Summary of Contents for Floyd Shelving System

  • Page 1 Shelving System...

  • Page 2: Table Of Contents

    Table of Contents Components The Tall Shelf The Short Shelf The Wardrobe The Display Shelf Installing the Wall Anchor + Adding a Tall Shelf? + Adding a Short Shelf? + Adding a Wardrobe? + Adding a Display Shelf?

  • Page 3: Components

    Components 4 × Wood Supports a. Tall / Wardrobe / Display b. Short Tall Short Display Wardrobe 2 × 1 × 2 × 2 × Fixed Shelves...
  • Page 4 Components cont. Tall Short Display Wardrobe 2 × 3 × 1 × 4 × Shelves 1 × Hex Tool Tall Short Display Wardrobe 16 × 8 × 16 × 16 × Bolts 16 × 8 × 16 × 16 × Nuts 8 ×...
  • Page 5 Components cont. WARDROBE ONLY Wardrobe Brackets 2 × Wardrobe Bar 1 × DISPLAY SHELF ONLY 1 × Display Shelf...
  • Page 6 Wall Anchor Kit Components Wall Anchor Bracket 1 × 2 × Screws 2 × Drywall Anchors 1 × Velcro Tape Strap...
  • Page 7 Additional items you may need for installing the Wall Anchor: 1 × Phillips Head Screwdriver Hammer 1 × 1 × Drill w/ 1/4” Drill Bit...
  • Page 8 – Two people are recommended for assembly. – If your floor is uneven, you can use the provided felt pads to level your Shelving System. The felt pads can be stacked on top of each other to add more height on one or more Wood Supports as needed.

  • Page 9: The Tall Shelf

    Shelf System The Tall Shelf...
  • Page 10 Position Place one fixed shelf (a) with its back edge on the floor and have a friend hold in place. Place two wood supports on either side first fixed of the fixed loop with the metal part facing down. shelf The bottom end of the wood supports have a notch cut in the wood.
  • Page 11 Begin to Insert two bolts through the square holes in the fixed shelf (a) and until attach the they are fully inserted. first fixed Next, insert the nuts (b) through the holes in the shelf wood and begin to tighten them to the bolts by hand.
  • Page 12 Tighten Finish tightening the nuts with the hex tool. The bolt should stay in place, but may fasteners need to be pressed to hold in place when tightening the nut. to secure Repeat steps 2a–2b to the fixed tighten the fasteners on the other side before proceeding.
  • Page 13 Attach Place the fixed shelf (b) at the top of the wood supports and repeat steps 2a–2b to second attach it to the two wood supports. fixed shelf at the top...
  • Page 14 Attach Take the two remaining wood supports and attach them to the fixed shelf as the front shown in steps 2a–2b. Have a friend hold the wood supports wood in place while you attach them to the fixed shelves. supports...
  • Page 15 Stand the Stand the shelf upright with the help of a friend. Shelf up- Note: After standing up the shelf, double check each right connection to make sure fasteners are fully tightened and secure.
  • Page 16 Add the To attach the shelves, insert each shelf from the back at a 45 degree angle. Rotate the shelf parallel to the shelves floor so that the tall side flanges of the shelf are in between the wood supports. Insert the hooks on each shelf into the slots in the metal tracks on the back side of each wood support.
  • Page 17 Adjust The shelf spacing is adjustable. With each shelf attached to the middle slot, the shelves will be evenly spaced. To increase or decrease shelf spacing, insert shelves the hooks on the shelves into the slots above or below the (optional) middle slots.
  • Page 18 Install After adding the shelves and adjusting them as desired, place the fully assembled the wall shelf unit against the wall. anchor Now that the assembly is complete, flip ahead to page 100 to install the Wall Anchor and attach your Shelving System to the wall.

  • Page 19: The Short Shelf

    Shelf System The Short Shelf...
  • Page 20 Position Place the fixed shelf with its back edge on the floor and have a friend hold in the fixed place. Place two wood supports on either side shelf of the fixed loop with the metal part facing down. The bottom end of the wood supports have a notch cut in the wood.
  • Page 21 Begin to Insert two bolts through the square holes in the fixed shelf (a) and until attach the they are fully inserted. fixed shelf Next, insert the nuts (b) through the holes in the wood and begin to tighten them to the bolts by hand.
  • Page 22 Tighten Finish tightening the nuts with the hex tool. The bolts should stay in place, but may fasteners need to be pressed to hold in place when tightening the nut. to secure Repeat steps 2a–2b to tighten the fixed the fasteners on the other side before proceeding.
  • Page 23 Attach Take the two remaining wood supports and attach them to the fixed shelf as shown in the front steps 2a–2b. Have a friend hold the wood supports in wood place while you attach them to the fixed shelf. supports...
  • Page 24 Stand the After standing the shelf upright, double check each connection to make sure shelf up- fasteners are fully tightened and secure. right...
  • Page 25 Add the To attach the shelves, insert each shelf from the back at a 45 degree angle. Rotate the shelves shelf parallel to the floor so that the tall side flanges of the shelf are in between the wood supports. Insert the hooks on each shelf into the slots in the metal tracks on the back side of each wood support.
  • Page 26 Adjust the The shelf spacing is adjustable. With each shelf attached to the middle slot, the shelves will shelves be evenly spaced. To increase or decrease shelf spacing, (optional) insert the hooks on the shelves into the slots above or below the middle slots.
  • Page 27 You're Place the fully assembled shelf unit against the wall. done! Don't be shy – we'd love to see your shelf's new home! @floyddetroit #thefloydshelf...

  • Page 28: The Wardrobe

    Shelf System Wardrobe...
  • Page 29 Position Place one fixed shelf (a) with its back edge on the floor and have a friend hold the first in place. Place two wood supports on either side fixed of the fixed loop with the metal part facing down. shelf The bottom end of the wood supports have a notch cut in...
  • Page 30 Begin to Insert two bolts through the square holes in the fixed shelf (a) and until they are attach the fully inserted. first fixed Next, insert the nuts (b) through the holes in the shelf wood and begin to tighten them to the bolts by hand.
  • Page 31 Tighten Finish tightening the nuts with the hex tool. The bolt should stay in place, but may fasteners need to be pressed to hold in place when tightening the nut. to secure Repeat steps 2a–2b to tighten the fixed the fasteners on the other side before proceeding.
  • Page 32 Attach Place the second fixed shelf (b) at the top of the wood supports and repeat steps second 2a–2b to attach it to the two wood supports. fixed shelf at the top...
  • Page 33 Attach Take the two remaining wood supports and attach them to the fixed shelves as shown in front wood steps 2a–2b, starting with the bottom fixed shelf. supports Before attaching the top to the fixed shelf to the wood supports, you will need to attach the wardrobe bar and bottom brackets.
  • Page 34 Attach Take the wardrobe bar and slide the other wardrobe bracket onto it. Then, insert wardrobe the wardrobe bar into the bracket that is already bar and attached. brackets Next, rotate the wardrobe bar into place and attach the second wardrobe bracket to fixed and fixed shelf to the front wood support.
  • Page 35 Stand the Stand the shelf upright with the help of a friend. shelf up- After standing the shelf upright, double check each right connection to make sure fasteners are fully tightened and secure.
  • Page 36 Add the To attach the shelf, insert shelf from the back at a 45 degree angle. Rotate the shelf shelf parallel to the floor so that the tall side flanges of the shelf are in between the wood supports. Insert the hooks on each shelf into the slots in the metal tracks on the back side of each wood support.
  • Page 37 Adjust the The shelf spacing is adjustable. With the shelf attached to the middle slot, the shelf will be shelf evenly spaced with the fixed shelf below it. To increase or (optional) decrease shelf spacing, insert the hooks on the shelves into the slots above or below the middle slots.
  • Page 38 Install Now that the assembly is complete, flip ahead to page 100 to install the Wall Anchor the wall and attach your Shelving System to the wall. The Wall anchor Anchor Kit should be installed to help prevent furniture tip-over. @floyddetroit #thefloydshelf...

  • Page 39: The Display Shelf

    Shelf System Display Shelf...
  • Page 40 Position Place one fixed shelf (a) with its back edge on the floor and have a friend hold the first in place. Place two wood supports on either side fixed of the fixed loop with the metal part facing down. shelf The bottom end of the wood supports have a notch cut in...
  • Page 41 Begin to Insert two bolts through the square holes in the fixed shelf (a) and until they are attach the fully inserted. first fixed Next, insert the nuts (b) through the holes in the shelf wood and begin to tighten them to the bolts by hand.
  • Page 42 Tighten Finish tightening the nuts with the hex tool. The bolt should stay in place, but may fasteners need to be pressed to hold in place when tightening the nut. to secure Repeat steps 2a–2b to tighten the fixed the fasteners on the other side before proceeding.
  • Page 43 Attach Place the second fixed shelf (b) at the top of the wood supports and repeat second steps 2a–2b to attach it to the two wood supports. fixed shelf at the top...
  • Page 44 Attach Take the two remaining wood supports and attach them to the fixed shelf as shown in the front steps 2a–2b. Have a friend hold the wood supports in wood place while you attach them to the fixed shelves. supports...
  • Page 45 Stand the Stand the shelf upright with the help of a friend. shelf up- Note: After standing up the shelf, double check each right connection to make sure fasteners are fully tightened and secure.
  • Page 46 Add the To attach the shelves, insert each shelf from the back at a 45 degree angle. Rotate the shelves shelf parallel to the floor so that the tall side flanges of the shelf are in between the wood supports. Insert the hooks on each shelf into the slots in the metal tracks on the back side of each wood support.
  • Page 47 Attach Rotate the display shelf 45 degrees, then insert from behind. Rotate so it’s parallel to the floor and insert the back hooks into the slots in the wood supports. Display Shelf...
  • Page 48 Attach Tilt the shelf forward so that the hooks go into the slots and the edges on the front of the shelf are resting on the front of the wood supports. Display Note: The Display shelf can be Shelf attached with any of the slots where a standard shelf can be attached.
  • Page 49 Adjust The shelf spacing is adjustable. With each shelf attached to the middle slot, the shelves will be shelves evenly spaced. To increase or decrease shelf spacing, insert (optional) the hooks on the shelves into the slots above or below the middle slots.
  • Page 50 Continue to the next page to install the Wall Anchor and attach your Shelving System to the wall. The Wall Anchor Kit should be installed to help prevent furniture tip-over. @floyddetroit #thefloydshelf...

  • Page 51: Installing The Wall Anchor

    – Place heaviest items in the lowest shelves. – Do not set TVs or other heavy objects on the top of the Shelving System. – Never allow children to climb or hang on shelves. Note that the use of the Wall Anchor Kit may only reduce, but not eliminate, the risk of tip-over.
  • Page 52 Mark the Mark the slots on the back of the fixed shelf on the wall with a pencil, then move the shelf wall unit away from wall. Align the wall anchor bracket between the slot marks, then mark the holes in the wall anchor bracket with a pencil.
  • Page 53 Insert Set the wall anchor bracket aside and drill two holes into the wall with a 1/4” drywall drill bit (x2). anchors Push the drywall anchors (if needed) into wall by hand (x2). If mounting to a stud, do not use the drywall anchors.
  • Page 54 Attach Align the wall anchor bracket with the two holes and screw it to the wall using the provided the wall screws and a phillips head screwdriver (x2). For stud anchor mounting, use a power drill with a phillips head bit for the screws. bracket Feed the Velcro Tape strap through the two slots in the...
  • Page 55 Fasten Move the shelf unit back against the wall. Feed the Velcro Tape 1.5” strap through the two slots in the strap the back of the fixed shelf. Fold one side flat against the fixed shelf before folding the other side over it and pressing firmly along the length of the tape to secure the strap.
  • Page 56 You're Don't be shy – we'd love to see your shelf's new home! done! @floyddetroit #thefloydshelf...

  • Page 57: Adding A Tall Shelf

    Adding First, choose which side you wish to attach the additional tall shelf to. Release the fasteners on the a Tall bottom fixed shelf and attach the new fixed shelf to the wood Shelf? supports before releasing the fasteners on the top fixed shelf. Then attach the new top fixed shelf to the wood supports with the first top fixed shelf.
  • Page 58 Adding First, choose which side you wish to attach the short shelf to. Release the fasteners on the a Short bottom fixed shelf on that side. The same fasteners will be used Shelf? to attach the new fixed shelf to the wood supports.
  • Page 59 Adding a First, choose which side you wish to attach the wardrobe to. Release the fasteners on the Wardrobe? fixed shelves on that side. The same fasteners will be used to attach new fixed shelves to the wood supports. Attach the two new fixed shelves to the two new wood supports on the outside, following the steps for a tall...
  • Page 60 Adding a First, choose which side you wish to attach the additional display shelf to. Release the fasteners Display on the fixed shelves on that side. The same fasteners will be used Shelf? to attach new fixed shelves to the wood supports. Attach the two new fixed shelves to the two new wood supports on the outside.
  • Page 61 To further reduce the risk of furniture tip-overs: – Place heaviest items in the lowest shelves. – Do not set TVs or other heavy objects on the top of the Shelving System. – Never allow children to climb or hang on shelves.
  • Page 62 FLOYDHOME.COM...
