- Page 1 Jarvis Standing Desk...
- Page 2 This Jarvis height adjustable desk has electric motors and is designed for use in dry work environments only. This Jarvis desk is adjustable so it can be positioned at an optimal ergonomic height. Any extracurricular use is at user’s own risk.
- Page 3 Components 2 × Lifting Column 1 × Frame End (w/ Capture Plate) 1 × Frame End 2 × Foot 2 × Center Rail...
- Page 4 Components Cont. 1 × Right Side Bracket 1 × Left Side Bracket 1 × Control Box 1 × Power Cable 1 × Leg Cable...
- Page 5 Components Cont. 10 × Cable Clip 12 × Media Machine Screw 8 × Small Machine Screw 8 × Medium Set Screw (Pre-Installed) 5 × Noise Attenuation (extra) Grommet...
- Page 6 Components Cont. 9 × Desktop Washer 1 × Memory Handset 1 × 3mm Hex Wrench 1 × 4mm Hex Wrench Phillips Screw Driver Included...
- Page 7 Lifting Column Insert one of the Lifting Columns (either one; they’re identical) into the Frame End with the Capture Plate. Frame End (w/ Capture Plate) To Secure the Frame End to the Lifting Column, thread four (4) of the Small Machine Screws into the holes as shown, but do Small Machine Screws not tighten them all the way.
- Page 8 Repeat Steps 1-2 for the D ecide if you want your Handset Step 1 Assembly remaining Lifting Column, on the left side or the right side of Frame End and Side Bracket. your finished desk. Select the Left or Right Side Left or Right Side Bracket Bracket (corresponding to the side...
- Page 9 *Leg Assembly w/ Capture Plate uses 4 screws. Leg Assembly w/o Capture Plate uses 5 screws. (Front edge of Floyd Desktop) L ay your desktop on a padded Step 2 Assembly surface with the underside facing up, and the front of the desktop towards you.
- Page 10 (Correct center of rail orientation) Center Rail Slide the Center Rails into the Frame End attached to the desktop, so that the midpoint mark is facing up and the cut- out slots are facing inwards. Slide the Right Leg Assembly onto the other end of the Center Rails (your left-hand side).
- Page 11 *Leg Assembly w/ Capture Plate uses 4 screws. Leg Assembly w/o Capture Plate uses 5 screws. Secure the Right Leg Assembly 4x/5x* Desktop Machine Screws to the desktop with the appropriate screws. Insert all screws part way. 4x/5x* Desktop Washer Once they are in place, tighten them completely.
- Page 12 Center the labeled midpoint Medium Set Screw (Pre-Installed) marks on both Center Rails between the two Frame Ends, and use the pre-sintalled Set Screws to lock the Center Rails down firmly.
- Page 13 Handset use included Wood Screws and holes 3 & 4 as shown. Wood Screw The Floyd Desktop comes with pre-drilled holes for attaching your Handset along the front of the desktop, on both the left and right sides. Keep in mind...
- Page 14 PRO TIP: Control Box Cable Management Cable Clips work best adhered directly to the Jarvis metal frame. Route your Power Cord & Leg Cable towards Power Cable the side of your nearest wall outlet, or use a cable management tray for optimal cable taming.
- Page 15 Loosely attach a Foot to the Foot bottom of each Lifting Column using four (4) Medium Machine Screws per Foot. Medium Machine Screw Once all screws are in place, tighten them down the rest of the way in an X pattern.
- Page 16 Double-check that all screws With one friend (or more), lift everywhere on the desk are the desk and gently flip it onto tight. Triple-check that all its feet. As you flip it support screws everywhere on the desk both the top and the frame, are tight.
- Page 17 You can now use your Jarvis Frame. PROGRAMMING MEMORY PRESETS To program your memory presets, raise or lower your Jarvis to your preferred height. Then, press the M icon followed by one of the four numbers you want to preset. This number will return Jarvis to your preferred height from now on.
- Page 18 All done! Now, don’t be shy— we’d love to see your table’s new home! @floyddetroit #thefloydtable...
- Page 19 MAX HEIGHT down and then use a tape measure to determine the height from If you want to limit how high your Jarvis can go, set a Max height the top of your desktop to the floor. Select the Calibrate height limit.
- Page 20 For the 1948 Division St. Suite 101 Floyd Side Table, do not load with more than 200 lbs (90 kg). For the other Tables, do not Detroit, MI 48207 load with more than 150 lbs (68 kg).
- Page 21 FLOYDHOME.COM...
