- Page 1 Media Console...
- Page 2 Table of Contents Conversion Kit Components Setting up a Media Console with four Shelves Setting up a Media Console with two Cabinets Setting up a Media Console with two Shelves + one Cabinet + Expanding a Tall Shelf with a...
- Page 3 Expanding If expanding to a shelf unit purchased before 10-12-2020, you'll need a conversion kit in a Media order to complete your set up. Console to a Shelf Unit Purchased before 10-12-2020?
- Page 4 Cont. Remove the supports on the sie that you'd like to expand to and replace them with your updated supports. Once you've replaced your supports, follow the instructions for expanding a media console onto an existing shelf unit.
- Page 5 Components MEDIA CONSOLE 4 Shelves 2 Cabinets 2 Shelves + 1 Cabinet 1 × 1 × 1 × Hex Tool 12 × 12 × 12 × Bolts 12 × 12 × 12 × Nuts 1 × 1 × 1 ×...
- Page 6 Components MEDIA CONSOLE 4 Shelves 2 Cabinets 2 Shelves + 1 Cabinet 6 × 6 × 6 × Wood Verticles 0 × 2 × 1 × Shelves 0 × 2 × 1 × Cabinets 0 × 0 × 1 ×...
- Page 7 Media Console Four Shelves...
- Page 8 Position Place the fixed shelf with its back edge on the floor and have a friend hold in place. Align the the first holes on the wood supports to the holes on the fixed shelf. The fixed shelf metal plate on the wood supports should be facing the ground.
- Page 9 Begin Insert two bolts through the square holes in the fixed shelf (a) and until they are to attach fully inserted. Next, insert the nuts (b) through the holes in the first the wood and begin to tighten them to the bolts by hand. fixed shelf...
- Page 10 Tighten Finish tightening the nuts with the hex tool. The bolt should stay in place, but may need to fasteners be pressed to hold in place when tightening the nut. to secure the fixed shelf to the wood supports...
- Page 11 Set up Take the second fixed shelf and two more wood supports and attach them together following second steps 2a-2b. fixed shelf...
- Page 12 Attach Take the three remaining wood supports and attach them to the fixed shelves as shown in steps 2a-2b. Have a friend help hold the wood supports in place while you remaining attach them to the fixed shelves. wood supports...
- Page 13 Stand Note: After standing up the shelf, double check each connection to make sure fasteners are fully the shelf tightened and secure. upright...
- Page 14 Add the To attach the shelves, insert each shelf from the back at a 45 degree angle. Rotate the shelf shelves parallel to the floor so that the tall side flanges of the shelf are in between the wood supports. Insert the hooks on each shelf into the slots in the metal tracks on the back side of each wood...
- Page 15 Adjust the The shelf spacing is adjustable. With each shelf attached to the middle slot, the shelves will shelves be evenly spaced. To increase or decrease shelf spacing, (optional) insert the hooks on the shelves into the slots above or below the middle slots.
- Page 16 Place felt Take two felt pads from the assembly components box and attach them to the tops of the pads on two middle supports. These will help prevent wear between the top of wood supports and metal shelf. middle supports...
- Page 17 Position Place the media console shelf down so it rests on the center wood supports. the media console shelf...
- Page 18 Attach From behind, insert the hooks on the media console shelf into the slots in the metal tracks on the media the back of the four outer wood supports. console Note: Make sure all four hooks shelf on each shelf are inserted into theslots in the metal tracks on the wood supports.
- Page 19 That's it! Place the fully assembled shelf unit against the wall. Don't be shy — we'd love to see your shelf's new home! @floyddetroit #thefloydshelf...
- Page 20 Media Console Two Cabinets...
- Page 21 Set up the Take the notched cardboard sheet that’s included with the packaging and fold it up into a cardboard 4-sided box. assembly...
- Page 22 Place the Place the cardboard assembly box on the floor then carefully set the cabinet down so it rests cardboard on the box. assembly...
- Page 23 Attach Starting with the back outside wood support, attach the hook of the cabinet unit to the bottom cabinet slot on the metal track on the back of the wood support. to back wood supports...
- Page 24 Secure the Underneath the cabinet, insert the bolts through the square holes on the bottom edge of the cabinet to unit. Make sure the bolts are fully seated. Then, insert the the wood nuts through the holes on the outside of the vertical wood supports supports and begin tightening them with the hex tool.
- Page 25 Tighten Finish tightening all of the nuts on both sides (8x) with the hex tool. fasteners...
- Page 26 Attach Repeat steps 4-5 with the front left wood support. Since there is no hook in the front to attach to the front the wood support, have a friend help hold it in place while you wood tighten the fasteners. support...
- Page 27 Attach Take the next two wood supports and attach them to the cabinet. Start with the back wood the middle support, setting the hook on cabinet into the bottom slot in wood the metal track on the back of the wood support. supports...
- Page 28 Insert Then have a friend hold the front wood support and insert the bolts through the square holes on bolts the bottom edge of the unit into the holes on the wood supports. through holes in cabinet...
- Page 29 Place Place the cardboard assembly box on the floor then carefully set the cabinet down so it rests second on the box. Place the hook on the cabinet into the bottom cabinet slot of the metal track on the back of the wood support.
- Page 30 Secure Insert the nuts through the square holes on the second cabinet and begin tightening fasteners them to the bolts by hand. Finish tightening with the to attach hex tool. cabinets to middle wood supports...
- Page 31 Attach the Repeat steps 3-5 with the back right and front right wood supports. Since there is no hook right side for the front wood support, have a friend hold it in place while you outer wood tighten the fasteners. supports...
- Page 32 Place felt Take two felt pads from the assembly components box and attach them to the tops of the pads on two middle supports. These will help prevent wear between the top of wood supports and metal shelf. middle supports...
- Page 33 Position Place the media console shelf down so it rests on the center wood supports. the media console shelf...
- Page 34 Attach From behind, insert the hooks on the media console shelf into the slots in the metal tracks on the media the back of the four outer wood supports. console Note: Make sure all four hooks shelf on each shelf are inserted into the slots in the metal tracks on the wood supports.
- Page 35 That’s it! Place the fully assembled shelf unit against the wall. Don't be shy — we'd love to see your shelf's new home! @floyddetroit #thefloydshelf...
- Page 36 Media Console Two Shelves, one cabinet...
- Page 37 Position Place the fixed shelf with its back edge on the floor and have a friend hold in place. Align the the first holes on the wood supports to the holes on the fixed shelf. The fixed shelf metal plate on the wood supports should be facing the ground.
- Page 38 Begin Insert two bolts through the square holes in the fixed shelf (a) and until they are fully to attach inserted. Next, insert the nuts (b) through the holes in the the first wood and begin to tighten them to the bolts by hand. fixed shelf Note: It may be easier to get the bolts engaged with the nuts...
- Page 39 Tighten Finish tightening the nuts with the hex tool. The bolt should stay in place, but may need to fasteners be pressed to hold in place when tightening the nut. to secure the fixed shelf to the wood supports...
- Page 40 Attach Repeat step 2 for the front wood support. front wood support.
- Page 41 Stand the Stand the fixed shelf and wood supports upright. Have a friend help hold them in place while you assembly get the next two wood supports and the cabinet. upright...
- Page 42 Insert Have a friend hold the middle wood supports while you insert the bolts through the bottom the bolts edge of the cabinet.
- Page 43 Place the Place the cardboard assembly box on the floor then carefully set the cabinet down so it rests cabinet on the box. Place the hook on the cabinet into the bottom slot of the metal track on the back of the wood support.
- Page 44 Tighten Insert the nuts through the square holes on the bottom edge of the cabinet and begin tightening by hand. Finish tightening with the hex tool. fasteners...
- Page 45 Attach Repeat step 2 with the back right and front right wood supports. Since there is no hook for the front wood front wood support, have a friend hold it in place while you tighten supports the fasteners. to cabinet...
- Page 46 Add the To attach the shelf, insert it from the back at a 45 degree angle. Rotate the shelf parallel to the shelf floor so that the tall side flanges of the shelf are in between the wood supports. Insert the hooks on each shelf into the slots in the metal tracks on the back side of each wood support.
- Page 47 Adjust The shelf spacing is adjustable. With each shelf attached to the middle slot, the shelves will be the shelf evenly spaced. To increase or decrease shelf spacing, insert the (optional) hooks on the shelves into the slots above or below the middle slots.
- Page 48 Place felt Take two felt pads from the assembly components box and attach them to the tops of the pads on two middle supports. These will help prevent wear between the middle wood supports and metal shelf. supports...
- Page 49 Position Place the media console shelf down so it rests on the center wood supports. the media console shelf...
- Page 50 Attach From behind, insert the hooks on the media console shelf into the slots in the metal tracks the media on the back of the four outer wood supports. console Note: Make sure all four hooks shelf on each shelf are inserted into the slots in the metal tracks on the wood supports.
- Page 51 That’s it! Place the fully assembled shelf unit against the wall. Don't be shy — we'd love to see your shelf's new home! @floyddetroit #thefloydshelf...
- Page 52 Expanding First, choose which side you wish to attach the additional tall shelf with a media console to. a Tall Release the fasteners on the top fixed shelf and attach the new Shelf with fixed shelf to the center wood...
- Page 53 Expanding First, choose which side you wish to attach the additional short shelf with a media console a Short to. Release the fasteners on the bottom fixed shelf and attach Shelf with the media console to the center wood supports with the first a Media bottom fixed shelf.
- Page 54 (59 kg) distributed between the interior of the cabinet and the top surface area. The maximum weight limit of the Media Console shelf is 65 lbs (29 kg). The maximum weight limit for the wardrobe bar is 50 lbs (22 kg). Do not exceed these weight limits. Inspect fastener connections and wall anchor system regularly for signs of wear.
