Summary of Contents for Floyd Cabinet

  • Page 1 Cabinet...

  • Page 2: Table Of Contents

    Table of Contents Components Tall Kit Short Kit Add On Installing the Wall Anchor + Adding a Tall Shelf with a Cabinet? + Adding a Short Shelf with a Cabinet? Warning...

  • Page 3: Components

    Components TALL SHORT + Cabinet Expansion + Cabinet Expansion 1 × 1 × 1 × 1 × Hex Tool TALL SHORT + Cabinet Expansion + Cabinet Expansion 16 × 16 × 8 × 8 × Bolts TALL SHORT + Cabinet...
  • Page 4 Components TALL SHORT + Cabinet Expansion + Cabinet Expansion 4 × 2 × 4 × 2 × Wood Supports TALL Expansion + Cabinet 1 × 1 × Fixed Shelves...
  • Page 5 Components TALL SHORT + Cabinet Expansion + Cabinet Expansion 3 × 3 × Shelves 1 × 1 × TALL SHORT + Cabinet Expansion + Cabinet Expansion 1 × 1 × 1 × 1 × Cabinet...
  • Page 6 Wall Anchor Kit Components Wall Anchor Bracket 1 × 2 × Screws 2 × Drywall Anchors 2 × Velcro Tape Straps (choose black or white)
  • Page 7 Additional items you may need for installing the Wall Anchor: 1 × Phillips Head Screwdriver Hammer 1 × 1 × Drill w/ 1/4” Drill Bit...

  • Page 8: Tall Kit

    Cabinet Tall Kit...
  • Page 9 Position Place one fixed shelf (a) with its back edge on the floor and have a friend hold in place. Place two wood supports on either side first fixed of the fixed loop with the metal part facing down. shelf The bottom end of the wood supports have a notch cut in the wood.
  • Page 10 Begin to Insert two bolts through the square holes in the fixed shelf (a) and until attach they are fully inserted. the first Next, insert the nuts (b) through the holes in the fixed wood and begin to tighten them to the bolts by hand. shelf...
  • Page 11 Tighten Finish tightening the nuts with the hex tool. The bolt should stay in place, but fasteners may need to be pressed to hold in place when to secure tightening the nut. the fixed Repeat steps 2a–2b to tighten the fasteners on the other side before shelf to proceeding.
  • Page 12 Attach Take the two remaining wood supports and attach them to the fixed shelf as the front shown in steps 2a–2b. Have a friend hold the wood wood supports in place while you attach them to the fixed shelf. supports...
  • Page 13 Stand Stand the shelf upright with the help of a friend. the shelf Note: After standing up the shelf, double check each upright connection to make sure fasteners are fully tightened and secure.
  • Page 14 Set up the Take the notched cardboard sheet that’s included with the packaging and fold it up cardboard into a 4-sided box. assembly...
  • Page 15 Place the Place the cardboard assembly box on the floor between the wood supports. cardboard assembly...
  • Page 16 Attach Set the cabinet in place from the back, having a friend help hold it. We suggest having one person hold it from the front and one person guide it into cabinet place from behind. Attach the hooks on the back of the cabinet into the bottom slots of the vertical wood supports.
  • Page 17 Secure Underneath the cabinet, insert the bolts through the square holes on the bottom edge of the unit. Make sure the bolts are fully seated. Then, insert the cabinet to nuts through the holes on the outside of the vertical wood...
  • Page 18 Tighten Finish tightening all of the nuts on both sides (8x) with the hex tool. fasteners...
  • Page 19 Add the To attach the shelves, insert each shelf from the back at a 45 degree angle. Rotate the shelves shelf parallel to the floor so that the tall side flanges of the shelf are in between the wood supports. Insert the hooks on each shelf into the slots in the metal tracks on the back side of each wood support.
  • Page 20 Adjust the The shelf spacing is adjustable. With each shelf attached to the middle slot, the shelves will shelves be evenly spaced. To increase or decrease shelf spacing, insert (optional) the hooks on the shelves into the slots above or below the middle slots.
  • Page 21 Install After adding the shelves & adjusting them as desired, place the fully assembled the wall shelf unit against the wall. anchor Now that the assembly is complete, flip ahead to the page 81 to install the Wall Anchor and attach your Shelving System to the wall.

  • Page 22: Short Kit

    Cabinet Short Kit...
  • Page 23 Fold up Take the notched cardboard sheet that’s included with the packaging and fold it up into the card- a 4-sided box. board assembly...
  • Page 24 Set up the Place the cardboard assembly box on the floor. cardboard assembly...
  • Page 25 Attach Starting with the back wood supports, attach the hooks of the cabinet unit to the cabinet bottom set of slots on the back of the supports. to back wood supports...
  • Page 26 Secure Underneath the cabinet, insert the bolts through the square holes on the bottom edge of the unit. Make sure the bolts are fully seated. Then, insert the cabinet to nuts through the holes on the outside of the vertical wood...
  • Page 27 Tighten Finish tightening all of the nuts on both sides (4x) with the hex tool. fasteners...
  • Page 28 Attach Repeat steps 3-5 with the front wood supports. There are no hooks in the front – front we recommend having a friend help hold the wood wood supports in place while you tighten the fasteners. supports...
  • Page 29 Add the To attach the shelves, insert each shelf from the back at a 45 degree angle. Rotate the shelves shelf parallel to the floor so that the tall side flanges of the shelf are in between the wood supports. Insert the hooks on each shelf into the slots in the metal tracks on the back side of each wood support.
  • Page 30 Adjust the The shelf spacing is adjustable. With each shelf attached to the middle slot, the shelves will shelves be evenly spaced. To increase or decrease shelf spacing, insert (optional) the hooks on the shelves into the slots above or below the middle slots.
  • Page 31 You're Place your shelf against the wall. You are done with setting up your new Floyd Shelf! done! @floyddetroit #thefloydshelf...

  • Page 32: Add On

    Cabinet Add On...
  • Page 33 Remove Remove the bottom adjustable shelf and set it aside, keeping the fixed shelf attached. bottom adjustable shelf...
  • Page 34 Release Using a 5/32” (4mm) hex tool, loosen the fasteners on the bottom fixed shelf. Remove fasteners the shelf and set aside. on the bottom fixed shelf...
  • Page 35 Fold up Take the notched cardboard sheet that’s included with the packaging and fold it up into the card- a 4-sided box. board assembly...
  • Page 36 Place the Place the cardboard assembly box on the floor between the wood supports. cardboard assembly...
  • Page 37 Attach Set the cabinet in place from the back, having a friend help hold it. We suggest having one person hold it from the front and one person guide it into cabinet place from behind. Attach the hooks on the back of the cabinet into the bottom slots of the vertical wood supports.
  • Page 38 Secure Underneath the cabinet, insert the bolts through the square holes on the bottom edge of the unit. Make sure the bolts are fully seated. Then, insert the cabinet to nuts through the holes on the outside of the vertical wood...
  • Page 39 Tighten Finish tightening all of the nuts on both sides (8x) with the hex tool. fasteners...
  • Page 40 Install Place the fully assembled shelf unit against the wall. the wall Now that the assembly is complete, flip ahead to the anchor next page to install the Wall Anchor and attach your Shelving System to the wall. The Wall Anchor Kit should be installed to help prevent furniture tip-over.

  • Page 41: Installing The Wall Anchor

    Install the wall anchor Note: The use of the Wall Anchor Kit may only reduce, but not eliminate, the risk of tip-over. For safe mounting, it is essential to use wall anchors appropriate to your wall type (i.e. dry- wall, plaster, brick, concrete, etc). The following steps and provided hardware are for drywall or wood stud mounting.
  • Page 42 Mark the Mark the slots on the back of the fixed shelf on the wall with a pencil, then move the shelf wall unit away from wall. Align the wall anchor bracket between the slot marks, then mark the holes in the wall anchor bracket with a pencil.
  • Page 43 Insert Set the wall anchor bracket aside and drill two holes into the wall with a 1/4” drywall drill bit (x2). anchors Push the drywall anchors into wall by hand (x2). If (if needed) mounting to a stud, do not use the drywall anchors.
  • Page 44 Attach Align the wall anchor bracket with the two holes and screw it to the wall using the provided the wall screws and a Phillips head screwdriver (x2). For stud anchor mounting, use a power drill with a Phillips head bit for the screws. bracket Feed the Velcro Tape strap through the two slots in the...
  • Page 45 Fasten Move the shelf unit back against the wall. Feed the Velcro Tape 1.5” strap through the two slots in the strap the back of the fixed shelf. Fold one side flat against the fixed shelf before folding the other side over it and pressing firmly along the length of the tape to secure the strap.
  • Page 46 You're Don't be shy – we'd love to see your shelf's new home! done! @floyddetroit #thefloydshelf...

  • Page 47: Adding A Tall Shelf With A Cabinet

    After tightening all fasteners, & the new shelves from the back. Note: When adding a tall shelf with a cabinet to an existing shelf, or when assembling two together, the shelf units will share two center wood supports and the fasteners used to attach the fixed shelves to the center wood.
  • Page 48 Adding First, choose which side you wish to attach the additional short shelf with a cabinet to. a Short Release the fasteners on the bottom fixed shelf and attach Shelf with the cabinet to the center wood supports with the first bottom fixed shelf.

  • Page 49: Warning

    The Shelving System on the floor against a wall. Disassemble before moving. The maximum weight limit per shelf is 65 lbs (29 kg). The maximum weight limit for the Cabinet is 130 lbs (59 kg) distributed between the interior of the cabinet and the top surface area.
  • Page 50 FLOYDHOME.COM...
