With the first Module now in place, insert 4 Bolts through the openings in the Base Aprons as shown. Loosely tighten each by hand. Assembly Instructions The Dresser System...
  • Page 11 Step: 2D Repeat Steps 2A-C to install the second Unit. After both Units are in place, use the Hex Tool to tighten all Bolts. Assembly Instructions The Dresser System...
  • Page 12 Step: 2E Step: 2E Once the Units are in place and aligned, slide 2 U-Brackets into the slots at top of each Unit. Push both Brackets down firmly to secure the Units to one another. Assembly Instructions The Dresser System...
  • Page 13 Step: 2F Place the Top onto the The Dresser. Ensure the angled metal cleat on its underside fits between the opening at top of the Units. Assembly Instructions The Dresser System...
  • Page 14 Step: 2G With the angled metal cleat between the opening in the top of the Unit, push the Top back. The cleat should lock into place with corresponding cleat on top of the Unit. Assembly Instructions The Dresser System...
  • Page 15 Then, insert Bolts through the marked holes in the underside of the Units’ tops and into corresponding holes in the underside of the Top. Tighten with the Hex Tool. NOTE: For Units with drawers, open top drawer to insert Bolts. Assembly Instructions The Dresser System...
  • Page 16 Once Unit is in place and secured to wall follow next steps to attach drawer faces or doors. WARNING: Serious or fatal crushing injuries can occur from furniture tip-over. Always install tip-over restraint provided to help reduce risk of tip-over. Assembly Instructions The Dresser System...
  • Page 17 Step: 3 Finishing the Units Assembly Instructions The Dresser System...
  • Page 18 8x Screws Drawer Units Components 2 Medium Drawer Unit 3x Drawer Faces 12x Screws 12x Screws 2 Mixed Drawer Unit 3x Drawer Faces NOTE: To assemble these components, you’ll need a #2 Phillips-Head Screwdriver (not provided). Assembly Instructions The Dresser System...
  • Page 19 Screws and a #2 Phillips-Head Screwdriver. Once all 4 Screws are in place, tighten each. Then, one at a time, repeat these steps with the remaining Drawers. NOTE: For this step, you’ll need a #2 Phillips-Head Screwdriver (not provided). Assembly Instructions The Dresser System...
  • Page 20 1x Shelf 4x Shelf Pins Shelf Units Components 2 Door Unit 1x Shelf 4x Shelf Pins 2x Doors 8x Screws NOTE: To assemble the 2 Door Unit, you’ll need a #2 Phillips-Head Screwdriver (not provided). Assembly Instructions The Dresser System...
  • Page 21 Open Shelf Units Align the 4 Shelf Pins to the desired position. Place the Shelf atop the Shelf Pins. Assembly Instructions The Dresser System...
  • Page 22 Screw both hinge plates to the side of the case with the 4 provided Screws and tighten using a #2 Phillips-Head Screwdriver. Repeat on opposite door to finish. NOTE: For this step, you’ll need a #2 Phillips-Head Screwdriver (not provided). Assembly Instructions The Dresser System...
  • Page 23 You’re done! With a partner, adjust your Dresser into its final positon (if necessary), ensure all screws and bolts are firmly in place, and enjoy your new furniture. Assembly Instructions The Dresser System...
  • Page 24 Double check that product is assembled correctly and all components Usage: are properly tightened before use. Periodically Remove all packaging before first use. re-tighten hardware. Only meant for indoor use. Assembly Instructions The Dresser System...
